Muratec F-360 Quick Reference Manual

Muratec F-360 Quick Reference Manual

Muratec f-360: quick start
Hide thumbs Also See for F-360:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Field Engineering Manual, User Manual

Advertisement

Table of Contents
loading

Related Manuals for Muratec F-360

Summary of Contents for Muratec F-360

  • Page 2: Enter The Fax Number

    Set the document in the ADF face up and adjust the document guides. Adjust the followings, if necessary: • Select the resolution by pressing [Mode]. • Select the contrast by pressing [Contrast]. The number of the pages you can set in the ADF at one time is as follows: Letter-sized: 80 sheets Half letter-sized: 80 sheets...
  • Page 3 Set the document in the ADF face up. Adjust the resolution and the contrast, if necessary. If you want to review the numbers you entered, press [Review]. When you are finished, press [Return] to return to the previous display. Enter the fax number using the numeric keypad Press the one-touch key* Press the speed-dial number using the numeric keypad...
  • Page 4 Press COMM.CANCEL/CONFIRM. Press to scroll through currently stored commands. " Press [Location] to see the individual numbers within the broadcast. Press until you find the number you want to cancel. When the command you want to cancel shown, press [Erase]. Press [Yes].

  • Page 5: Using The Numeric Keypad

    Press to change COPY to Copy mode. Set the document in the ADF face up. Helpful Tip If you want to reduce the document, set the reduction rate in advance: 1. Press , 2, 3, 0, 1, MENU 2. Select "Copy Reduction Rate", then press 3.
  • Page 6 Press to change COPY to Copy mode. Open the bypass tray on the right side of your machine. Flapper release lever Pull out the hopper of the bypass tray and raise the flapper release lever. Set the document in the ADF face up. Place the paper on the bypass tray face down.
  • Page 7 The LCD will show: Bypass Tray Letter Legal H.LTR Using the cursor key, select the paper size you’ve set on the bypass tray. When you use transparency film, select "OHP". Enter the number of copies. Adjust the following, if necessary. •...

  • Page 8: Clearing Original Document Jams

    Just in case Document Jam Open & Check the Blinking Cover Open the scanner cover and remove the jammed paper (see next page). If the document jammed in the following cases, perform the job again from the beginning after removed the jammed paper. •...
  • Page 9 To remove the document . . . Open the scanner cover. Remove the original document. If you cannot remove it, go to step 2. Otherwise, skip to step 3. Open the inner cover. Remove the original document. Gently close the scanner cover. Make sure both sides are If the document has become wrinkled snapped down securely.

  • Page 10: Open The Top Cover

    Important ! Be careful not to put your hand between the top cover and the machine. Open the top cover. Important ! Shield the drum cartridge from light, especially strong light. Remove the toner and drum cartridge. Pull up the printer cover release and open the printer cover.
  • Page 11 Important ! The fuser unit becomes very hot. Do not touch the fuser unit when you are removing jammed paper. Remove the jammed paper. Gently close the top cover. Press firmly on the both sides of the cover until you hear it click. Open the side cover.

  • Page 12: Function Table

    Speed-Dial, press MENU Note: “Page” in the rightest column in this table means the pages in the F-360 Operating Instructions. Note: Your machine can print a function list. It lists the functions available on your fax machine and the keystrokes needed to complete them.
  • Page 13 Level one function Level two function Level three function 2. User Settings 2.Fax Settings 01.Scan Parameters 02.Print Parameters 03.Number of Rings 04.Redial 05.Dialing Pause 06.Memory Tx 07.Quick Memory Tx 08.TTI Transmission 09.ECM Mode 10.Block Junk Fax 11.Security Rx 12.Separator Page 13.Rotate Rx 14.PIN Mode 15.DRD...
  • Page 14 Enter the Media Access Control Address for network card. 03.Default Relay Setting of relay box. 01.Polling Document Store the document to be retrieved by other fax machine. 02.F-Code Document Store the document to be retrieved by other F-Code compatible fax machine.
  • Page 15 Level one function Level two function Level three function 5.Print 1.List Print 01.Function List 02.User Settings 03.Journal 04.Commands List 05.One-Touch List 06.Speed Dial List 07.Group List 08.Block Junk Fax List 09.Cover Page 10.Dept. Time List 11.P One-Touch List 12.F-Code Box List 13.F-Code Doc.
  • Page 16 Muratec America, Inc. 6400 International Parkway Suite 1500 Plano, Texas 75093 http://www.muratec.com © Muratec America, Inc. 2001 Printed in China. MAI order number: OMF360QRG MML item number: D94-90020-60...
