Makita AF633 Parts List

ITEM NO. PART NO.
01 A0304-0311 EXHAUST VALVE COLLAR
02 A0103-0091 SAFETY SPRING
03 A0200-1241 O-RING 49*1.8W
04 A0000-0441 NYLOK SCREW 6*45
05 A0005-0021 WASHER #6*1.5t
06 A0301-0241 CYLINDER CAP
07 A0204-0121 HANDLE GRIP
08 A0005-0281 WASHER
09 A0100-0041 COMPRESSION SPRING
10 A0103-0131 SPRING
11 K0300-0521 DISC VALVE ASS'Y
12 A0200-0051 O-RING 13.8*2.4
13 A0200-0311 O-RING 50*2.5
14 A0308-0121 PISTON HEAD
15 A0311-0191 SEAL, AIR
16 K0600-0521 PISTON SET
17 A0200-0131 O-RING 35*3.5
18 K0600-0522 PISTON HEAD&DRIVER BLADE
19 A0601-0221 DRIVER BLADE PISTON
20 A0600-0941 DRIVER BLADE
21 A0305-0041 COLLAR
22 A0200-0561 O-RING 58*3
23 K0300-0381 CYLINDER SET
24 A0200-0371 O-RING 44.5*2.5
25 A0303-0271 CYLINDER
26 A0201-0031 RING
27 A0309-0231 BUMPER
28 A0205-0011 GASKET
29 A0311-0051 SEAL, AIR
30 A0005-0041 E-RING ƒÓ 2.5
31 A0401-0531 BODY
32 A0000-0071 SCREW 5*16
33 A0005-0031 WASHER #5*1.1t
34 A0004-0021 NYLON NUT M5
35 A0205-0021 GASKET
36 A0306-0002 TAIL COVER
AIR PLUG+DUSTER
37A B0300-2641 for MUK
38 A0005-0051 WASHER #4*0.9t
39 A0000-0021 SCREW 4*16
40 A0011-0151 SPRING PIN 3*28
41 A0006-0291 STEP PIN ƒÓ 5*28
42 A0011-0161 SPRING PIN 3*24
43 A0200-0061 O-RING 40*1
44 A0310-0071 NOZZLE WASHER
45 A0302-0011 LOWER COVER
DESCRIPTION
ITEM
PART NO.
NO.
46 A0000-0471 NYLOK SCREW 6*20
47 A0713-0121 OUTLET SITE
48 A0800-0011 STOPPER
49 A0000-0411 NYLOK SCREW 5*20
50 B0800-0011 CLICK LEVER SET
51 A0713-0141 OUTLET SITE COVER
52 A0011-0301 PIN 3*14
53 A0011-0311 PIN 3*22
54 A0712-0191 CATCH GUIDE
55 A0006-0092 PIN 3*14
56 A0100-0761 SPRING
57 A0005-0231 C-RING
58 A0004-0151 SAFETY ADJUSTMENT WHEEL
59 A0711-0661 RELEASE CATCH (B)
60 A0711-0901 JOINTER
61 A0711-0651 RELEASE CATCH (A)
62 A0100-0731 SAFETY SPRING
63 A0009-0011 STEEL BALL
64 A0204-0161 GRIP
65 K0500-0141 TRIGGER VALVE ASS'Y
66 K0500-0051 TRIGGER SET
67 A0204-0091 HANDLE GRIP
68 A0718-0091 TAIL COVER
69 A0000-0181 SCREW 5*10
70 A0706-0461 MAGAZINE SUPPORT
71 A0004-0001 HEX. NUT M5
72 A0702-0231 NAIL RAIL
73 A0000-0221 SCREW 5*8
74 A0712-0211 GUARD COVER
75 A0701-0691 MAGAZINE
76 A0004-0011 NYLON NUT M4
77 A0000-0571 SCREW 4*12
78 A0105-0021 SPRING PLATE
79 A0707-0651 PUSHER
80 A0102-0031 SPRING SET
81 A0005-0211 WASHER
82 A0000-0331 SCREW 5*6
83 A0703-0131 WHEEL GUIDE
84 A0101-0161 SPRING
85 A0707-0741 PUSHER SITE
86 A0006-0451 GUIDE PIN
DESCRIPTION
