- Page 1 All manuals and user guides at all-guides.com SB-A510 Reference Guide...
- Page 2 To the extent permitted by law no liability (including liability to any person by reason of negligence) will be accepted by CompuLab, its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or inaccuracies in this document.
-
Page 3: Table Of Contents
Power Output Terminals (P17, P19) ................. 20 4.12 S-ATA Connector (P18) .................... 20 4.13 S/PDIF Connectors (P22, U6) ................... 21 4.14 CompuLab Video Input FPC (P25) ................22 4.15 MMC/SD/SDIO Socket (P5) ..................23 4.16 Audio Jacks (J1, J3) ....................23 4.17 MISC. - Page 4 MECHANICAL DRAWINGS ..................27 OPERATIONAL CHARACTERISTICS ............... 29 Absolute Maximum Ratings ..................29 Recommended Operating Conditions ................29 DC Electrical Characteristics ..................29 Power Consumption ....................... 29 Operating Temperature Ranges..................30 ACCESSORIES ........................ 31 Revised May 2011 SB-A510 Rev 1.1...
- Page 5 May 2011 Fixed table 4, Jumper E8 description fixed. Please check for a newer revision of this manual at CompuLab's web site – http://www.compulab.co.il/ Compare the revision notes of the updated manual from the web site to those of the printed or electronic version you have.
-
Page 6: Introduction
This document is part of a set of reference documents providing information necessary to operate and program CompuLab’s SBC-A510. Related Documents For additional information not covered in this manual, please refer to the documents listed in Table 2. Table 2 Related Documents Document Location CM-A510 Product Developer Resources http://www.compulab.co.il/ Revised May 2011 SB-A510 Rev 1.1... -
Page 7: Overview
CM-A510 single board computer. It is implemented module and a SB-A510 baseboard. with a CM-A510 module providing most of Micro-ATX form factor. the functions, and a SB-A510 carrier board providing standard connectors and Marvell Armada 510 SoC @1000MHz ... -
Page 8: Block Diagram
All manuals and user guides at all-guides.com Block Diagram Figure 1 SB-A510 Block Diagram b a c k-u p S te re o o u t c o in c e ll b a tte ry R T C a u d io... -
Page 9: Features
All manuals and user guides at all-guides.com Features SB-A510 does not have assembly options. The "CM Option" column specifies the P/N code of CM- A510 required to have the particular feature. "+" means that the feature is always available, regardless of P/N code. - Page 10 -40o to 85o C Storage temperature -40o to 85o C 10% to 90% (operation) Relative humidity 05% to 95% (storage) Shock 50G / 20 ms Vibration 20G / 0 - 600 Hz MTBF > 100,000 hours Revised May 2011 SB-A510 Rev 1.1...
-
Page 11: System Components
Low power mode – only power rails required for sleep-mode support are enabled. All other voltage rails are disabled (gated). SB-A510 power state is controlled by the CM-A510 “STBY_PWRDWN” signal, available on pin 37 of connector P1. Table 5... -
Page 12: Dvi Transmitter
Interfaces and Connectors DVI Transmitter The SB-A510 is equipped with a DVI Transmitter that is based on the TFP410/SIL164 IC. DVI output signals are routed to the onboard HDMI Connector (J4). The DVI Transmitter is connected to the 24bit RGB interface of the CM-A510. -
Page 13: Back-Up Battery
All manuals and user guides at all-guides.com Interfaces and Connectors Back-Up Battery SB-A510 is supplied with a 3V 200mAh Lithium Dioxide coin cell, which powers the CM-A510 RTC whenever the main power supply is not present. 4 .22 NOTE: The E5 jumper must be installed for RTC back-up support. Please refer to chapter for additional details. -
Page 14: Interfaces And Connectors
15-02037-R Mating with power supply adapter 209C10020 supplied by CompuLab. RS232 connector (P10) The RS232 port of the CM-A510 is routed to the SB-A510 on-board RS232 ultra-mini connector (P10). All signals are at RS232 levels. Table 9 P10 connector pinout... -
Page 15: Usb Host Connectors (P11, P15)
54F-10202GDD2 Standard USB type A plug Gigabit Ethernet Connectors (P11, P15) The SB-A510 is equipped with two Gigabit Ethernet RJ45 connectors (P11 & P15). P11 is interfaced with the CM-A510 LAN0 port, and P15 with the LAN1 port. Table 14... -
Page 16: Analog Vga Connector (P7)
Ethernet configuration option. Analog VGA connector (P7) The SB-A510 is equipped with an analog VGA output connector (P7). P7 is connected to the CM- A510 analog VGA output, and provides a standard VGA DB-15 interface for PC monitors. The DSUB_I2C2_SCL and DSUB_I2C2_SDA signals are routed to the CM-A510 I2C port 2 signals and serve as a DDC host interface. -
Page 17: Dvi Connector (J4)
Interfaces and Connectors DVI Connector (J4) The SB-A510 is equipped with a standard HDMI socket (J4) providing a DVI interface. The on-board DVI transmitter IC drives the DVI signals through the HDMI socket. For additional details, please refer to section 3 .2 of this document. -
Page 18: Lcd Fpc (P13)
Interfaces and Connectors LCD FPC (P13) The on-board LCD FPC connector (P13) allows easy integration with custom LCD panels. The CABFPC40 and CONLCD-GEN accessories (supplied by CompuLab) provide a generic 100-mil 7 header connection. For additional details, please refer to section of this document. -
Page 19: Lvds Header (P9)
4.10 Touch Screen Header (P12) The touch screen (P12) header of the SB-A510 allows evaluating any resistive touch panel with the touch panel interface provided by the CM-A510. Please refer to the CM-A510 reference guide for additional details on the touch-screen interface. -
Page 20: Power Output Terminals (P17, P19)
All manuals and user guides at all-guides.com Interfaces and Connectors 4.11 Power Output Terminals (P17, P19) The SB-A510 is equipped with two power output terminals. The power output terminals (P17 & P19) are provided for the S-ATA hard drive power supply. Table 24 P17 connector pinout... -
Page 21: S/Pdif Connectors (P22, U6)
Mating connector Hosiden JPJ1225-01-040 Standard EIAJ-RC-5231 plug. Table 30 U6 optical transmitter pinout Signal Name VCC3_3 SPDIF_OUT_OPT Table 31 U6 connector data Manufacturer Mfg. P/N Mating connector EVERLIGHT PLT133/T Standard plastic optic fiber cable Revised May 2011 SB-A510 Rev 1.1... -
Page 22: Compulab Video Input Fpc (P25)
All manuals and user guides at all-guides.com Interfaces and Connectors 4.14 CompuLab Video Input FPC (P25) The on-board CompuLab Video Input FPC connector (P25) allows direct integration with the CompuLab Video Input module. P25 is connected to the CM-A510 Camera interface. Table 32 P25 connector pinout... -
Page 23: Mmc/Sd/Sdio Socket (P5)
MMC_WP SD0_CLK/GPIO40 SD0_DATA0/GPIO42 SD0_DATA1/GPIO43 4.16 Audio Jacks (J1, J3) The SB-A510 features two 3.5mm jacks, one for stereo headphone output (J1) and the other (J3) for stereo audio input. Table 35 J1 connector pinout Signal Name Mating plug pin Jack pin-out... -
Page 24: Misc. Signals Headers (P14, P21)
ARM JTAG header pinout (AKA ARM-20). The JTAG signals are referenced to 3V3SBY voltage levels. Table 40 P16 connector pinout Signal Name Signal Name 0V3SBY JTAG_RTCK 0V3SBY JTAG_nTRST JTAG_TDO JTAG_TDI SYSRST_INn JTAG_TMS_CPU JTAG_CLK Revised May 2011 SB-A510 Rev 1.1... -
Page 25: Boot Source Button (Sw1)
4.20 Reset Button (SW2) The SB-A510 features a user-accessible reset button (SW2). Pressing the reset button issues a cold reset to the CM-A510. 4.21 Suspend/Resume Button (SW3) To be added in a future revision of this document. -
Page 26: Jumpers
All manuals and user guides at all-guides.com Interfaces and Connectors 4.22 Jumpers The SB-A510 jumpers configure SB-A510 sub-systems and CM-A510 operation modes. The table below summarizes all jumpers and their possible configurations. Table 41 Jumpers description Jumper Shorted SB-A510 Description... -
Page 27: Mechanical Drawings
All manuals and user guides at all-guides.com Mechanical Drawings MECHANICAL DRAWINGS Figure 3 SB-A510 top Revised May 2011 SB-A510 Rev 1.1... - Page 28 Mechanical Drawings Figure 4 SB-A510 bottom (X-Ray view - as seen from top side) Mechanical drawings are available in DXF format from CompuLab's website, following [Developer] >> [SB-A510] >> [SB-A510 – schematics, dimension, layout] links. Revised May 2011 SB-A510 Rev 1.1...
-
Page 29: Operational Characteristics
PCI device using 12V through connector P3, the device drawing it’s power from P19 and the range of SB-A510 when no devices use 12V on SB-A510. DC Electrical Characteristics DC electrical characteristics of SB-A510 are derived from the characteristics of the CM-A510. Please refer to the “CM-A510 reference guide”. Power Consumption To be added in a future revision of this document. -
Page 30: Operating Temperature Ranges
Operational Characteristics Operating Temperature Ranges The information in this section refers to the SB-A510 board only. For temperature ranges of off-board components such as the LCD panels or hard drives, please refer to the component’s datasheet. The SB-A510 is available with three options of operating temperature range:... -
Page 31: Accessories
Description Cable, DB9-F to Ultra Mini Plug (USB like), L=2m (RS-232) 199D10170 CABDB9UMP Used to connect the RS232 interface of the SB-A510 to a PC. Connects directly to P12 on the SB-A510. FPC cable, 0.5mm, 40-pos Used with CONLCD-GEN and...
