COBY
LOCATION OF CONTROLS
1. PUSH OPEN CLOSE Button
14. HOUR/F.FWD Button
DIGITAL AM/FM ALARM CLOCK
2. ALARM1 Switch
15. Band Selector
RADIO/CD PLAY
3. Function Switch
16. STOP Button
4. CLOCK SET Button
17. PLAY/PAUSE Button
5. RANDOM Button
18. SNOOZE Button
6. PROG Button
19. FUNCTION Lights
88:88
7. REPEAT Button
20. PM Light
8. POWER/ALARM OFF Button
21. ALARM1 Light
9. CD Door
22. Display
10. ALARM2 Switch
23. ALARM2 Light
11. SLEEP Button
24. Dial
12. CD/DISPLAY Buttton
25. TUNING Rotary
13. MIN.REW Button
26. VOLUME Rotary
MODEL NO: CD-RA145
9
1
2
10
3
11
4
12
5
13
6
14
7
8
15
18
17
16
19
20
22
88:88
21
23
Please read instruction manual before use.
24
IMPORTANT SAFEGUARDS
INTRODUCTION
Always operate the product from a power supply of the
same voltage, frequency and rating as indicated on the
Please read and follow the instruction manual carefully be-
product identification plate.
fore operating in order to avoid any damage to the unit.
Do not operate product with a damaged cord or plug.
POWER SUPPLY
Never install the unit where there are heat sources such as
radiators, heat registers, stoves, direct sunlight, excessive
The player operates on AC 110V/60Hz household mains
dust or where there is mechanical vibration or shock. Switch
supply. Before connecting to the power supply, ensure that
off and unplug from AC outlet when not in us
the rated voltage of this unit matches your local voltage.
IMPORTANT
Warning: Disconnect the unit from the main power supply
The CD mechanism and the sensitive circuitry may cause
when not in use.
interference to a radio tuner nearby. Do not operate this
To avoid the risk of electric shock, do not remove
unit while operating other radio devices.
the cover of the apparatus. To prevent fire or
Danger This product utilizes invisible laser
shock hazard, do not expose the apparatus to
radiation. Avoid direct exposure
rain or moisture.
to the beam.
Caution Use of controls, adjustments or procedures
not listed in this manual may result in
BATTERY BACK-UP
hazardous radiation exposure.
A 9V type 006P battery is to be put in the battery
CONCERNING COMPACT DISCS
compartment of the CD room for clock back-up only.
Only compact discs identified with this
Replace the battery every six months.
25
mark can be used with this player.
Remove the battery if the player will not be in use for a
26
long period of time.
CARE AND MAINTENANCE
STANDBY MODE
Handle your unit with care to extend the life of the unit.
Once the player is powered, it goes to the standby mode.
Use a soft and clean cloth damped with plain lukewarm
The system clock will display time under the standby
water to clean the exterior of the unit.
mode. Refer to clock setup section for time setting.
Never use solvents such as benzene or other strong
chemical cleaners since these could damage your unit.
It is important that no liquid reaches the inside of the unit.
Do not touch the CD laser part or look directly at it.
1
2
Snooze to repeat alarm
CLOCK SETUP
1. When alarm comes on you can temporarily turn it off by
1. Plug power cord into power souce.
pressing the SNOOZE button. Approximately 6 minutes
2. The flashing "12:00 " will appear on the screen.
later the alarm will resume. This operation cycle will be
3. Hold down CLOCK SET button by one hand while
repeated up to five times within an hour, and then
by the other hand, press MIN.REW BUTTON to adjust
automatically release the wake up function.
minutes and HOUR.FWD button to adjust hour.
2. To cancel the snooze operation, slide the ALARM1
4. Release CLOCK SET button after adjusting.
switch to "OFF" position
5. The clock starts with the set time.
Time will always be shown on the LCD screen except
RADIO OPERATION
1. Slide FUNCTION switch to RADIO.
for the period of setup execution.
1. Slide FUNCTION switch to RADIO.
If the player is under the standby mode, press POWER
ALARM
SETUP
button to set the player ready for function.
Wake up to Radio/CD /Buzzer
2. Select AM or FM with BAND selector.
Select a means of wake-up by FUNCTION switch before or
3. Get to the desired station by TUNING rotary
after time setting.
4. Adjust the volume with VOLUME rotary
MODE
MEANS OF WAKE UP
5. Extend antenna and adjust the direction to obtain the
Radio mode
Radio broadcasting.
optimum reception.
CD mode
CD playback
6. Press POWER button to get to the standby mode.
Buzzer mode
Beeping.
Sleep Function
If you want to wake to radio or CD playback, select a radio
station or a CD disc and set the volume to a proper level.
Radio broadcasting will last for a preset period of time and
then shut off automatically.
Set Alarm1
1. Slide the ALARM1 switch to SET position.
The system is preset with the following sleep periods :
2. Press MIN.REW button to set minutes and HOUR/F.FWD
90 minutes 60 minutes 30 minutes
1. Repeatedly press SLEEP button till desired sleep period
button to set hours.
appears. Sleep indicator flashes red.
3. Slide the ALARM1 switch to ON position. The ALARM1
2. Sleep function will be activated once the sleep indicator
SET ON indicatior lights up in red.
turns still after a few seconds flashing.
4. The alarm will go off at the set time.
5. To interept alarming, press SNOOZE button.
3. To quit sleep function, pess SLEEP button to select " -- ",
Sleep indicator flashes for a while and then turns off.
6. To stop alarming, press POWER/ALARM OFF button.
Sleep function can be entered under the radio-on mode
6. To disable alarm setting, push the ALARM1 switch to
and the standby mode.
OFF and the ALARM1 SET ON indicator turns off.
At the standby mode, press SLEEP button twice , radio will
Set Alarm 2 (Refer to alarm1 setup)
turns on automatically.
3
4
CD OPERATION
Repeat Mode
1. Press REPEAT button once to repeat currently played
1. Slide the FUNCTION switch to CD.
track. The repeat indicator starts flashing in red.
if it is in the standby mode, press POWER button to set
Press it twice to repeat all tracks, the repeat indicator
the player ready for function
lights red.
2. Press the OPEN/CLOSE button to open the disc door.
2. Keep pressing REPEAT button until repeat indicator
3. Insert a CD disc.
turns off to quit repeat mode.
Play/Stop/Pause
Repeat mode can be entered from both the playback mode
and the stop mode. under the stop mode,press
1. Press PLAY/PAUSE button once to start playback.
PLAY/PAUSE button to get started.
2. Press PLAY/PAUSE button to pause playing.
Random Mode
3. Press PLAY/PAUSE button to resume normal playback
The player will start playback by an random order .
from the pause mode.
Random mode can be entered from both the playback
4. Press STOP button to stop playback.
mode and the stop mode.
5. Always press STOP and wait for a complete stop to
1. Press RANDOM button
remove CD from the player.
2. Random indicator lights red and random play start. If it is
Listen to the desired track
in the stop mode, press PLAY/PAUSE to get started.
1. Press F.FWD button to get to the next track.
3. To quit random mode, just press RANDOM button to
2. Press REW button to get to the previous track.
turn off indicator.
During playback, press REW button once, it will go to the
Program Mode
beginning of the currently played track and press it twice, it
1. Press the PROG button at the stop mode.
will get to the previous one.
P-01 appears on the screen and the PROG indicator
Move to the desired spot
starts flashing in red.
Hold down F.FWD/REW button to search through a disc
2. Press MIN .REW/HOUR/F.FWD button to select track.
and release the button at a desired point.
3. Press PROG button to confirm and P-01turns to P-02. It
View Playback Status
is ready to make next selection.
4. Repeat step 2-3 to edit up to 20 tracks.
Press CD DISPLAY button to view playback status.
The information will show up a few seconds and then
5. Press PROG button to view program list.
change back to the time display.
6. Press PLAY/PAUSE button to start program playback.
Under the stop mode, the screen shows total tracks of a
7. To quit program playback, press STOP button and then
CD disc. If there is no disc loaded, the screen shows " NO"
press PROG button. PROG indicator starts flashing for a
a few seconds and turns off automatically. Or press
Under the playback mode, the screen shows currently
STOP button again while PROG indicator is flashing.
played track .
8. To erase memory, unplug power cord or open the CD
door.
5
6
SPECIFICATION
Power supply-----------------------------110V/60Hz
Back-up battery--------------------------DC 9V
FM--------------------------------------------88-108MHz
AM--------------------------------------------530-1700KHz
Power consumption--------------------5W
Output power-----------------------------1W
Speaker-------------------------------------8 Ohm
7
