Siemens SIMATIC S7-1500 Equipment Manual
Hide thumbs
Also See for SIMATIC S7-1500:
- System manual (523 pages) ,
- Function manual (402 pages) ,
- Manual (188 pages)
Related Manuals for Siemens SIMATIC S7-1500
Summary of Contents for Siemens SIMATIC S7-1500
- Page 1 Edition 11/2022 EQUIPMENT MANUAL SIMATIC S7-1500 CPU 1517T-3 PN/DP 6ES7517-3TP00-0AB0 support.industry.siemens.com...
- Page 2 Introduction Safety instructions SIMATIC Product overview S7-1500 CPU 1517T-3 PN/DP Wiring (6ES7517-3TP00-0AB0) Interrupts, error messages, diagnostics and system alarms Equipment Manual Technical specifications Dimension drawing 11/2022 A5E36285525-AD...
- Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 4: Table Of Contents
Table of contents Introduction............................Guide documentation S7-1500/ET 200MP................. 1.1.1 Information classes S7-1500/ET 200MP................1.1.2 SIMATIC Technical Documentation..................Safety instructions..........................10 Security information......................10 Product overview..........................11 New functions........................11 Application........................13 Hardware properties......................19 Firmware functions......................21 Operator controls and display elements................26 3.5.1 Front view of the CPU with closed front flap.............. -
Page 5: Introduction
Industry Mall The Industry Mall is the catalog and order system of Siemens AG for automation and drive solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power (TIP). -
Page 6: Guide Documentation S7-1500/Et 200Mp
Guide documentation S7-1500/ET 200MP 1.1.1 Information classes S7-1500/ET 200MP The documentation for the SIMATIC S7-1500 automation system and the ET 200MP distributed I/O system is arranged into three areas. This arrangement enables you to access the specific content you require. Changes and supplements to the manuals are documented in a Product Information. -
Page 7: Simatic Technical Documentation
ET 200MP distributed I/O system gathered together in one file. You can find the Manual Collection on the Internet. (https://support.industry.siemens.com/cs/ww/en/view/86140384) SIMATIC S7-1500 comparison list for programming languages The comparison list contains an overview of which instructions and functions you can use for which controller families. - Page 8 Online Support: Industry Online Support International https://support.industry.siemens.com/cs/ww/en/view/109742705 Watch this short video to find out where you can find the overview directly in Siemens Industry Online Support and how to use Siemens Industry Online Support on your mobile device: Quick introduction to the technical documentation of automation products per video ( https://support.industry.siemens.com/cs/us/en/view/109780491...
- Page 9 Introduction 1.1 Guide documentation S7-1500/ET 200MP You can find the application examples on the Internet. (https://support.industry.siemens.com/cs/ww/en/ps/ae) CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0) Equipment Manual, 11/2022, A5E36285525-AD...
-
Page 10: Safety Instructions
Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats. -
Page 11: Product Overview
Product overview New functions This section contains an overview of the most important new firmware functions of the CPU compared to the predecessor CPU (V2.9). New functions of the CPU in firmware version V3.0 New functions Applications Customer benefits Communication of the CPU SNMP network manage... - Page 12 .csv file over a long period (e.g. hours, days). Reference You can find an overview of all new functions, improvements and revisions in the respective firmware versions on the Internet (https://support.industry.siemens.com/cs/ww/en/view/109478459). CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0) Equipment Manual, 11/2022, A5E36285525-AD...
-
Page 13: Application
SIMATIC S7-1500 is the modular control system for a wide variety of automation applications in discrete automation. SIMATIC S7-1500 is the cost-effective and convenient solution for a broad range of tasks and offers the following advantages: • Modular, fanless design •... - Page 14 Product overview 3.2 Application Performance segments of standard CPUs The CPUs can be used for smaller and mid-range applications, as well as for the high-end range of machine and plant automation. Table 3-1 Standard CPUs Performance segment PROFIBUS PROFINET PROFINET Basic Work Processing interfaces...
- Page 15 Product overview 3.2 Application The higher the risks and costs of a production downtime, the more worthwhile the use of a redundant system. The avoidance of production downtimes compensates for the generally higher investment costs. Table 3-2 Redundant CPUs Performance segment PROFIBUS PROFINET PROFINET...
- Page 16 Product overview 3.2 Application Performance segments of technology CPUs The technology CPUs can be used for low and mid-range applications, as well as for the high- end range of machine and plant automation. Because of their extended motion control functions, they are primarily used for drive control. Table 3-4 Technology CPUs Performance segment PROFIBUS...
- Page 17 Product overview 3.2 Application Additional password protection for F-configuration and F-program is set up for IT security. Table 3-5 Fail-safe CPUs Performance segment PROFIBUS PROFINET PROFINET Basic Work memory Pro interfaces IO RT/IRT IO RT inter PROFINET cessing interfaces face functional time for bit opera...
- Page 18 VPN connections. Design and handling All CPUs of the SIMATIC S7-1500 product series feature a display with plain text information. The display provides the user with information on the order numbers, firmware version, and serial number of all connected modules.
-
Page 19: Hardware Properties
Product overview 3.3 Hardware properties connection cables and I/O modules), as well as easy wiring inside the control cabinet (flexible connection consisting of front connectors with assembled single conductors). System diagnostics and alarms Integrated system diagnostics is activated by default for the CPUs. The different types of diagnostics are configured instead of programmed. - Page 20 The CPU 1517T‑3 PN/DP has the following properties: Property Description Additional information CPU display All CPUs of the SIMATIC S7-1500 product series feature a • S7-1500, ET 200MP system manu display with plain text information. The display provides information on order numbers, firmware version and (https://support.automation.
-
Page 21: Firmware Functions
IO controller and is used in the process as an intelligent pre-processing unit of sub-processes Accessories You can find information on "Accessories/spare parts" in the S7-1500, ET 200MP system manual (https://support.automation.siemens.com/WW/view/en/59191792). Firmware functions Functions The CPU supports the following functions: Function... - Page 22 The web server lets you access the CPU data by means of • Web server function manual a network. Evaluations, diagnostics, and modifications (https://support.automation. siemens. are thus possible over long distances. Monitoring and com/WW/view/en/59193560) evaluation is possible without STEP 7, only a web •...
- Page 23 Product overview 3.4 Firmware functions Function Description Additional information IRT (isochronous real time) A reserved bandwidth within the send clock is available for IRT data. The reserved bandwidth ensures that the IRT data can be transmitted in time-synchronized intervals, unaffected by other high network loading (e.g. TCP/IP communication or additional real time communication).
- Page 24 You program the technology objects with Motion Control instructions according to PLCopen. Extended Motion Control The technology CPUs of the SIMATIC S7-1500 also sup Motion Control topic page functions port extended Motion Control functions with the addi...
- Page 25 Know-how protection The know-how protection protects user blocks against System manual S7‑1500/ET 200MP unauthorized access and modifications. (https://support.automation.siemens. com/WW/view/en/59191792) Copy protection Copy protection links user blocks to the serial number of the SIMATIC memory card or to the serial number of the CPU.
-
Page 26: Operator Controls And Display Elements
Product overview 3.5 Operator controls and display elements Operator controls and display elements 3.5.1 Front view of the CPU with closed front flap The figure below shows the front view of the CPU 1517T‑3 PN/DP. ① LEDs for the current operating mode and diagnostics status of the CPU ②... - Page 27 S7-1500, ET 200MP (http://support.automation.siemens.com/WW/view/en/59191792) system manual. Reference You can find detailed information on the individual display options, a training course and a simulation of the available menu commands in the SIMATIC S7-1500 Display Simulator (https://support.industry.siemens.com/cs/ww/en/view/109761758). CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0) Equipment Manual, 11/2022, A5E36285525-AD...
-
Page 28: Front View Of The Cpu Without Front Flaps
Product overview 3.5 Operator controls and display elements 3.5.2 Front view of the CPU without front flaps The figure below shows the operator controls and connection elements of the CPU 1517T‑3 PN/DP. ① Mode selector ② No function ③ PROFIBUS interface (X3) ④... -
Page 29: Rear View Of The Cpu
Product overview 3.6 Mode selector 3.5.3 Rear view of the CPU The following figure shows the connection elements on the rear of the CPU 1517T‑3 PN/DP. ① Shield contact surfaces ② Plug-in connection for power supply ③ Plug-in connection for backplane bus ④... -
Page 30: Wiring
Wiring This section provides information on the pin assignment of the individual interfaces and the block diagram of the CPU 1517T‑3 PN/DP. 24 V DC supply voltage (X80) The connector for the power supply is plugged in when the CPU ships from the factory. The following table shows the signal names and the descriptions of the pin assignment of the 24 V DC supply voltage. - Page 31 You can find additional information on the topics of "Connecting the CPU" and "Accessories/spare parts" in the S7-1500, ET 200MP (https://support.automation.siemens.com/WW/view/en/59191792) system manual. Assignment of the MAC addresses CPU 1517T‑3 PN/DP has two PROFINET interfaces. The first interface has two ports. The PROFINET interfaces each have a MAC address, and each of the PROFINET ports has its own MAC address.
- Page 32 Wiring The MAC addresses of the PROFINET ports are needed for the LLDP protocol, for example for the neighborhood discovery function. The number range of the MAC addresses is sequential. The first and last MAC addresses are lasered on the rating plate on the right side of each CPU 1517T‑3 PN/DP. The table below shows how the MAC addresses are assigned.
- Page 33 Wiring Block diagram The figure below shows the block diagram of the CPU 1517T‑3 PN/DP. X2 P1 X1 P1 X1 P2 X80 DC 24 V X2 P1 X1 P1R X1 P2R PB X3 ① Display PN X1 P1R PROFINET interface X1 port 1 ②...
-
Page 34: Interrupts, Error Messages, Diagnostics And System Alarms
You can find additional information on the topic of "Interrupts" in the STEP 7 online help. You can find additional information on the topic of "Diagnostics" and "System alarms" in the Diagnostics (https://support.automation.siemens.com/WW/view/en/59192926) function manual. Status and error displays of the CPU LED display The figure below shows the LED displays of the CPU 1517T‑3 PN/DP. - Page 35 Interrupts, error messages, diagnostics and system alarms 5.1 Status and error displays of the CPU Meaning of the RUN/STOP, ERROR and MAINT LEDs The CPU 1517T‑3 PN/DP has three LEDs to signal the current operating status and diagnostics status. The following table shows the meaning of the various combinations of colors for the RUN/STOP, ERROR and MAINT LEDs.
- Page 36 Interrupts, error messages, diagnostics and system alarms 5.1 Status and error displays of the CPU RUN/STOP LED ERROR LED MAINT LED Meaning Startup (CPU booting) LED flashes red LED flashes yellow LED flashes Test of LEDs during startup, inserting a module. yellow/green LED flashing test Meaning of LINK RX/TX LED...
-
Page 37: Technical Specifications
Internet (https://support.industry.siemens.com/cs/ww/en/pv/6ES7517-3TP00-0AB0/td?dl=en). General technical specifications You can find information on the general technical specifications, such as standards and approvals, electromagnetic compatibility, protection class, etc., in the S7‑1500, ET 200MP system manual (https://support.automation.siemens.com/WW/view/en/59191792). CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0) Equipment Manual, 11/2022, A5E36285525-AD... -
Page 38: Dimension Drawing
Dimension drawing This section contains the dimension drawing of the module on the mounting rail, as well as a dimension drawing with the front panel open. Always observe the specified dimensions for installation in cabinets, control rooms, etc. Dimension drawings for CPU 1517‑3 PN/DP Figure A-1 Dimension drawing of the CPU 1517T‑3 PN/DP, front and side view Figure A-2 Dimension drawing of the CPU 1517T‑3 PN/DP, side view with open front panel CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)
