REFRIGERATOR FOR LP-GAS AND ELECTRIC OPERATION
RM 2352 RM 2353
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don’t touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage. Refer to this
manual. For assistance or additional
information consult a qualified
installer, service agency or the gas
supplier.
All manuals and user guides at all-guides.com
INSTALLATION AND
®
OPERATING INSTRUCTIONS
AVIS
Cet appareil doit être réparé
seulement par un réparateur
autorisé. Modification de
l’appareil pourrait être
extrèmement dangeruse, et
pourrait causer mal ou mort.
®

Advertisement

Table of Contents
loading

Related Manuals for Dometic RM 2352

Summary of Contents for Dometic RM 2352

  • Page 1 All manuals and user guides at all-guides.com INSTALLATION AND ® OPERATING INSTRUCTIONS REFRIGERATOR FOR LP-GAS AND ELECTRIC OPERATION RM 2352 RM 2353 FOR YOUR SAFETY If you smell gas: 1. Open windows. 2. Don’t touch electrical switches. 3. Extinguish any open flame.
  • Page 2 All manuals and user guides at all-guides.com...
  • Page 3 All manuals and user guides at all-guides.com Heater(s) Flue baffle 12 volt terminal block, Protection cover 3-Way only Manual gas Inlet fitting Screw for burner cover shutoff valve Burner jet Flexible cord Refrigerator control panel LEGEND...

  • Page 4: General Instruction

    All manuals and user guides at all-guides.com INSTALLATION GENERAL INSTRUCTION CERTIFIED INSTALLATION “Certified Vent System Kits” METHODS OF INSTALLATION Condenser Minimum ventilation height VENTILATION Minimum ventilation height Condenser “Certified Vent System Kits”...

  • Page 5: Ventilation Heights

    All manuals and user guides at all-guides.com VENTILATION HEIGHTS Refrigerator Minimum ventilation heights in inches and mm. model installation with Installation with roof RM 2352 upper and lower vent and lower side RM 2353 side vent vent inch CLEARANCES Overall...

  • Page 6: Gas Connection

    All manuals and user guides at all-guides.com INSTALLING REFRIGERATOR IN ENCLOSURE GAS CONNECTION ! WARNING Securing the Refrigerator...

  • Page 7: Testing Lp Gas Safety Shutoff

    All manuals and user guides at all-guides.com TESTING LP GAS SAFETY SHUTOFF 12 Volts DC Connection 3-way refrigerator model RM2353 3-way 25.0 ft. 7.6 m 40.0 ft. 12.2 m ELECTRICAL CONNECTION 120 Volts AC Connection ! CAUTION Breaker Ignition Switch key point coil 120 Volt AC...
  • Page 8 CHANGING DOOR SWING TO OPPOSITE PANEL DIMENSIONS SIDE MAX. THICKNESS 5/32" (4 mm) REFR.MODELS HEIGHT WIDTH TYPE MAX. MIN. MAX. MIN. INSTRUCTIONS FOR MOUNTING THE RM 2352 inch 25-9/32 25-3/16 19-5/8 19-17/32 RM 2353 DOOR PANEL • • • CERTIFIED VENT SYSTEM KITS...

  • Page 9: Importance Of Leveling Arefrigerator

    All manuals and user guides at all-guides.com OPERATING INSTRUCTIONS OFF/ON PUSH WHEN LIGHTING OFF/ON PUSH WHEN LIGHTING IMPORTANCE OF LEVELING A REFRIGERATOR ! WARNING GAS OPERATION...

  • Page 10: How To Use The Refrigerator

    All manuals and user guides at all-guides.com ELECTRIC OPERATION THERMOSTAT DEFROSTING HOW TO USE THE REFRIGERATOR ! CAUTION FOOD STORAGE COMPARTMENT CLEANING THE REFRIGERATOR FROZEN FOOD STORAGE COMPARTMENT...

  • Page 11: Maintenance And Service

    All manuals and user guides at all-guides.com SHUT- OFF (STORAGE PROCEDURE) ! WARNING see Item 2. Refrigerator Removal. 2. REFRIGERATOR REMOVAL MAINTENANCE & SERVICE 1. CARTRIDGE HEATER 3. PERIODIC MAINTENANCE see Item 2. Refrigerator Removal GAS EQUIPMENT ASSEMBLY MANUAL SHUT OFF VALVE Shown in open position Use a quarter dollar or a slotted screwdriver to change position INLET FITTING...

  • Page 12: Troubleshooting

    All manuals and user guides at all-guides.com ! WARNING ! WARNING 4. TROUBLESHOOTING Refrigerator Does Not Cool Properly...

  • Page 13: Spare Parts

    All manuals and user guides at all-guides.com SPARE PARTS...
  • Page 14 All manuals and user guides at all-guides.com Removing and replacing of shelves (General) The number of shelves and position may vary between refrigerator models.
  • Page 15 All manuals and user guides at all-guides.com RM 2352 293 31 29 GROUND 120 VOLTS AC ADAPTER THERMO- COUPLE INDICATOR 120 VOLTS AC BLACK WHITE YELLOW/GREEN GREEN BLUE HEATER 120V AC SWITCH THERMOSTAT RM 2353 293 31 30 12 VOLTS DC...
  • Page 16 All manuals and user guides at all-guides.com...
