.44 [11.1]
n
1.24 [31.5]
n
1.093-32 UN -2A
M25x.75T
n
1.44 [36.5]
5-PHASE MOTOR PINOUT
PIN 3 = +5Vdc
PIN13 = COMMON
PIN 8 = FAR LIMIT
PIN 12 = NEAR LIMIT
PIN 15 = MOTOR 1
PIN 5 = MOTOR 2
PIN 10 = MOTOR 3
PIN 4 = MOTOR 4
PIN 14 = MOTOR 5
15 PIN HIGH DENSITY
3.83 [97.3]
.80 [20.3]
4.96 [125.9]
4.08 [103.5]
11/16-32 UN - 2B
D-SUB
.38 [9.5]
.75 [19.1]
(4) x
4-40 UNC - 2B
.32 [8.3]
.72 [18.4]
n
1.60 [40.6]
+
.000
n
1.312
- .001
USED ON:
MATERIAL:
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES
-2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX
.005
FINISH:
`
DR.:
DEC. .XX
.010
`
FRACT.
1/64
CH.:
ANGLES
`
30'
APP.:
CONCENTRICITY
.003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
CHAMFER ALL THREADS
MAX. SURF. ROUGHNESS
32
DO NOT SCALE DRAWING
~
30
TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
2.99 [76.0]
2.19 [55.7]
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (5PH) 6X ULTRA w/2
R. PODLENA
0.0
inch
1.0
POS LS (HE), MANUAL 3mm FF &
P. BONAFEDE
SIZE
0.0
mm
25.0
9/10/2003
B
1.05 [26.8]
2.02 [51.3]
OUTLINE
COAX PORT
1-62645
REV
A
SHEET
1
OF
1
