How to connect more than one TP-
Link Led Light Strips together
If you have multiple TP-Link Led light strips and wish to connect them to a single power source,
this article will explain what models of Led light strips can be connected together and how.
The maximum length of the light strip is limited by the maximum output of the power
adapter:
Model
KL400L5
KL400L10
KL420L5
TapoL900-5
TapoL900-10
TapoL900-20
TapoL920-5
TapoL920-10
TapoL930-5
TapoL930-10
10(10*1m) *support Serial Connection
KL430
Case 1: Led Light Strips – 10M/20M
( X Serial Connection; √ Parallel Connection )
Models: KL400L10, TapoL900-10, TapoL900-20, TapoL920-10, TapoL930-10 etc.
The 10 or 20-meter-long light strips are composed of multiple 5 -meter-long light
strips. The included 5-meter-long light strips do NOT support being connected in
Series, they can only be connected in Parallel.
Each of them is connected to the controller separately like in the following picture
What should I do if I cannot make
Tapo smart devices (smart plug,
smart camera, smart lighting) work
with Alexa or Google Home
If the Tapo device can be controlled both locally and remotely but fails to work with Amazon
Alexa/Google Home, you can refer to the following steps to troubleshoot according to the
problem you encountered.
Maximum length (unit:m)
5
10（2*5m）
5
5
10（2*5m）
20（4*5m）
5
10（2*5m）
5
10（2*5m）
up to 10 meters
input power of light strip (unit: W)
12
18
18
12
18
39.6
18
39.6
12
24
2m light strips: 17W
3~10m light strips: 25W
Advertisement
Related Manuals for TP-Link KL400L5
Summary of Contents for TP-Link KL400L5
- Page 1 How to connect more than one TP- Link Led Light Strips together If you have multiple TP-Link Led light strips and wish to connect them to a single power source, this article will explain what models of Led light strips can be connected together and how.
- Page 2 Example model: Tapo L900-20 Case 2: Led Light Strips- 5M ( X Serial Connection ) Models: KL400L5, KL420L5, TapoL900 -5, TapoL920-5, TapoL930 etc. For the light strip whose whole length is 5 meters, it DOES NOT support connecting with the same model of another 5 -meter-long light strip.
- Page 3 Case3: Led Strip(s) – KL430 ( √ Serial Connection ) KL430(2*1m) supports being connected in Series with another 8 KL430E(1*1m) for a total length of 10 meters. What if Tapo Sync-to-Sound doesn’t work on my Tapo Light Strip Make sure this Tapo device is powered on. ·Make sure the sound source is closer to your phone/tablet.
- Page 4 Option 1: Open the Tapo app, then press and touch your light strip card. Then tap Remove at the bottom to remove your light strip. The light strip will be removed from your Tapo account and reset to the default settings. Option 2: Open the Tapo app and tap on your light strip card.
