- Page 1 Navitar 10K High Intensity Slide Projector NAVITAR, Inc., 200 Commerce Drive, Rochester, New York 14623 USA Phone (585) 359-4000 Fax (585) 359-4999 Internet navitar.com E-mail info@navitar.com...
-
Page 2: Table Of Contents
Table of Contents Warning ... 3 Introduction ... 4 System Diagrams ... 5 Available Models ... 6 Operation ... 7 Maintenance and Care ... 8 Projection Lenses ... 9 Slide Tray Use ... 10 Display Functions ... 11 Installing a New Lamp ... 14 Slide Recommendations ... -
Page 3: Warning
CAUSE SEVERE DAMAGE TO THE RETINA. AVOID LOOKING DIRECTLY INTO THE LIGHT BEAM. ALWAYS ALLOW THE LAMP TO COOL COMPLETELY BEFORE HANDLING. When disposing of HTI-lamps, handle with care to prevent injury. If you have any questions, please call Navitar at 1-800-828-6778. -
Page 4: Introduction
It provides full RS-232 operation, random slide access compatibility, and enhanced corner illumination. The 10K is available in a standard model or a dissolve model with either AVL or Dataton compatibility. Usage, Building and Functional Principles Navitar’s SUPERNOVA 10K is a very strong projector which can project 10 to 20... -
Page 5: System Diagrams
System Diagrams Front View Tray Adjustment Nose for Tray Lens Adjustable Leg Rear View Buttons RS-232 Input Remote Control Power Connection Slot for Modules Projector Body Adjustable Leg Adjustable Leg Tray Adjustment Nose for Tray LEDs... -
Page 6: Available Models
Available Models Navitar SUPERNOVA 10K Available Models In order to meet all requirements of the professional market, the SUPERNOVA 10K is available in two different versions. SUPERNOVA 10K Digital This projector can be used for single projections or faded projections. When using a fading-control-unit the SUPERNOVA 10K automatically recognizes the type of control-unit used and the fading results are optimized electronically. -
Page 7: Operation
ATTENTION: The 10K uses a metal halide lamp requiring a minimum burning time of at least 5 minutes. If you do not observe the minimum burning time the life-duration of the lamp will be considerably shortened. A general advice is to ignite the lamp only when necessary to guarantee a long life-duration for your lamp. -
Page 8: Maintenance And Care
It is used to take in air for proper ventilation. Depending on the dust and dirt found in your projection environment, the air filter might get clogged. The Navitar 10K uses a filter fleece in the air filter, which can be easily vacuumed from the outside. -
Page 9: Projection Lenses
Available Navitar Slide Projection Lenses The SUPERNOVA 10K is equipped with a lens changing system. This enables the user to change to a different focal length lens within a few seconds. Navitar recom- mends the following projection lenses for the SUPERNOVA 10K:... -
Page 10: Slide Tray Use
(i.e. in the zero position). No Slide / No Light The SUPERNOVA 10K has a built-in detector which recognizes when a slide is in the gate and then allows the projection light to pass through the slide. If there is... -
Page 11: Display Functions
Display Functions Display Functions On Button When you plug-in the SUPERNOVA 10K the LED for stand-by will light up. After pressing the On-button, the lamp will ignite and the whole unit will start to operate. Off Button When you press the off-button, the lamp will turn off and the cooling period will start. - Page 12 LED. Remote Control Connector Timer The SUPERNOVA 10K has a timer included to forward the slides. It is program- mable between 2 and 99 seconds. Programming the Interval Between the Slides Press the timer button for at least 2 seconds and hold it for the desired interval (the red LED flashes for every second, for example, 8 flashes equals 8 sec- onds).
- Page 13 If you do experience a slide jam, please remove the slide from the gate and press the reset button. This avoids having to restart the whole unit, including lamp ignition.
-
Page 14: Installing A New Lamp
Change the lamp as follows: before starting to change the lamp. 1. UNPLUG THE PROJECTOR! 2 Open the screw at the lamp-door and remove the lamp-door. 3. Now you can see the lamp module. You will see two screws, one on the... - Page 15 COOL before handling. Be sure to check that the lamp and the projector are not warm to the touch before starting to change the lamp. 5. You can see the lamp in its socket. To remove the lamp you must remove the safety guard first.
- Page 16 (see below). Lamp Adjustment The socket for the lamp module in the SUPERNOVA 10K projector is secured at three points so that the lamp can be adjusted in every direction. 1. Ignite the lamp and insert an empty slide (no picture) in the slot. The lighter side of the frame must face the lamp.
-
Page 17: Slide Recommendations
Slide Recommendations Slide Mounts For the high-performance SUPERNOVA 10K projector, we recommend special high-performance slide mounts, such as the AHX-slide mounts from Wess. This slide mount provides optimal cooling, simple handling, and great performance. It is specifically made so a slide can safely be projected over a long period of time without damage. -
Page 18: Rs-232 Specifications
RS-232 Specifications Configuration of the Terminal To control the SUPERNOVA 10K by serial protocol, connect a 1:1 RS-232 cable to the projector and adjust the configuration of the terminal to: Baud 9600 8N2 Xon/Xoff 8 databits no parity 2 Stopbits... -
Page 19: Warranty
If during the warranty period the product is found to be defective, it will be repaired or replaced at the facilities of Navitar. However, Navitar reserves the right to refund the purchase price if the replacement or repair is not commercially practical or timely. - Page 20 RETINA. AVOID LOOKING DIRECTLY INTO THE LIGHT BEAM. ALWAYS ALLOW THE LAMP TO COOL COMPLETELY BEFORE HANDLING. When disposing of HTI-lamps, handle with care to prevent injury. If you have any questions, please call Navitar at 1-800-828-6778. NAVITAR, Inc. 200 Commerce Drive Rochester, NY 14623 USA...
