Hyundai HOL292101 User Manual

Hyundai Standing tripod working light
HOL292101
INTRODUCTION
You are now the proud owner of the Hyundai Standing tripod work-
ing light! For best results study the manual carefully before using the
Hyundai Standing tripod working light. Please keep this manual handy
for ready reference.
To get the most out of your new Standing tripod working light, please
read these instructions in case you need to refer to them at a later date
INTENDED USE
The LED floodlight is intended for indoor and outdoor use. do not move
the product during use. the LED floodlight is not suitable for purposes
other than those described here.
SAFETY PRECAUTIONS
CAUTION! read all instructions. Failure to heed the following instruc-
tions may lead to electric shock,fire and/or sirious injury.safe this user
manual for future reference! Include this user manual should you give
the LED floodlight to other persons.
• The LED flootlight's housing may become very hor during use.
make sure the floodlight is sufficiently ventilated to promote the
dissipation of generated heat.
• touch the floodlight with your bare hands only when it s cooled
down.
• set up the floodlight with sufficient clearance to flammable
surfaces and objects.if you set up the floodlight near flammable
objects,keep a minimum dinstance of 1m (3.3ft) from the housing.
HOW TO USE
• The LED floodlight may be operated in combination with the
included floor stand only.
• Make sure that the connection cable is not taut or in contact with
sharp objects,chemicals or solvents.
• Check the products for damages before first use.
• Resolve any malfunctions and repair any damages immidiatelly to
guarantee safe operation.
• Interrupt the power supply before repairing the LED floodlight.
• The safety glass is non-replaceable. dispose of the product if the
safety glass is damaged.
• The floodlight may be set up on an even and stable surface only.
• Risk of electric schock! This product complies with protection type
IP65 and is protected against dust and low pressure jet-water
from all directions.Do not submergethe article in water.Keepa min-
imum distance of 5m (16 ft) from swimming pools of ponds.Shield
the power plug from moisture.
KEEP THIS INSTRUCTION MANUAL FOR REFERENCE AS
IT CONTAINS IMPORTANT INFORMATION.
NL / EN - support@alleenonline.nl
BE / FR - support@alleenonline.be
1.Safety glass
2.Terminal box
3.Fastebung Bolts (both sides)
4.Mounting bracket
5.Height lock ring
6.Lock latch
7.Legs
8.Connention cable with power plug
9.Connection cable camp
10.Mounting bracket screw with washer and nut
11.LED
12.Tripod
13.Crossbar with screw
SETUP
• Use the fastening bolts to set the desired beam angle:
• Before use. make sure the floodlight is standing securelly.
• Connect the power plug to a suitable power outlet to turn on the
device. unplug the device to turn it off.
CLEANING
Interrupt the power supply before repairing or cleaning the LED flood-
light.
Use a slightly damp cloth clean the LED floodlight's housing.Do not use
any aggressive cleaning agents.
Color: black/blue
Dimensions: 53.5cm(L)*6.2cm(W)*140cm(H)
Product weight: 3kg
Materials: Die-casting aluminum housing & steel tripod
Input voltage: 220-240V
Lumen: 90LM/W total 2*900lm
RF: ≥0.9
RA: 80
Beam angle: 120°
Operating temp.: -30 ~+45
Color temperature: 6000-6500K
LED: SMD2835*15
Water resistance: IP65
Cable: 1.8m 3*1.0 cable cord+EU Plug
