Summary of Contents for Corsair RGB ELITE H60x
- Page 1 H60x | H100x RGB ELITE PERFORMANCE RGB LIQUID CPU COOLER 简体中文 ENGLISH ITALIANO اﻟﻌﺮﺑﻴﺔ FRANÇAIS (EURO) ESPAÑOL (EURO) DEUTSCH PORTUGUÊS (EURO) POLSKI NEDERLANDS...
- Page 2 ENGLISH TABLE OF CONTENTS INTEL (All Sockets) AMD AM5/AM4 FINISHING UP YOUR INSTALLATION Note: Most newer PC cases include a CPU cut-out to allow access to the bottom of the motherboard. If your case does not include a cut-out, you will need to remove your motherboard from the case prior to installation.
-
Page 3: Included Hardware
ENGLISH ENGLISH INCLUDED HARDWARE Highlighted parts for Intel installation only x4 INTEL 1200/1156/1155/1151/1150 x4 INTEL 2066/2011-3/2011 STANDOFFS x4 INTEL 1700 STANDOFFS STANDOFFS x1 INTEL BACKPLATE x1 INTEL MOUNTING BRACKET x4 THUMB NUTS (1200/115X/1700 ONLY) (PRE-INSTALLED) x4 AMD AM5/AM4 STANDOFFS x1 AMD AM5/AM4 MOUNTING BRACKET ARGB CABLE Y-SPLITTER x4 LONG FAN SCREWS (H60x) - Page 4 ENGLISH 1. INSTALLING THE INTEL BACKPLATE Adjust backplate for your required socket. NOTE: Intel LGA 2066/2011-3/2011 do not require backplate installation. Proceed to step 2. 2. INSTALLING THE INTEL STANDOFF SCREWS > Attach the provided Intel standoff for your socket. LGA 1200/1150/ 1151/1155/1156 >...
- Page 5 ENGLISH 3. INSTALL THE FANS AND RADIATOR Attach the radiator and the fans as shown. For the best cooling performance, we recommend mounting the fans as an air-intake to your PC case. 4. INSTALLING THE PUMP UNIT > Align the bracket and pump over the standoff screws as shown.
- Page 6 ENGLISH INCLUDED HARDWARE Highlighted parts for AMD AM5/AM4 installation only x4 INTEL 1200/1156/1155/1151/1150 x4 INTEL 2066/2011-3/2011 STANDOFFS x4 INTEL 1700 STANDOFFS STANDOFFS x1 INTEL BACKPLATE x1 INTEL MOUNTING BRACKET x4 THUMB NUTS (1200/115X/1700 ONLY) (PRE-INSTALLED) x4 AMD AM5/AM4 STANDOFFS x1 AMD AM5/AM4 MOUNTING BRACKET ARGB CABLE Y-SPLITTER x4 LONG FAN SCREWS (H60x)
- Page 7 ENGLISH 1. INSTALLING THE AMD AM5/AM4 MOUNTING BRACKET > Remove the integrated Intel mounting bracket (Figure 1). > Install the AMD AM5/AM4 bracket by pushing both sides into the slot on the pump until secure (Figure 2). Note: It is important that the AMD AM5/AM4 retention bracket be evenly secured on all sides before installation.
- Page 8 ENGLISH 4. INSTALLING THE AMD AM5/AM4 STANDOFF SCREWS > Attach the provided AMD AM5/AM4 standoffs to the CPU socket. > Tighten all four screws until firmly secure. 5. INSTALLING THE PUMP UNIT Align the bracket with the AMD AM5/AM4 standoffs as shown. Tighten the thumb nuts (F) until secure.
- Page 9 ENGLISH CONNECT PUMP AND FANS TO MOTHERBOARD > Connect pump tach cable to the CPU_FAN header on your motherboard (Figure 1). > Connect each fan to the Y-splitter cable (J) then plug the Y-splitter cable into a 4-pin header on your motherboard.
- Page 10 Please double check all connections between the cooler and fans. Ensure that the cooler is updated to the most recent firmware via iCUE. If this does not resolve your problems, please open a support ticket at support.corsair.com or contact our customer support team for further troubleshooting and assistance.
