Model:
: MTV085ICER
: MTV095ICER
: MTV110ICER
: MTV120ICER
SERVICE MANUAL
Specifications ------------------------1
Circuit Diagram-----------------------4
Refrigerant Circuit-------------------7
Replacement of Parts---------------8
Trouble shooting---------------------18
Contents
Advertisement
Related Manuals for mabe MTV085ICER
Summary of Contents for mabe MTV085ICER
-
Page 1: Table Of Contents
SERVICE MANUAL Model: : MTV085ICER : MTV095ICER : MTV110ICER : MTV120ICER Contents Specifications ------------------------1 Circuit Diagram-----------------------4 Refrigerant Circuit-------------------7 Replacement of Parts---------------8 Trouble shooting---------------------18... -
Page 2: Specifications
P a g e SERVICE MANUAL Refrigerator Specifications 1-1) Specific parts for specific countries Item Power Source Model Destination Power Cord (Voltage-ac / Hz) MTV085ICER Philippines(PH) 220 / 50 MTV095ICER Philippines(PH) 220 / 50 MTV110ICER Philippines(PH) 220 / 50 MTV120ICER Philippines(PH) 220 / 50 PRINTED : May’2015... - Page 3 B60-120/ QP3-12A J Starting relay QP3-12A J Electrical data Resistance(25°C) :9~19Ω Max. working voltage : 350V Max. working current : 8A Defrost heater Model Electrical data 120W 220V R: 100MΩ (MTV085ICER,MTV095ICER) 130W 220V R: 100MΩ (MTV110ICER,MTV120ICER) PRINTED : May’2015 REF NO. SM7715029-00-11...
- Page 4 P a g e 1-3) Electrical Parts Freezer Fan motor Model FD-F6110A-5059 Electrical data Rated Current: 0.048±15%,(AT 25°C) Input Rated Power: 7.1±15%,(AT 25°C) Thermal fuse Model SF76E Electrical data 10A 250V cut-off temperature 77 C BIMETAL THERMO Model ‐ Cut off temp: 11±3°C Electrical data Cut in temp: 2±4°C Door switch...
-
Page 5: 2-1 Circuit Diagram
P a g e Circuit Diagram Model: MTV085ICER, MTV095ICER, MTV110ICER, MTV120ICER (Fix speed compressor) 2-1 Circuit Diagram PRINTED : May’2015 REF NO. SM7715029-00-11... - Page 6 P a g e 2-2 Reference wiring diagram PRINTED : May’2015 REF NO. SM7715029-00-11...
- Page 7 P a g e 2.3 Rating plate Model : MTV085ICER Total Volume : 242 L , 8.5(Cu.ft) Voltage : 220 V Frequency : 50 Hz Current : 1.2 A Power Input : 135 W Defrosting Input : 120 W Refrigerant R600 A : 41 g...
-
Page 8: Refrigerant Circuit
P a g e Refrigerant Circuit PRINTED : May’2015 REF NO. SM7715029-00-11... -
Page 9: Replacement Of Parts
P a g e Replacement of Parts • Unplug the power cord before servicing. Part Name Operating Procedure Frz Fan Blade. 1. Remove Ice Storage Box. 2. Remove Ice Cube Tray Assy. 3. Remove Shelf F. 4. Dig Cover Cap out. Release screws at FF Cover 6.Lift Cover and Fan Cover out. - Page 10 P a g e Part Name Operating Procedure Fan Motor. - Follow step 1-10 of replacing Fan Blade. 1. Lift Plate MTG Motor out. 2. Take out socket of Fan Motor. 3. Release screw at Cover A. 4. Pull Cover A from Plate MTG Motor. 5.
- Page 11 P a g e Part Name Operating Procedure Bimetal Thermo. Follow step 1-10 of replacing Fan Blade. Follow step 1-2 of replacing Fan Motor. 1. Take out socket of Bimetal Thermo. 2. Cut out Cable Tie from Evaporator 3. Pull Bimetal Thermo from tube.
- Page 12 P a g e Part Name Operating Procedure Glass Tube Heater. Follow step 1-10 of replacing Fan Blade. Follow step 1-2 of replacing Fan Motor. 1. Take out socket of Glass Tube Heater. 2. Take out socket of Glass Tube 3.
- Page 13 P a g e Part Name Operating Procedure LAMP. 1. Pull out Chiller. 2. Remove all Glass Shelf. 3. Remove Lamp Cover . 4. Remove lamp. 5. After replacing lamp, reverse the steps above. PRINTED : May’2015 REF NO. SM7715029-00-11...
- Page 14 P a g e Part Name Operating Procedure Thermostat. Follow step 1-5 of replacing Lamp. 1. Release screws at Multi Duct Ass’y. 2. Turn Thermo Knob R to “left 3. Pull out Thermo Knob R from Multi ” position. Duct Ass’y. 4.
- Page 15 P a g e Part Name Operating Procedure Lamp Socket. Follow step 1-5 of replacing Lamp. Follow step 1-6 of replacing Thermostat. 1. Take out socket of Thermostat. 2. Press R Lamp Socket to remove lock. 3. Lift out R Lamp Socket. 4.
- Page 16 P a g e Part Name Operating Procedure Starting Relay (PTC) - Follow step 1-4 of replacing Elec. Component Ass’y. 1. Release screws that hold Relay 2. Remove Relay Cover. 3. Lever Starting Relay by flatton Cover. screw driver. 4. Remove Starting Relay. Hold Recept Terminal then pull out 6.
- Page 17 P a g e Part Name Operating Procedure Overload Protector. Follow step 1-5 of replacing Starting Relay. 1. Remove Overload Protecto 2. Hold Recept Terminal then pull out 3. After Replacing Overload electrical wires from Overload Protector. Protector, reverse the steps above.
- Page 18 P a g e Part Name Operating Procedure Timer. 1. Release screws that hold Electric Box 2. Pull out Electric Box Ass’y 3. Release screws that hold Cover Ass’y. Case Elec. 4. Separate Electric Box Ass’y from 5. Release screws that hold Electric Pull out Timer each other.
-
Page 19: Trouble Shooting
P a g e Trouble shooting Before calling for service, please read the following troubleshooting table first. This can save both your time and money. The table contains common problems except those caused by defects in workmanship or material of the refrigerator. Problem Cause Solution... - Page 20 P a g e Too High Temperature Warm air will enter the refrigerator whenever the The door is opened too frequently Too high door is opened. Try to open the door as or for too long each time. temperature in less frequently as possible.
