  • Page 1 Ｅ６５８２０５６ TOSVERT VF Series Adaptation manual for IE3 motors...

  • Page 2: Table Of Contents

    Ｅ６５８２０５６ Contents INTRODUCTION PROCEDURE FOR IE3 MOTOR PARAMETERS SETTING 2.1. In case of Toshiba standard IE3 motors (Premium Gold Motor) 2.1.1. Setting of V/F parameters 2.1.2. Perform the Auto-tuning 2.2. In case of other than Toshiba standard IE3 motors (4pole) 2.2.1.

  • Page 3: Introduction

    2.1. In case of Toshiba standard IE3 motors (Premium Gold Motor) The motor parameters of Toshiba standard IE3 motors (4 pole) for each models are shown in Table 1.1 and Table 1.2. Table 1.1 is for 200V models. (Base frequency voltage1 is 200V) Table 1.2 is for 400V models.

  • Page 4: Perform The Auto-Tuning

    Ｅ６５８２０５６ 2.1.2. Perform the Auto-tuning In case of the following V/F control mode selection (pt), Auto-tuning is required. Please perform the Auto-tuning according to the next page procedure. VF-AS1 Automatic torque boost (pt=2), Sensorless vector control1 (pt=3), Sensorless vector control2 (pt=4), PG feedback control (pt=7), PG feedback vector control (pt=8) VF-PS1 Automatic torque boost (pt=2), Sensorless vector control1 (pt=3), PG feedback control (pt=7),...
  • Page 5 Ｅ６５８２０５６ Procedure1. Setting of motor prameters (1) Set 50Hz or 60Hz to vl(Base frequency1). (2) Set 200V or 400V to vlv(Base frequency voltage1). (3) Set the motor parameters of Table1.1 and Table1.2. Please set the below parameters from Table1.1 and Table 1.2. VF-AS1, VF-PS1 Communication Title...
  • Page 6 Ｅ６５８２０５６ Table 1.1 200V models ( In case of Base frequency voltage1 is 200V: vlv=200(V) ) Automatic Torque torque boost Motor rated current Motor rated speed Type boost Rated slip (%) value1 (min-1) value VFAS1 f410 f406 f407 f413 VFPS1 VFS15 VFnC3 f402...
  • Page 7 Ｅ６５８２０５６ Table 1.2 400V models ( In case of Base frequency voltage1 is 400V: vlv=400(V) ) Automatic Torque torque Motor rated speed boost Motor rated current Rated slip Type boost (min-1) value1 value VFAS1 f410 f406 f407 f413 VFPS1 VFS15 VFnC3 f402 f415...

  • Page 8: In Case Of Other Than Toshiba Standard Ie3 Motors (4Pole)

    For adaptation other than Toshiba standard IE3 motors (4pole), the motor parameters setting are required. Please set them refer to motor name plate or test report. Even if you use Toshiba standard IE3 motors (4-pole), If the base frequency is set to other than 200V or 400V, the motor parameters setting are required.
  • Page 9 Ｅ６５８２０５６ VF-FS1 Automatic torque boost control (pt=2), Vector control (pt=3), Advanced energy-saving (pt=4) VF-nC3 Automatic torque boost control (pt=2), Vector control (pt=3), Advanced energy-saving (pt=4)

  • Page 10: Toshiba Ie3 Motor Parameter Adaptation Inverter

    If the Auto-tunig error (etn、etn1～3) occurs at Auto-tuning, please refer to the countermeasure of the instruction manual of each models. 2.3. Toshiba IE3 motor parameter adaptation inverter The default setting values of motor parameters of “VF-AS1/PS1/S15/nC3” have been changed to IE3 motors from traditional IE1 motors.

  • Page 11: Troubleshooting

    Ｅ６５８２０５６ 3. TROUBLESHOOTING If you have any problems by setting according to “Procedure for IE3 motor parameters setting” of chapter 2, please refer to this section or the instruction manual of each models. If the problem is not solved, please contact our distributor. 3.1.
  • Page 12 Ｅ６５８２０５６ Table 3.2 VF-AS1 / VF-PS1 f458 f458 f458 Type Form (Recommended value) (Minimum value) (Default setting) 2110 or less 2150～2220 2300～2550 2750～ － － ― 0,1,5 4015 or less 4022～4037 4055～4185 4220～4550 4750～ － － ― 2110 or less VFAS1 2150～...
