Chapter 2: Quick Start Guide
If the Xilinx EDK Platform Studio included in this kit is to be installed, the user must obtain
a 16-Digit Registration ID. To obtain this 16-Digit Registration, register this software on the
Xilinx Software Registration web site. Locate the product ID on the Software assembly
DVD holder on the ISE WebPACK Product ID sticker. Enter the ISE WebPACK Product ID
on the Xilinx Software registration web site at http://www.xilinx.com/swreg.htm.
As part of this registration process the user will be sent a message by email from Xilinx
containing the 16-Digit Registration ID that will use during the ISE WebPACK installation
steps. After the 16-Digit Registration ID has been received, insert the ISE WebPACK DVD
and follow the installation instructions.
If any problems are encountered, contact Xilinx Support at
http://www.xilinx.com/support/mysupport.htm.

Step 3

Verify that the Spartan-3A DSP 1800A Development Board is Functional

Review the Spartan3A DSP 1800A Board User Guide found at
http://www.xilinx.com/s3adspmb. This user guide will provide more information on the
default settings and position of the jumpers.
Software Prerequisites
The software used to test this reference design is:
•
•
•
Note: ISE and EDK latest Service Packs are available at
http://www.xilinx.com/support/download/index.htm.
Hardware Prerequisites
The hardware setup used by this reference design includes:
•
•
•

Hardware Setup

1.
2.
3.
4.
5.
6.
8
Windows XP 32-bit
Xilinx ISE software, version 9.2i with Service Pack 4
Xilinx EDK software, version 9.2i with Service Pack 2
Xilinx Spartan-3A DSP 1800A Starter Platform
Xilinx Parallel Cable IV (PC4) or Platform Cable USB with flyleads
Serial Cable
Install JP9 jumper on M1 and M2 to configure in SPI mode.
JP1, JP2, and JP3 jumpers can be installed in either position.
Install two jumpers each in the 1:3, 2:4 positions of JP4, JP5, JP6, and JP10.
Install a jumper on JP11 in the OFF position.
JP8 must NOT have a jumper, as this is the write enable for the serial flash.
All other jumpers are NOT installed.
www.xilinx.com Getting Started SP-3A DSP S3D1800A
UG485 (v1.0) January 28, 2008
