Cordless Impact
Driver
Equipped with Electric Brake
MODEL BTD042
MODEL BTD062
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
w w w . m a k i t a t o o l s . c o m

Advertisement

Table of Contents
loading

Related Manuals for Makita BTD042

Summary of Contents for Makita BTD042

  • Page 1 Cordless Impact Driver Equipped with Electric Brake MODEL BTD042 MODEL BTD062 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    1. Keep your work area clean and well lit. Cluttered benches and dark areas invite acci- dents. BTD042 4 mm - 8 mm (5/32” - 5/16”) 5 mm - 10 mm (3/16” - 3/8”) 5 mm - 8 mm (3/16” - 5/16”) 0 - 2,500/min.
  • Page 3 Electrical Safety 4. A battery operated tool with integral bat- teries or a separate battery pack must be recharged only with the specified charger for the battery. A charger that may be suit- able for one type of battery may create a risk of fire when used with another battery.

  • Page 4: Specific Safety Rules

    SPECIFIC SAFETY RULES DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to cordless impact driver safety rules. If you use this tool unsafely or incorrectly, you can suffer serious personal injury.
  • Page 5 SYMBOLS The followings show the symbols used for tool. V ... volts ... direct current ... no load speed ˚ IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CARTRIDGE 1. Before using battery cartridge, read all instructions and cautionary markings on (1) battery charger, (2) battery, and (3) product using battery.
  • Page 6 Overcharging shortens the battery service life. 3. Charge the battery cartridge with room temperature at 10°C - 40°C (50°F - 104°F). Let a hot battery cartridge cool down before charging it. 4. Charge the Nickel Metal Hydride battery cartridge when you do not use it for more than six months.

  • Page 7: Functional Description

    When the tool is switched off, the light goes out after approx. 5 seconds. If the battery has not been used for a long time, or is needed refresh charging, the orange lamp begins to flicker. Use Makita refreshing adapter to refresh the battery. CAUTION: •...
  • Page 8 001255 1. Switch trigger 001257 1. Reversing switch lever 001258 Switch action CAUTION: • Before inserting the battery cartridge into the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released. To start the tool, simply pull the switch trigger.
  • Page 9 001259 1. Indicating lamp 2. Switch trigger 3. Battery cartridge 001260 1. Tool housing 2. Screwdriver 001261 1. Pulling the trigger, insert the battery cartridge. Keep on pulling the trigger after inserting the battery cartridge. (The indicating lamp on the back of the tool will flash about 10 times, then the lamp will keep lighting up lit.) 2.
  • Page 10 Presetting number 01 - 99 ASSEMBLY 001266 12 mm 9 mm (15/32”) (3/8”) Example: presetting number is 12. 1. Green color lamp flashes once. 2. Red color lamp flashes two times. 3. The lamp goes out. Relation between presetting number and action Clockwise rotation Auto-stop setting does not work.

  • Page 11: Operation

    001267 1. Bit 2. Sleeve OPERATION 001270 Standard bolt N·m (ft·lbs) (29) (21) M8 (5/16”) (14) (M8) M6 (1/4”) (M6) (13) (25) 1. Number of impacts 2. Dial setting • To install the bit, pull the sleeve in the direction of the arrow and insert the bit into the sleeve as far as it will go.
  • Page 12 001271 High tensile bolt N·m (ft·lbs) (29) (21) (14) M6 (1/4”) (M6) (25) (50) 1. Number of impacts 2. Dial setting 001272 Standard bolt N·m (ft·lbs) M10 (3/8”) (29) (21) (M10) M8 (5/16”) (14) (M8) M6 (1/4”) (M6) (13) (25) 1.

  • Page 13: Maintenance

    CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 14 Memo...
  • Page 15 Memo...
  • Page 16 Memo...
  • Page 17 First-Class Postage Required Post Office will not deliver without proper postage. Makita U.S.A., Inc. 14930 Northam Street La Mirada, CA 90638-5753 Fold...
  • Page 18 Paste 3. How did you learn about this product: Magazine From Dealer Newspaper Store Display Catalog 4. Most favored points are: Design Features Size Price Makita Brand MODEL NO. YEAR SERIAL NO. PHONE 20-29 30-39 40-49 Paste Paste Radio Exhibition...

  • Page 19: Factory Service Centers

    Date Purchased When you need service: Send complete tool (prepaid) to one Dealer’s Name & Address of the Makita Factory Service Centers listed, or to an Authorized Makita Service Center. Be sure to attach a letter to the outside of Model No.

  • Page 20: Warranty Policy

    MAKITA LIMITED ONE YEAR WARRANTY Warranty Policy Every Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase.
