Page 1: Instruction Manual
MA715 | MP3/MP4 Digital Audio/Video Player Instruction Manual... - Page 2 Thank you for purchasing our Digital Media Player. combines an MP3 Player, Video Player and removable Flash Memory drive all in one unit. You can move and store files between computers and enjoy your MP3 music collection anytime and anywhere. Plus, you can store and watch videos on this player ! (1) We have made every attempt to ensure the correctness and completeness of this manual, however mistakes and omission may still exist.
- Page 3 (1) Do not use this player when driving, riding or operating any other vehicles as it may lead to traffic accidents. (2) Keep your player clean. Do not place it near heat or subject to direct sunlight, dust, humidity or rain/moisture. (3) If the surface becomes dusty or dirty, clean it with a soft, slightly dampened cloth.
-
Page 4: System Requirements
256MB 244MB~256MB 512MB 488MB~512MB 953MB~1000MB 1907MB~2000MB System requirement of MP3 player: (1) Microsoft Windows98SE/2000/ME/XP (2) CPU series with Pentium 200MHZ or above (3) USB connector (4) 120MB hard disc capacity (5) CD-ROM driver Due to different firmware sizes, the amount of actual free memory will Free capacity range after stored firmware 73MB～127MB... -
Page 5: Function Overview
(1) Support formats such as MP3 WMA WAV SMV JPG BMP This product supports playback of MP3 files, photo browse and movie play with high quality. (2) Folder management Facilitate your music folder playback. (3) DRM 9 function This product supports WMA DRM 9 digital authorized music playback. (4) Receive and record FM radio This product can receive FM radio, which can also be recorded in MP3 format and saved or playback. -
Page 6: Get To Know Your Player
Button layout Earphone jack USB port Display area Button lock Rewind button Microphone Volume down button－ Play／pause button Volume up button＋ (10) Reset hole (11) Fast forward button (12) Power button (13) A-B repeat／record button 5. GET TO KNOW YOUR PLAYER... - Page 7 This product uses a built-in rechargeable Li-ion battery. This icon will be displayed at the upper left corner of the screen. The following pictures indicate the charging status of the battery: When the battery is charging, the icon will be changing from an empty battery to a full one to indicate the process.
-
Page 8: Using The Usb Connection
Connection and download Connection to PC Plug the attached USB cable to PC，and connect the other end to the MP3 player. If the connection is successful, the screen of player will display the following picture. 7. USING THE USB CONNECTION... - Page 9 MP3 music download When the connection is done, select the desired files and click the right key of the mouse and select “copy”. Double click to open the disc icon of player (i.e. “H”, the name of disc may differ) and then click the right key of the mouse and select “paste”. During the process of writing, the player may display the following picture.
- Page 10 Remove from USB port Double click the icon of safely remove hardware on the task column, and the relevant dialog box will be displayed. On the picture of safely remove hardware dialog box, select the item of “USB mass storage device” and click “stop” button. The screen will display “stop to Hardware Device” as below.
- Page 11 Click “OK” button. When the screen displays “Safe to Remove Hardware”, the player can be safely removed from PC.
- Page 12 Special reminder: Do not disconnect the USB cable when data is being transmitted between PC and the player, which may cause data loss or damage to the player. Disconnection should be done only when “device can now be safely removed from the system” is displayed; When USB is in operation, other buttons are locked and do not operate.
- Page 13 Main menu Music：Select music in the main menu, the device will enter music sub-menu. Photo：Select photo in the main menu, the device will enter photo sub-menu. Movie：Select movie in the main menu, the device will enter movie function. Voice：Select voice in the main menu, the device will enter voice play function. FM Radio：Select FM radio in the main menu, the device will enter FM radio function.
- Page 14 Selection and exit Long press play button menu. The uppermost menu is main menu, which includes: music mode, photo mode, movie mode, voice mode, FM radio mode, record mode, delete mode, setting mode, about and exit. Select next or previous item by pressing fast forward button the main menu is in music picture, press rewind button if the main menu is in information page, press fast forward button picture.
- Page 15 Power off player When the player is powered off, the following modes will be saved, which includes: current mode, music elapse time, user setting. (i.e. volume, EQ, timing off and play mode etc.) If the player is powered off normally (i.e. user shut it off or it is shut off according to the setting), the above-mentioned modes will be saved.
-
Page 16: Using The Player
Music play function Press rewind button or fast forward button play button to enter the sub-menu of Music Play All or Internal Device. Operation instruction: When the music is stopped or played, press rewind button select previous or next file. When playing the music, long press rewind button fast backward or forward within the track. - Page 17 Press A-B/REC button to set the start point of repeat section A-B, the screen display ， press that button again to set the end of repeat section A-B, the screen will display A B and start repeating section AB. Press A-B/REC button for the third time to cancel section AB repeat function.
- Page 18 Single music play der play Playing songs in folders and playing under root directory Play mode Under root directory Normal Play all the songs under root directory and in folders one time and then stop. Repeat one Repeat play the current song. Repeat all Repeat play all the songs under root directory and in folders.
- Page 19 Random Repeat play all the songs under root directory and in folders. Rand.&Rep. Shuffle repeat play all the songs under root directory and in folders. Photo Press rewind button or fast forward button play button to enter the sub menu of Photo : Manual， Slide Show and Thumbnail. This player supports pictures in JPG and BMP formats.
- Page 20 Manual browse After entering photo function, press rewind button browse and press rewind button Slide show After entering photo function, press rewind button and press rewind button or fast forward button or fast forward button or fast forward button or fast forward button to browse the photo automatically.
- Page 21 Thumbnail After entering photo function, press rewind button thumbnail display and press play button Movie Press rewind button or fast forward button play button to enter Movie play. This player supports the playing of movie files in SMV format. Convert the desired movie （...
- Page 22 When the movie is playing, long press volume up button + or volume down buton – to adjust the volume. Select video2smv and double click it to enter the folder as indicates in the following figure:...
- Page 23 Select and double click video2smv.exe program to enter as indicates in the following figure: c. Click INPUT to select the files that need to be converted. You can set the screen resolution and display dimension at the same time, the higher the resolution, the more space the finished converted files will occupy and vice versa.
- Page 24 e. When there is black dot appears within the bracket before END, it means the conversion is finished. Click Quit to exit. Your can play movie on the player directly now.
- Page 25 Voice Press rewind button or fast forward button press play button to enter that voice play function. The following functions are provided in voice mode: Play FM record Play microphone record Support record files in WAV format Operation instruction: When in voice standby or play mode, press rewind button select the previous or next voice file.
- Page 26 Radio Press rewind button or fast forward button press play button to enter FM Radio play function. Up to 20 radio stations can be stored in the radio. 2 radio bands: US-EU band （87~108MHz） ，Japan band （76~91MHz） ，which can be set in setting menu.
- Page 27 FM radio Press play button A-B/REC to switch radio station from CH01 the radio station, the player will save the current frequency to the current station number before skip to the next station. Press rewind button backward by 0.1MHz. Long press rewind button the strongest signal forward or backward.
- Page 28 FM record Long press A-B/REC button to start FM record. At this moment, the player will display the picture of FM record and record icon. The recorded content is FM program but not microphone. The flashing record status icon moment, press play button record pause.
- Page 29 Record Press rewind button and press play button microphone record function when the player is in any state other than FM radio. The flashing record state icon play button pause. Press play button to stop microphone record. When the microphone record stops, the interface will be changed to voice play function.
- Page 30 ７ record sampling rates: user can set the sampling rate of record file. The higher the sampling rate, the better record quality will gain. The lower the sampling rate, the more common quality will gain with longer record duration. There are total 7 sampling rate available: 8KHz, 11KHz, 16KHz, 22KHz, 32KHz, 44KHz and 48KHz.
- Page 31 Delete Press rewind button press play button Delete one Press rewind button press play button button to quite the deletion and return to the main menu. Delete all Press rewind button player. Press play button WMA） ， voice files （ WAV） and movie files （ SMV） in the player will be deleted. But personal file and photo will not be deleted, which can be deleted one by one.
- Page 32 Settings Press rewind button press play button play mode setting, record format setting, FM band setting, FM auto scan setting, contrast setting, timing off setting and resume default value setting. Language Press rewind button or fast forward button press play button to confirm.
- Page 33 Press rewind button or fast forward button in EQ setting menu to select EQ and press play button to confirm. Long press play button or press power button to skip this setting. When playing music, the change of EQ can be felt in the earphone. EQ of this player includes: Normal，Rock，Jazz，Classical，Pop，Ultra Bass，Blues，Club，Dance，Full Bass and Treble，...
- Page 34 Play mode Press rewind button or fast forward button in play mode setting menu to select play mode and press play button to confirm. Long press play button or press power button skip this setting. The play mode of this player includes: normal, repeat one, repeat all, random and random &...
- Page 35 FM band Press rewind button or fast forward button press play button to confirm. Long press play button this setting. FM band includes: US-EU band and Japan band. FM auto scan Select “YES” to start FM auto scan, while select “NO” to return to the setting menu. Contrast Press rewind button or fast forward button...
- Page 36 Timer off Press rewind button or fast forward button press play button to confirm. Long press play button this setting. The sub menus of timing off are: stop off, sleep off and backlight off. Stop off: Disable, 15 SEC, 30 SEC, 1 MIN, 2 MIN, 5 MIN, 10 MIN and 30 MIN. Sleep off: Disable, 10 MIN, 15 MIN, 30 MIN, 60 MIN, 90 MIN, 2 HR and 3 HR.
- Page 37 Reset Select “YES” to return to default setting, while select “NO” to return to the setting menu. About Press rewind button or fast forward button in the main menu to select About and press play button to enter About. You can check the total memory capacity, occupied space and version of the software.
-
Page 38: Other Functions
A-B play mode In music or voice play mode: Press A-B/REC button to set the starting point of repeat section A-B, and the play mode icon A will be displayed. Press A-B/REC button again to set the finishing point of repeat section A-B, and the play mode icon A Press A-B/REC button for the third time to cancel the repeating of AB and the icon will return to play mode. - Page 39 On Window 98SE / Window ME / Windows 2K / Windows XP, music with DRM should be transferred by Windows Media Player version 9.0 or 10.0 (Version 10.0 is for Windows XP only) to mp3 player. Other download operations will cause the player to be unable to read/play DRM files.
- Page 40 A. Connect player to PC. B. Choose the desired WMA music with DRM.
- Page 41 C. Click Right button of the mouse and choose “Add to Sync list”. D. On the open window, choose “Sync” option.
- Page 42 E. On “Sync” window, choose the desired WMA music with DRM as step B and choose “Removable Disk”.
- Page 43 F. Click “Start Sync“ to transfer the WMA music with DRM to player.
-
Page 44: Troubleshooting
If there is no picture displayed after the player is connected to PC and the unit does not work as storage disc or cannot be powered on after the battery is fully charged, please refer to the following steps to update the software in the player. Download the most updated software from the included CD (if any) or from the website and run the setup.exe files in the folder to complete the installation. -
Page 45: Specifications
Technical MP3 bit rate Specifications Photo format Sampling rate Record format Record duration Signal to noise Dynamic scope Distortion Output power Storage condition Working environment Capacity □128MB □256MB 12. SPECIFICATIONS 32~320Kbps Music format JPG、 BMP Movie format 8/11/16/22/32/44/48KHz Frequency response Dynamic current 9 hours（...
