- Page 1 ™ PROJECTOR MODEL XD600U/XD600U-G WD620U/WD620U-G User Manual XD600U XD600U-G WD620U WD620U-G This User Manual is important to you. Please read it before using your projector.
- Page 2 EN55022 Class B device. Please follow WARNING instructions. Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be recycled and/or reused. This symbol means that electrical and electronic equipment, batteries and accumula- tors, at their end-of-life, should be disposed of separately from your household waste.
-
Page 3: Table Of Contents
XD600U/XD600U-G/WD620U/WD620U-G Trade Name : MITSUBISHI ELECTRIC Responsible party : Mitsubishi Digital Electronics America, Inc. 9351 Jeronimo Road, Irvine, CA 92618 U.S.A Telephone number : +1-(949) 465-6000 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Important Safeguards
Water and moisture Do not use this projector near water or in contact with water. Accessories Do not place this projector on an unstable cart, stand, tripod, bracket or table. - Page 5 • Consult the dealer or an experienced Radio / TV technician for help. Changes or modifications not expressly approved by Mitsubishi could void the user’s authority to operate this equipment. COMPLIANCE NOTICE OF INDUSTRY CANADA This Class B digital apparatus complies with Canadian ICES-003.
-
Page 6: Overview
This projector has a Kensington Security Standard connector for use with Kensington MicroSaver Security System. Refer to the information that came with the Kensington System for instructions on how to use it to secure the projector. Please contact Kensington Technology Group below. -
Page 7: Bottom Side
Overview (continued) Bottom side Remote control MAGNIFY KEYSTONE DOWN MENU ENTER MUTE VIEWER COMPUTER UNPLUG This model does not have these functions. WIRELESS STANDBY ASPECT This model does not PAGE have these functions. AUTO POSITION FREEZE VIDEO S-VIDEO HDMI Adjustment feet MAGNIFY button VOLUME UP, DOWN buttons KEYSTONE button... -
Page 8: Remote Control
The maximum operation distance of the remote control is about 10 m (or about 32 feet) when the remote control is pointed at the remote control sensor of the projector. When the remote control is pointed to the screen, the distance from the remote control to the projector via the screen should be 5 m or less. -
Page 9: Installation
Installation Layout of the projector XD600U/XD600U-G Image size varies depending on the distance between the screen and the projector. Front projection Screen Diagonal size Width : SW inch inch • The above figures are approximate and may be slightly different from the actual measurements. -
Page 10: Ceiling Mount Installation
Diagonal Size inch inch inch Ceiling Mount Installation If you wish to install the projector using a ceiling mount, please use the screw holes as the illustration shows. Important: • Screws are not included. Please obtain the appropriate screws for your type of ceiling. -
Page 11: Rear Projection
Put a hard board under the pro- jector to facilitate ventilation. • Place the projector at least 50 cm (or 20 inch) away from the wall to prevent the air inlet grille and the air outlet grilles that emit hot air from being blocked. -
Page 12: Basic Connections
Make sure that the connected device is turned off before starting connection. • Plug in the power cords of the projector and the connected devices firmly. When unplugging, hold and pull the plug. Do not pull the cord. • When the projector and the connected devices are located too close to each other, the projected image may be affected by their interference. -
Page 13: Connection (For Video Equipment Having An Hdmi Terminal)
You don’t have to connect any cable for audio input. You can input video and audio using an HDMI cable only. • When HDMI audio isn’t output, it may be output by turning off the power of the video equipment with the projector and the video equipment con- nected to each other and then turning back on the power. - Page 14 • After connecting a computer supporting this standard to this terminal, plug the power cord of the projector in the wall outlet first, and then boot up the computer. EN-14...
-
Page 15: Preparation
Remove the lens cap. Warning: • Do not look into the lens directly when the projector is on. • The lens cap is for protecting the lens. If you leave the lens cap on the lens with the projector turned on, it may be deformed because of heat build-up. -
Page 16: Basic Operation
In order to ensure the safety in case of trouble with the projector, use an electrical outlet having an earth leakage breaker to supply the power to the projector. If you do not have such outlet, ask your dealer to install it. -
Page 17: Setting The Aspect Ratio
The lamp can’t be lit again for one minute after turned off for safety purpose. It will take another one minute for the STATUS indicator to go out. If you want to turn on the projector again, wait until the indicator goes out, and then press the POWER button. - Page 18 When connecting to a laptop computer: When this projector is connected to a laptop computer, there may be times when images may not be projected. When it occurs, set the computer so that it can output signals externally. The procedure varies across computers in use.
-
Page 19: Menu Operation
Comparing QUICK MENU with DETAIL MENU, if the contents in those two menus are same each other, the functions in those two menus are same as well. • To close QUICK MENU or DETAIL MENU, press MENU button when MENU is displayed. QUICK MENU * Menus are not displayed when no signal is supplied to the projector. QUICK MENU COLOR ENHANCER CONTRAST BRIGHTNESS COLOR TEMP. -
Page 20: Menu Options
Menu operation (continued) Menu Options Set the following options provided in the respective menus. 1. QUICK MENU Menu option Setting AUTO PRESENTATION COLOR ENHANCER STANDARD THEATER USER ±30 CONTRAST ±30 BRIGHTNESS COLOR TEMP. 4 options ±5 SHARPNESS STANDARD LAMP MODE NORMAL ASPECT 16:9... - Page 21 *5 Available only when the input signal is from the VIDEO IN or S-VIDEO IN terminal. *6 AUDIO 1, AUDIO 2, AUDIO 3, and MIX cannot be selected when the Input Source is HDMI input. is not displayed and is not available in WD620U/WD620U-G. *8 This function is not available in WD620U/WD620U-G. AUTO...
- Page 22 Adjusts the input level of analog video signals. The input level of the video signal varies across devices to which the projector is connected. A high input level causes projected images to appear solid white, and a low input level causes projected images to appear dark.
- Page 23 Select ON when you set the projector at the ceiling. • When the lamp is off, the projector is in standby. Use the remote control to turn on the lamp. Selects a desired timer setting until the projector enters the standby mode when there is no signal input from the source.
-
Page 24: Feature Menu
RESET ALL • You can select CINEMA MODE only when the input signal is a TV60, TV50, 480i, or 576i video signal. is not displayed and is not available in WD620U/WD620U-G. *2 This function is not available in WD620U/WD620U-G. EN-24 Feature description Automatically sets the aspect ratio in relative to the input signal. - Page 25 Select this setting when you connect the projector to high definition video equipment having R, G, and B output terminals. Select this setting when you connect the projector to a DVD player or other device having Y, C , and C...
- Page 26 Menu operation (continued) 6. INFORMATION menu Menu option This menu shows a lamp operating time (hour) calculated assuming that LAMP MODE is LOW. • When the LAMP MODE is STANDARD, this menu shows a longer lamp operating time than the actual time. (See page 36 for the interval of lamp replacement.) •...
-
Page 27: Image Adjustment
Image adjustment Adjusting projected images To adjust the brightness (CONTRAST and BRIGHT- NESS): You can make adjustments of the brightness of the projected image using the menu. (See page 20 or 22 for the menu options.) Display the QUICK MENU or the IMAGE menu. Select CONTRAST or BRIGHTNESS by pressing the button. - Page 28 Every time button is pressed, the image appears more reddish. This projector automatically and properly projects video signals being input from the computer. However, some video signals may not be projected, depending on the type of the computer. When it occurs, press the AUTO POSITION button.
-
Page 29: Network Settings
Network settings You can set the network of the projector using the menu. opt. NETWORK PROJECTOR NAME NETWORK PASSWORD IP CONFIG PJLink CERTIFICATION NETWORK RESET Setting Projector Name Display the NETWORK menu. (See page 22 for menu setting.) Press the button to select PROJECTOR NAME. -
Page 30: Ip Address Settings
Network settings (continued) Setting or Clearing DHCP Display the IP CONFIG menu. Press the button to select DHCP. DHCP Press the ENTER button. • Confirmation dialog appears. Press the button to select ON Select the item to set, and press the ENTER button. •... - Page 31 Configure the IP CONFIG correctly. If the settings are not cor- rect, the communication may be unavailable. For the detail, consult the network administrator. • Depending on the settings of standby mode of the projector, LAN function may be unavailable. See page 23 for the detail of standby mode. Glossary For more detail of the glossary below, refer to the technical book that is commercially available.
-
Page 32: Advanced Features
Do not keep displaying a still picture for an extended period of time, as the afterimages may linger on the screen. Password function This projector provides the password function that is intended to pre- vent wrong operations by children and set controlled access for speci- fied users. - Page 33 Advanced features (continued) To cancel the password function: Display the FEATURE menu. Press the button to select PASSWORD FUNCTION. Press the ENTER button. • The screen for canceling the password function appears. opt. FEATURE MENU ACCESS LOCK UNLOCK Press the ENTER button. •...
-
Page 34: Supervising And Controlling By Computer
(JBMIA). (http://pjlink.jbmia.or.jp/english) • This projector is fully compliant to the specifications of JBMIA PJLink™ Class 1. It supports all the commands defined by PJLink™ Class 1, and the compliance has been verified with the PJLink™ standard specifications Version 1.0. Connection •... -
Page 35: Lamp Replacement
• When replacing the lamp, do not loosen the screws other than two screws (d). It may cause the failure of projector. • Pull the lamp unit out of the projector slowly. If it is pulled out quickly, the lamp may break, scattering glass fragments. -
Page 36: Interval Of Lamp Replacement
(Caution) • Pull the lamp unit out of the projector slowly. If it is pulled out quickly, the lamp may break, scattering glass fragments. • Do not spill liquid on the removed lamp unit or do not place it near any flammable object or where children can reach to pre- vent injuries or fire. -
Page 37: Troubleshooting
Troubleshooting Before asking for repair of the projector, check the following. If the symptom persists, stop using the projector, be sure to unplug the power plug, and then contact your dealer. No image appears on the screen. Problem Power can not be turned on. -
Page 38: Images Are Not Displayed Correctly
• This phenomenon is normal for a DLP projector and is not a malfunction. (A very small number of pixels may visibly or invisibly be persistent all the time, but they are not a sign of system malfunctions. Over 99.99% of the pixels are effective.) - Page 39 Cleaning of the projector and the ventilation slots Use a soft cloth to clean the projector and the ventilation grilles. When the grilles become dirty, wipe them with a soft cloth dampened with diluted mild detergent, and then wipe them with a dry cloth.
-
Page 40: Indicators
Indicators This projector has two indicators, each of which shows the operation condition of the projector. The following offer solutions to possible problems. If these problem persist, turn the projector off and consult your dealer. STATUS indicator Normal condition POWER... -
Page 41: Specifications
XD600U/XD600U-G: 40 - 300 inch (Wide) (aspect ratio 4:3) Picture size WD620U/WD620U-G: 40 - 300 inch (Wide) (aspect ratio 16:10) Resolution: 640x400 (Expand) - XD600U/XD600U-G: 1024x768 (Real) / WD620U/WD620U-G: 1280 x 800 (Real) - PC compatibility 1280x1024 (Compress) Sync on Green available NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM / PAL-60... -
Page 42: Connectors/Dimensional Drawings
AC power cord for US J2552-0063-03 for EU J2552-0066-02 for UK J2552-0065-02 1 RGB cable for PC J2552-0072-03 Replacement part (Option / Not included in the box) Spare lamp for XD600U/XD600U-G/WD620U/WD620U-G EN-42 pin No. Spec. R(RED)/CR G(GREEN)/Y B(BLUE)/CB HD/CS 1 Remote control... - Page 43 • Some computers aren’t compatible with the projector. • The projector’s maximum resolution is 1024 x 768 (XD600U/ XD600U-G) / 1280 x 800 (WD620U/WD620U-G) pixels. It may not display images of higher resolutions than its maximum resolution correctly. • Images with SYNC on G (Green) signal may jitter.
- Page 44 11TH FL., 90 SEC. 6, CHUNG SHAN N. RD., TAIPEI, 111 R.O.C. Sales & Technical Inquiries Phone :+886-2-2832-8255 :+886-2-2833-9813 MKY (Mitsubishi Electric Kang Yong Watana Co., Ltd. ) http://www.mitsubishi-kyw.co.th/ Road, Huamark Bangkapi, Bangkok 10240, Thailand Sales & Technical Inquiries Phone :+66-2-731-6841...
