- Page 1 TIG/INS07 TIGER GARDEN PAVILION GENERAL ASSEMBLY INSTRUCTIONS...
-
Page 2: Before You Get Started
BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. - Page 3 Please retain instructions for future reference CAUTION: CAUTION: All buildings should be erected It is advisable to wear safety by three competent adults. gloves during building installation. Whilst all products manufactured are made to the highest standards of safety, we cannot accept responsibility for your safety whilst erecting or using this product.
-
Page 4: Tools Required
BEFORE YOU GET STARTED TOOLS REQUIRED We recommend using the following tools (not supplied): HAMMER RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW FIXING KIT CONTENTS: Clout Nails (20mm Galvanised - QTY CN20 Screws (70mm - QTY 48) 240) Screws... - Page 5 Please retain instructions for future reference BUILDING PACK CONTENTS: For full details of what should be included please see the Module Pack List that is supplied with the delivery. They are also available on request in pdf form from our helpful Customer Support team – please call 0113 205 4189 or use the Items Delivered Query form at tigersheds.com/contact.
- Page 6 TIGER GARDEN PAVILION GENERAL INSTRUCTIONS IMPORTANT: Customer to supply own fixings for type of ground. Posts 92mm square. NOTE - Make sure that customer supplied fixings are in place before building commences - For post layout. (Detail A) 2877 EXTERNAL...
- Page 7 Please retain instructions for future reference Step 1: ASSEMBLE UPRIGHT FRAMES (CHECK WHAT SIZE YOU HAVE AND THE MODULES SUPPLIED) • Layout upright posts and longer horizontal rails (2790 mm) as shown. (Detail B) • Secure together using 1x S70 per join. (Detail C) NOTE: DO NOT TIGHTEN FULLY.
-
Page 8: Assemble Frame
TIGER GARDEN PAVILION GENERAL INSTRUCTIONS Step 2: ASSEMBLE FRAME • Slot in shorter horizontal rails (2705mm) as shown. (Detail F) • Secure to upright post using 1x S70 per join. (Detail G) NOTE: DO NOT TIGHTEN FULLY. • Check frame is square by measuring between points. If measurements are the same, your frame is square. - Page 9 Step 4: FIXING TO BASE • Secure the garden pavilion to your desired IMPORTANT: base before fitting the roof. NOTE: TIGER SHEDS DOES NOT PROVIDE Customer to supply own fixings for type of ground. GROUND FIXINGS. Posts 92mm square. • Again, check frame is square.
- Page 10 TIGER GARDEN PAVILION GENERAL INSTRUCTIONS Step 5: ASSEMBLING ROOF PANELS • Fix 1x A & 1x B roof panels together using 2x S40 equally spaced per section. • For extra strength, we recommend securing through both sides of the framing of each panel.
- Page 11 Please retain instructions for future reference 3150 1335 PIECE 1 PIECE 2 FOR REFERENCE ONLY - NOT TO SCALE PIECE 2 PIECE 1 1335 3150 75mm PIECE 2 OVERLAP FOR REFERENCE ONLY - NOT TO SCALE PIECE 1 ROOF PANEL A ROOF PANEL B Step 7: INSTALLING ROOF PANELS...
- Page 12 TIGER GARDEN PAVILION GENERAL INSTRUCTIONS • For remaining roof panels, push acorn base upward, slightly loosening the roof and catch the new panel edge then lower to “lock in”. For order of panel installation. (Detail N) • Secure through acorn base using 2x S40 per joined roof panel.
- Page 13 Please retain instructions for future reference Step 8: ATTACHING ROOF SKIRTING • Secure skirting to bottom of roof panels using 4x S40 equally spaced per skirting. (Detail R) • Repeat for remaining roof panels. 4 roof sections in total.
- Page 14 TIGER GARDEN PAVILION GENERAL INSTRUCTIONS Step 9: FELTING THE ROOF (MEASURE AND CUT BEFORE INSTALLING THE FELT) • 9.1: Roll large angle cut felt piece along low side of roof (Piece 1) leaving sufficient overhang to fold down onto lower edge. Do not fold underneath roof.
- Page 15 Please retain instructions for future reference Step 10: INSTALLING PAVILION FEET • Secure the garden pavilion feet to outside of upright post using 2x S70 per foot, 2 feet per post. (Detail U) • Repeat for all remaining corners.
