To Connect A Tv To Your Notebook (Select Models Only) - Compaq Personal Computer Startup Manual

Basic Operation
To Connect a TV to Your Notebook
(Select Models Only)
You can use a TV as an external monitor for your notebook. To
connect a TV to your notebook:
1. Plug a standard 4-pin S-Video cable to the S-Video out jack
on your notebook (yellow connector on the back panel). Plug
the other end of the cable to the S-Video in jack on your
television.
✎
2. Select Start > Control Panel > Appearance and Themes >
Display. Then, select Settings tab > Advanced button >
Display tab.
3. To enable the TV, select the red button next to TV.
✎
4. Select Apply to accept the changes.
5. If you are prompted to restart Windows, select Yes.
2–8
Although your notebook has a 7-pin S-Video out jack, the
notebook accepts either a 7-pin or 4-pin cable connection.
If the S-Video cable is not plugged into your notebook and TV,
the red button will not be displayed.
Startup Guide
