Ryobi RFL4 Original Instructions

ORIGINAL INSTRUCTIONS
4V USB Lithium LED Flip Light
RFL4
IMPORTANT!
It is essential that you read the instructions in
this manual before assembling, operating, and
maintaining the product.
Subject to technical modifications.
Safety, performance, and dependability have been
given top priority in the design of your flip light.
INTENDED USE
The flip light is intended for general illumination.
The product is protected against water splashed
from all directions, limited ingress permitted. Do
not submerge the product in water or other liquids.
When using magnet, check to ensure secure
attachment. Ensure magnet is used on solid metal
surface that works with magnets. For example,
22-gauge low carbon steel surface will provide
greater magnetic adhesion.
Do not use the product for any other purpose.
Use of the product for operations different from
intended could result in a hazardous situation.
FLIP LIGHT SAFETY WARNINGS
■ The light source contained in this luminaire
shall only be replaced by the manufacturer or
his service agent or a similar qualified person.
■ Use only with recommended battery pack. Any
attempt to use another battery pack will cause
damage to the product and could possibly
explode, cause a fire, or personal injury.
■ Do not disassemble the product.
■ If wrapped or in contact with fabrics, the lens
can produce sufficient heat to melt some
fabrics. To avoid serious personal injury,
never allow the lens to come in contact with
anything.
■ Do not place the product or battery pack
near fire or heat. This will reduce the risk of
explosion and possible injury.
■ Remove the battery pack or disconnect the
mains power before starting any work on
the product.
■ Do not store the product in a damp or
wet location, or in a location where the
temperature may reach or exceed 40°C. For
example, inside sheds, vehicles, or metal
buildings in the summer.
■ Do not direct the light beam at persons or
animals and do not stare into the light beam
yourself (not even from a distance). Staring
into the light beam may result in serious
injury or vision loss.
■ Charge the product/battery indoors.
BATTERY SAFETY WARNINGS
■ To reduce the risk of fire, personal injury,
and product damage due to a short circuit,
never immerse your tool, battery pack or
charger in fluid or allow a fluid to flow inside
them. Corrosive or conductive fluids, such
as seawater, certain industrial chemicals,
and bleach or bleach-containing products,
etc., can cause a short circuit.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local
and national provisions and regulations.
Follow all special requirements on packaging
and labelling when transporting batteries by a
third party. Ensure that no batteries can come
in contact with other batteries or conductive
materials while in transport by protecting
exposed connectors with insulating, non-
conductive caps or tape. Do not transport
batteries that are cracked or leaking. Check with
the forwarding company for further advice.
MAINTENANCE
■ Use only original accessories and spare
parts. Should components need to be
replaced which have not been described,
please contact an authorised service centre.
All repairs should be performed by an
authorised service centre.
■ Avoid using solvents when cleaning plastic
parts. Most plastics are susceptible to
various types of commercial solvents and
may be damaged by their use. Use clean
cloths to remove dirt, carbon dust, etc.
■ Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils,
etc., come in contact with plastic parts.
Chemicals can damage, weaken or destroy
plastic which may result in serious personal
injury.
SYMBOLS ON THE PRODUCT
V
Volts
Direct current
The rated maximum ambient
temperature
Regulatory Compliance Mark
(RCM). Product meets applicable
regulatory requirements.
Please read the instructions
carefully before starting the
machine.
Class III protection
IP54
Ingress protection rating
Do not stare at light source.
Do not dispose of waste batteries,
waste electrical and electronic
equipment as unsorted municipal
waste.
Waste batteries and waste electrical
and electronic equipment must be
collected separately.
Waste batteries, waste
accumulators, and light sources
have to be removed from the
equipment.
Check with your local authority or
retailer for recycling advice and
collection point.
According to local regulations,
retailers may have an obligation
to take back waste batteries and
waste electrical and electronic
equipment free of charge.
Your contribution to the reuse and
recycling of waste batteries and
waste electrical and electronic
equipment helps to reduce the
demand of raw materials.
Waste batteries, in particular
containing lithium, and waste
electrical and electronic equipment
contain valuable and recyclable
materials, which can adversely
impact the environment and the
human health if not disposed of
in an environmentally compatible
manner.
Delete personal data from waste
equipment, if any.
SYMBOLS IN THIS MANUAL
Safety Alert
Note
Parts or accessories sold
separately
Charging time
PRODUCT SPECIFICATIONS
4V USB Lithium LED Flip Light
Model RFL4
Voltage 4 V
Wattage 6.5 W
Light output (Lumens)
High brightness level 500 Lum
Medium brightness level 200 Lum
Low brightness level 40 Lum
Colour rendering index (CRI) 80
Correlated colour temperature (CCT) 5000 K
Weight - excluding battery pack 0.17 kg
BATTERY
Compatible battery pack RB420
