Creating a VPN Policy for the FVX538 or FVS338

ProSafe® VPN Firewall with a Remote Endpoint of

0.0.0.0

Summary

This application note describes how to configure a VPN policy to support a remote

gateway IP set to 0.0.0.0.on one WAN interface of a NETGEAR FVX538 or FVS338

ProSafe VPN Firewall. This is an updated version using the version 2.x router firmware.

Procedure

This application note describes how to create a VPN Client policy using the VPN Wizard

and then editing that policy to set a remote endpoint of 0.0.0.0. It also describes how to

set the remote endpoint to 0.0.0.0. for VPN policies that were manually created.

This procedure was tested using the following:

• NETGEAR FVX538 ProSafe VPN Firewall with version V 2.x firmware

o IP address subnet: 192.168.1.1; 255.255.255.0

Using the VPN Wizard to Create a VPN Policy

1. From the

VPN menu, select the VPN Wizard submenu.

Select the VPN client radio button.

3. Type the connection name and preshared key.

4. Click Apply.

Application Note

Page 1 This application note describes how to configure a VPN policy to support a remote gateway IP set to 0.0.0.0.on one WAN interface of a NETGEAR FVX538 or FVS338 ProSafe VPN Firewall. This is an updated version using the version 2.x router firmware.
Page 2 V e r if yi n g t h e IK E a n d V PN p o l ic y 1. From the VPN menu, select Policies. 2. Select the VPN Policies tab to verify that the VPN policy is in the list. 3.
Page 3 M od i f yi n g t he R e m ot e E nd po int A dd res s 1. From the VPN menu, select the Policies submenu. 2. Select the VPN Policies tab, and click Edit for the VPN policy you created (in this example conn1)..
Page 4 Setting the Remote Endpoint Address for a Manually Created VPN Policy After you manually add an IKE and VPN policy, you can manually set the remote endpoint address. To manually set the remote endpoint address: 1. From the VPN menu, select the Policies submenu. 2.
