- Page 1 ISDN ProxyServer Model MTPSR1-202ST Quick Start Guide...
- Page 2 The CE mark is affixed to the enclosed MultiTech product to confirm compliance with the following European Community Directives: Council Directive 89/336/EEC of 3 May 1989 on the approximation of the laws of Member States relating to electromagnetic compat- ibility; Council Directive 73/23/EEC of 19 February 1973 on the harmoni- zation of the laws of Member States relating to electrical equip- ment designed for use within certain voltage limits;...
-
Page 3: Quick Start Guide
Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes. -
Page 5: Table Of Contents
Contents Introduction ... 7 Related Documentation ...8 Safety Warnings ... 9 Unpacking your ProxyServer ...9 Cabling your ProxyServer ... 10 Before You Start Loading your Software ...12 Network Configuration ... 12 Call Control Parameters ...13 Data Control ... 14 Loading your Software ...16 IP Port Configuration ...19 Limited Warranty ...24 Service ...24... - Page 6 ISDN ProxyServer Quick Start Guide...
-
Page 7: Introduction
Introduction Introduction Welcome to Multi-Tech's new ISDN ProxyServer model number MTPSR1-202ST, a single, secure gateway that provides multiple LAN users with high performance Internet access. The ISDN ProxyServer functions as a TCP/IP proxyserver that resides on the outer edge of your firewall and provides Basic Rate ISDN Service using its internal 2B+D terminal adapter. -
Page 8: Related Documentation
ISDN ProxyServer User Guide is also available on Multi-Tech’s Web site at: http://www.multitech.com From the MTS home page, click Support | Manuals | ProxySer- ver and choose the User Guide for your Model MTPSR1-202ST which will download the .pdf file. -
Page 9: Safety Warnings
Safety Warnings 1. Never install telephone wiring during a lightning storm. 2. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. 3. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. -
Page 10: Cabling Your Proxyserver
ISDN ProxyServer Quick Start Guide Cabling your ProxyServer Cabling your ProxyServer involves making the proper Power, Command Port, Ethernet, and WAN connections. Figure 3 shows the back panel connectors and the associated cable connections. Table 1 details the procedures for connecting the cables to your ProxyServer. - Page 11 Table 1. Cabling Procedure Step Procedure Connect one end of the power supply to a live AC outlet and connect the other end to the ProxyServer as shown in Figure 3. The power connector is a 6-pin circular DIN connector. Connect the ProxyServer to a PC by using the short RJ45 to DB25 (female) cable provided with your unit.
-
Page 12: Before You Start Loading Your Software
ISDN ProxyServer Quick Start Guide Before You Start Loading your Software Consider the following choices before you configure your Proxy- Server and record your selections on the following pages; then refer to them while loading your software. Network Configuration ü Network Switch Type_______________________________ Select the network switch type your ISDN service provider uses at its local central office. -
Page 13: Call Control Parameters
Note: For DMS-100 switches, any ASCII character except the underline (_) character is valid. For NI-1 and AT&T switches, only the digits 0-9 are valid. ü Voice SPID________________________________________ The voice SPID is assigned by the local phone company and is for the specific BRI line to which the ProxyServer will be at- tached. -
Page 14: Data Control
ISDN ProxyServer Quick Start Guide conveying Calling Party information to the terminal for ISDN voice calls. The CLI information is only included with the first RING message for a given incoming call, and appears as fol- lows: FM: 5552000 TO: 5551000 If the Calling Party Number information is not included in the incoming SETUP message, the RING message appears as follows:... - Page 15 Software MLPPP Protocol The MLPPP (Multi-Link PPP) protocol provides rates up to 64K bps per channel. This protocol uses both B channels at once, providing an aggregate data transmission speed of 128K bps. ü Dialing Method _____________________________________ Select either the “Enbloc” or the “Overlap” dialing method for use when establishing a data call.
-
Page 16: Loading Your Software
ISDN ProxyServer Quick Start Guide Loading your Software The following loading procedure does not provide every screen or option used in the process of installing the ProxyServer software. The assumption is that a technical person with a thorough knowl- edge of Windows and the software loading process is doing the installation. - Page 17 4. Follow the on-screen instructions to install the Proxy- Server software. 5. The following dialog box selects the COM port of your PC that is connected to the Command Port of the ProxyServer. From the Select Port list box, click on the down arrow and choose the COM port of your PC.
- Page 18 ISDN ProxyServer Quick Start Guide 7. Click on the Finish button to continue. 8. The “Do you want to download default setup?” dialog box is displayed. 9. Click on Yes to download the default setup. Clicking on the No button prevents the defaults from being downloaded to the ProxyServer.
-
Page 19: Ip Port Configuration
IP Port Configuration This dialog allows for the configuration of IP parameters that are generally applicable to IP Proxying on all ports. 10. The default LAN IP address has to be changed to your unique LAN address. Change the default IP address, 192.168.0.1, to your unique LAN IP address. - Page 20 ISDN ProxyServer Quick Start Guide 13. Click on the Default Configuration supplied by your local ISDN service provider. Refer to your entry in Network Switch Type in Before You Start Loading Your Software in this chapter. 14. Click on the ISDN Dial Number field and enter the telephone number supplied by your ISDN service provider.
- Page 21 17. Click on the Voice TEI field in Network Parameters. Refer to your Voice TEI entry in the Network Configuration section in Before You Start Loading Your Software. If the Voice TEI is different, click on the drop-down list arrow, then click on the selection that matches the Voice TEI supplied by your ISDN service (i.e., Disabled, Auto TEI, or zero to 63).
- Page 22 ISDN ProxyServer Quick Start Guide 22. If US Parameters are active, enter the Data Directory Num(ber) supplied by your local telephone company and you recorded. If Europe Parameters are active, enter the Data Sub Address supplied by your local telephone company and you recorded.
- Page 23 26. The Writing Setup dialog box is displayed as the setup configuration is written to the ProxyServer. 27. Check to ensure that the Fail LED on the ProxyServer is Off after the download is complete and the Proxy- Server is rebooted. 28.
-
Page 24: Limited Warranty
CEED THE PURCHASE PRICE FOR DEFECTIVE PRODUCTS. Service Multi-Tech has an excellent staff of technical support personnel available to help you get the most out of your Multi-Tech product. Refer to your ISDN ProxyServer User Guide for Warranty and Service information. - Page 25 82076801...
