PORTABLE CD PLAYER
CX-CD114
The CD mechanism and the sensitive circuitry may cause interference
to a radio tuner nearby. Do not operate this unit while operating other
radio devices.
Danger
This product utilizes invisible laser
radiation. Avoid direct exposure to
the beam.
Caution
Use of controls, adjustments or procedures not listed in
this manual may result in hazardous radiation exposure.
General
Maximum Output (Stereo Headphone..15mW+15mW(32ohm)
Only compact discs identified with this mark can
be used with this player.
DC.................................................. 3V with 2 size "AA" Batteries
5.1"x 1.1"x 5.9"(WHD)
(1)Press PLAY/PAUSE (
the power on.
(2)LCD screen will display "diSC" if CD is not
in the unit.
PRG BUTTON
MODE BUTTON
FF
REW
PLAY/PAUSE BUTTON
OPEN BUTTON
STOP BUTTON
RAN BUTTON
LCD Display
(4)LCD screen will display "Er" if the unit cannot
read CD track data.
(5)When CD track data has been read, LCD
screen will display the last track number
with the total play time.
(6)Unit will start play from track No.1
automatically.
C OM PA C T
Press STOP(
)button to stop play,
DIGITAL AUDIO
and the last track Number will display.
Press PLAY/PAUSE(
)button to pause
on/off alternately.
Time display will flash on pause mode.
)button to turn
BATTERY OPERATION (BATTERIES NOT INCLUDED)
Your unit operates on two(2)AA size alkaline batteries. Open the
CD cover and insert the batteries in the battery compartment
following the polarity diagram located inside.
DC IN JACK
HOLD SWITCH
DBBS SWITCH
114
PHONE JACK
VOLUME CONTROL
BUTTON
BUTTON
During play, press and hold FF
REW
) button to fast forward (or
fast reverse) the current track.
(1) Press FF
(or REW
)button to set the
REPEAT ONE TRACK
desired track# . Press PLAY/PAUSE
(1) Press MODE button once to repeat current track.
button to play. Press FF
(or REW
)
Press FF button
(2) Repeat one indicatior appears.
button to change the track # during the play
mode.
REPEAT ALL TRACKS
(1) Press MODE button twice to repeat all tracks.
(2) Repeat all indicatior appears.
INTRO FUNCTION
(2) During play, press REW
button to play
The player will play each track for a few seconds.
previous track.
(1) Press MODE button the third time,
Press REW button at the head of NO.4
INTRO indicator appears flashing.
(2) Press PLAY/PAUSE button to start INTRO play and
INTRO indicator turns still.
RANDOM FUNCTION
The player will start playback in an random order.
(1) Press RAN button the fourth time,
(3) During pause mode, press FF
(or REW
)
RAND indicator appears flashing.
button to play the next track (or previous track).
(2) Press PLAY/PAUSE button to start RANDOM play .
RAND indicator turns still.
The unit will keep in pause mode and time
display will flash.
NOTE: To quit REPEAT/INTRO/RAN mode, just keep pressing MODE
button till funnction indicator disappears from the screen.
Hearing experts advise against the constant use of personal stereos played
at high volume. Constant high volume use can lead to hearing loss. If you
experience ringing in the ears or hearing loss, discontinue use and seek
medical advice.
. T o remove the disc from its storage case, press down on the center of
the case and lift the disc out. Hold it carefully by the edges as shown
below.
Insert the disc into the unit with the label of the disc facing UP .
Gently wipe the disc using a soft cloth from the center to the outer
direction to remove dust, fingerprints or any other particles on the
disc surface. Never use chemicals, such as record sprays , anti-static
sprays, benzene or thinners to clean the CD. These chemicals can
damage the disc surface permanently.
To avoid serious scratches on CD, keep them in the cases after each
use. Scratches can cause the laser pick-up skip in the future play.
Do not place stickers or write anything on the disc.
PROGRAM PLAY
(or
1. Press PROG button, the screen is read as:
2. Press FF/REW button to get the desired track.
3. Press PROG to confirm, 01turns to 02.
it is ready to make next selection.
1
4. Repeat the above steps to edit up to 20 tracks.
Press PROG button to check program list.
ALL
5. Press PLAY/PAUSE button to start playback.
6. To stop program playback, press STOP button.
7.To erase memory, open the CD door or cut off power.
NOTE: Repeat/Intro function works also under the program play mode.
INTRO
(1)
is displayed when the battery voltage
reaches low.
(2) When the voltage is too low, the unit will
RAND
automatically turn off.
Read the instruction manual before operating this unit.
Do not expose the unit to high temperature or humidity.
Use dampened soft cloth to clean the unit. Do not use strong
detergent or solvent to clean the unit.
Consult your dealer if you are ever in doubt about the
installation, operation or safety of your equipment
DBBS FUNCTION
DBBS FUNCTION
The Dynamic Bass Boost System(DBBS) enhances the
low frequency(Bass) response of the output.
Set the Volume to low listening level and set DBBS switch to ON .
Note: Some CD'S with DBBS may exceed the bass response
capacity and can cause distortion.
To avoid this , do not play DBBS in high volume.
Playing DBBS in high volume may cause damage to the
headphone and more importantly, to your hearing.
