Flexible Arm Installation

This LCD monitor is designed for use with a flexible arm. To mount the monitor to
a flexible arm:
. Follow the instructions on how Remove Monitor Stand for Mounting to remove
the stand.
2. Use the 4 screws to
NOTE: The LCD monitor should only be used with an approved arm (e.g. GS mark).
To meet the safety requirements, the monitor must be mounted to an arm which
guaranties the necessary stability under consideration of the weight of the monitor.
2mm
4 x 2mm with lock washer and flat washer
Figure F.
4 Screws (M4)
(Max Depth: 8.5 mm)
attach the arm to the monitor (Figure F.1).
M4
00mm
00mm
8
Thickness of Bracket (Arm)
2.0~3.2mm
Weight of LCD assembly:
70GX - 4.0 kg (MAX)
2
90GX - 4.8 kg (MAX)
2
