NETGEAR ProSafe GS724TP Datasheet

Full-featured, flexible Power
over Ethernet (PoE)

Advanced Security

Advanced Quality of Service

/
24 7
T E C H N I C A L
S U P P O R T*
1-888-NETGEAR (638-4327)
Email: info@NETGEAR.com
ProSafe™ 24 and 48-Port 10/100/1000
Smart PoE Switch
GS724TP and GS748TP
Full 24-port or 48-port PoE Solution Plus Easy Browser-based Management
NETGEAR ProSafe Smart Switches fill the gap between unmanaged and fully managed switches.
The family of ProSafe Smart Switches is designed for growing businesses that want control over
their network without the cost and complexity of a full Layer 2 management implementation.
These PoE capable Smart Switches, the GS724TP and GS748TP , provide power and data
using built-in IEEE 802.3af PoE on all 24 or 48 ports. In addition, they offer an intuitive web-
based management tool for quick and easy deployment and configuration making it ideal for
deploying access points, VoIP phones and IP-based surveillance cameras. This switch is equipped
with highly advanced features such as Access Control Lists (ACL), 802.1x port authentication,
enhanced QoS, rate limiting and IGMP Snooping among others to provide a small and
medium-sized business with a network that is geared for growth while providing scalability
and reliability. With the utility of 24 or 48 10/100/1000 Mbps ports, two or four combination
(Copper/hot-swappable Small Form-factor Pluggable (SFP)) Gigabit ports for optional fiber
connectivity, growing business networks, classrooms and workgroups can benefit from superior
performance and keep up with expanding network needs. These high performing switches
feature a nonblocking wire-speed architecture with a 48 Gbps or 96 Gbps switching capacity for
maximum data throughput.
All 24 and 48 RJ-45 ports automatically negotiate to the highest speed and support Auto
Uplink™ technology to make the right link.
With a total power budget of 192 Watts for the GS724TP and 384 Watts for the GS748TP ,
customers can choose to plug in up to 48 802.3af IP-based devices. Power-over-Ethernet (PoE),
optimizes the installation and power management of network devices such as wireless access
points (AP), Voice over IP (VoIP) phones, and IP-based surveillance cameras. Power-over-Ethernet
(IEEE 802.3af) capabilities reduce installation time and costs for many new network productivity
devices. Free your wireless AP deployments and IP cameras from the restrictions of power outlet
proximity using a standard CAT-5 cable. Enable uninterruptible power supply for all your PoE
devices by powering your switch from a UPS device.
These switches also provide advanced features that provide more robust security to the SMBs.
These include:
• 802.1x for authentication
• ACL filtering to permit or deny traffic based on MAC or IP addresses.
Priority queuing ensures high-priority traffic gets delivered efficiently, even during congestion
from high traffic bursts. Companies implementing network telephony or video conferencing,
for example, need to be able to prioritize such voice and video traffic and other real-time
applications over less latency-sensitive traffic to ensure reliability and quality. The ability to
prioritize traffic ensures quality of latency-sensitive services and applications despite increasing
traffic loads. The ProSafe GS724TP and GS748TP provide several advanced QoS features:
• 802.1p based prioritization
• Layer 3-based (DSCP) prioritization
• Rate-limiting
Data Sheet
