Instructions for Use – NPS3
1
Intended use
The NPS3 pressure display unit is an active medical product with internal power supply, which in
combination with other RAUMEDIC accessories, such as the ICP-TEMP-Cable (REF 094328-001), and
single-channel RAUMEDIC precision pressure catheters is used for short-time measurement of a
physiological pressure.
Warning: Limiting alarm values cannot be monitored with the NPS3 pressure display device!
The NPS3 can be used to display the pressure value of a pressure catheter prior to implantation. Three
pressure values per second are displayed after the particular pressure catheter has been implanted.
Fig. 1: Example of a typical measuring chain layout
2
Operational environment
The NPS3 is intended for use in clinical environments and doctor's office to be operated by specialized
medical staff. The unit is used either stationary or mobile during transport in the hospital. Doctors,
intensive care nurses and medical technicians shall use the unit. The unit is not intended for use outside
of the hospitals, such as in helicopters or in ambulances. The NPS3 is not intended for use in domestic
settings.
3
Explanation of labels and symbols on the device
Battery low
No sensor present
Test 0 mmHg
0123
Manufacturer: RAUMEDIC AG, Hermann-Staudinger-Str. 2, 95233 Helmbrechts, Germany
Instructions for use of RAUMEDIC NPS3
(REF 091656-001)
Discharged battery
No sensor (pressure catheter) connected or cable interrupted or defective
Test button
Device corresponds the essential requirements of Directive 93/42/EEC
Page 1 of 10
zwo-188 EN Rev. 11 / 2022-05-04
Advertisement
Table of Contents
Related Manuals for RAUMEDIC NPS3
Summary of Contents for RAUMEDIC NPS3
- Page 1 The unit is used either stationary or mobile during transport in the hospital. Doctors, intensive care nurses and medical technicians shall use the unit. The unit is not intended for use outside of the hospitals, such as in helicopters or in ambulances. The NPS3 is not intended for use in domestic settings.
-
Page 2: Technical Data
Attention! Observe accompanying instructions for use! Date of manufacture Observe disposal regulations. Do not throw used devices away in landfill waste. Temperature limitation Manufacturer: RAUMEDIC AG, Hermann-Staudinger-Str. 2, 95233 Helmbrechts, Germany zwo-188 EN Rev. 11 / 2022-05-04 Page 2 of 10... - Page 3 Caution: • For self-test of the zero point of the NPS3, a test shall have to be carried out prior to every use: With the pressure catheter connected, press the ”Test 0 mmHg” button → 0 mmHg must appear in the display.
-
Page 4: Change Of Battery
In case the housing and the membrane keyboard have been damaged, the NPS3 may not be used anymore. Cleaning For cleaning, the NPS3 and the connecting cable are wiped with a cloth which previously has been saturated in soap suds or 70 % isopropyl alcohol. Disinfection A short-time (maximum 5 min.) spray disinfection shall be permissible (recommended agent: Incidin... - Page 5 Do not clean the inner surface of the NPS3 or ICP-TEMP-Cable connectors! • Do not use the NPS3 if it has been damaged by a fall. Send it back to RAUMEDIC for checking. • Do not use the NPS3 after the expiry date of its calibration. For the function of the NPS3, operating or precision deviations may occur! Manufacturer: RAUMEDIC AG, Hermann-Staudinger-Str.
-
Page 6: Safety Information
6 or replaced. • If the NPS3 comes into contact with liquids accidentally, it must be dried with a cloth prior to use. 13 Inspections, Safety and measurement related checks 13.1... - Page 7 Art.-Nr. 094328-001 Catheter (Application part): NEUROVENT-P Art. No. 092946-001 OMNIBAR E5F Art. No. 091204-001 To learn about other compatible catheters, ask the manufacturer. Manufacturer: RAUMEDIC AG, Hermann-Staudinger-Str. 2, 95233 Helmbrechts, Germany zwo-188 EN Rev. 11 / 2022-05-04 Page 7 of 10...
-
Page 8: Electromagnetic Compatibility
Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the NPS3, including cables specified by the manufacturer. Otherwise, degradation of the performance of this equipment could result. - Page 9 Instructions for Use – NPS3 15.4 Electromagnetic immunity The NPS3 is intended for use in an electromagnetic environment as specified below. The operator or the user of the NPS3 should ensure that it is operated in such an environment. Measurement of Immunity...
-
Page 10: Warranty And Liability
This shall also apply for the further processing of this article and for its use for the manufacture of other products. RAUMEDIC warranty terms shall apply exclusively. These instructions for use shall be protected by copyright. The rights derived, in particular those in the translation, reproduction, use of illustration, radio transmission, representation by photo-mechanical or similar way and the storage in data processing systems, shall be reserved.
