Page 4
Copyright This document and parts thereof must not be reproduced or copied without written permission from ABB, and the contents thereof must not be imparted to a third party, nor used for any unauthorized purpose. The software or hardware described in this document is furnished under a license and may be used, copied, or disclosed only in accordance with the terms of such license.
Page 5
ABB is not liable for any such damages and/or losses.
Page 6
(EMC Directive 2004/108/EC) and concerning electrical equipment for use within specified voltage limits (Low-voltage directive 2006/95/EC). This conformity is the result of tests conducted by ABB in accordance with the product standards EN 50263 and EN 60255-26 for the EMC directive, and with the product standards EN 60255-1 and EN 60255-27 for the low voltage directive.
Page 10
Table of contents LD0.SPCLGGIO1 Multipurpose binary outputs - status (1)...................35 LD0.SPCRGGIO1 Multipurpose binary outputs - status (1)...................36 Physical and raw I/O data............36 LD0.XGGIO100 Physical I/O..........36 LD0.XGGIO110 Physical I/O..........37 LD0.XGGIO120 Physical I/O..........37 Binary outputs...................37 System functions.................38 LD0.LLN0/LPHD1 Reset indications and LEDs, reset device..................38 LD0.DNPGGIO1 Parameter setting group control....38 Switchgear functions..............38...
Page 11
Table of contents CTRL.ESSXSWI2 Earth switch 2, 4-pole (2 bit) position values..................44 Metering and measurand functions..........45 LD0.CMMXU1 Phase currents (1)..........45 LD0.RESCMMXU1 Residual current (1)........45 LD0.CSMSQI1 Sequence of currents........45 LD0.VMMXU1 Voltage measurement ........45 LD0.VMMXU2 Voltage measurement (2).......46 LD0.VSMSQI1 Sequence of voltage measurement....46 LD0.VSMSQI2 Sequence of voltage measurement (2)..47 LD0.PEMMTR1 Power measurement and accumulated power values................47...
Section 1 1MRS757823 A Introduction Section 1 Introduction This manual The point list manual describes the outlook and properties of the data points specific to the IED. The manual should be used in conjunction with the corresponding communication protocol manual. Intended audience This manual addresses the communication system engineer or system integrator responsible for pre-engineering and engineering for communication setup in a...
1.3.2 Document revision history Document revision/date Product version History A/2013-09-17 First release Download the latest documents from the ABB Website http://www.abb.com/substationautomation. 1.3.3 Related documentation Name of the document Document ID DNP3 Communication Protocol Manual 1MRS757820 Symbols and conventions 1.4.1...
Section 1 1MRS757823 A Introduction of a hazard which could result in corruption of software or damage to equipment or property. The information icon alerts the reader of important facts and conditions. The tip icon indicates advice on, for example, how to design your project or how to use a certain function.
Page 16
Section 1 1MRS757823 A Introduction Table 1: Functions included in the IED Function IEC 61850 IEC 60617 IEC-ANSI Protection Three-phase non-directional overcurrent protection, low stage, FPHLPTOC1 3I> (1) 51P-1 (1) instance 1 Three-phase non-directional overcurrent protection, high stage, PHHPTOC1 3I>> (1) 51P-2 (1) instance 1 Three-phase non-directional...
Page 18
Section 1 1MRS757823 A Introduction Function IEC 61850 IEC 60617 IEC-ANSI Disconnector position indication, DCSXSWI1 I <-> O DC (1) I <-> O DC (1) instance 1 Disconnector position indication, DCSXSWI2 I <-> O DC (2) I <-> O DC (2) instance 2 Earthing switch indication, instance 1 ESSXSWI1...
Page 19
Section 1 1MRS757823 A Introduction Function IEC 61850 IEC 60617 IEC-ANSI Time delay off (8 pcs), instance 1 TOFGAPC1 TOF (1) TOF (1) Time delay off (8 pcs), instance 2 TOFGAPC2 TOF (2) TOF (2) Time delay on (8 pcs), instance 1 TONGAPC1 TON (1) TON (1)
Section 2 1MRS757823 A DNP3 data mappings Section 2 DNP3 data mappings Overview This document describes the DNP3 data points and structures available in the IED. The data points are unmapped as a default on the DNP3 level. The point lists describe a superset of all DNP3 data available through the standard configuration/s including the optional functionalities.
Section 2 1MRS757823 A DNP3 data mappings 2.3.1 System functions 2.3.1.1 CTRL.LLN0 Local/remote state (also present in DNP IIN-bits) Table 4: CTRL.LLN0 Local/remote state (also present in DNP IIN-bits) IEC 61850 name SA name Description Values CTRL.LLN0 .Loc.stVal Remote/Local state 0/1=Rem/Loc 2.3.1.2 LD0.LLN0 Settings supervision...
Section 2 1MRS757823 A DNP3 data mappings 2.3.5 Power quality functions 2.3.5.1 LD0.CMHAI1 Power quality - current total demand distortion Table 15: LD0.CMHAI1 Power quality - current total demand distortion IEC 61850 name SA name Description Values LD0.CMHAI1 .Alm.stVal ALARM Distortion alarm 10=Alarm 2.3.5.2...
Section 2 1MRS757823 A DNP3 data mappings 2.3.8.3 LD0.MAPGAPC1 Multipurpose analog protection function (1) Table 64: LD0.MAPGAPC1 Multipurpose analog protection function (1) IEC 61850 name SA name Description Values LD0.MAPGAPC1 .Op.general OPERATE Stage operate 1 = Operate .Str.general START Stage start 1 = Start 2.3.8.4 LD0.MAPGAPC2 Multipurpose analog protection function (2)
Section 2 1MRS757823 A DNP3 data mappings IEC 61850 name SA name Description Values .SPCS06.stVal Output 6 state 0/1=Off/On .SPCS07.stVal Output 7 state 0/1=Off/On .SPCS08.stVal Output 8 state 0/1=Off/On .SPCS09.stVal Output 9 state 0/1=Off/On .SPCS10.stVal Output 10 state 0/1=Off/On .SPCS11.stVal Output 11 state 0/1=Off/On .SPCS12.stVal...
Section 2 1MRS757823 A DNP3 data mappings 2.4.1 System functions 2.4.1.1 LD0.LLN0/LPHD1 Reset indications and LEDs, reset device Table 78: LD0.LLN0/LPHD1 Reset indications and LEDs, reset device IEC 61850 name SA name Description Type LD0.LLN0 .LEDRs1.Oper.ctlVal Reset indications and LEDs .LEDRs2.Oper.ctlVal Reset alarm LEDs LD0.LPHD1...
Section 2 1MRS757823 A DNP3 data mappings 2.4.3 Sensors and monitoring functions 2.4.3.1 LD0.SSCBR1 Reset signals of CB condition monitoring Table 81: LD0.SSCBR1 Reset signals of CB condition monitoring IEC 61850 name SA name Description Type LD0.SSCBR1 .RsAccAPwr.Oper.ctlVal RST_IPOW Reset accum. energy .RsCBWear.Oper.ctlVal RST_CB_WEAR Reset CB life and op.
Section 2 1MRS757823 A DNP3 data mappings 2.4.6 Generic functions 2.4.6.1 LD0.SPCGGIO1 Multipurpose binary outputs (1) The binary outputs can be configured either as pulse- or persistent-type outputs. Pulse- type outputs are triggered with the write value "1". Persistent-type outputs can be written with both values "1"...
Section 2 1MRS757823 A DNP3 data mappings IEC 61850 name SA name Description Type .SPCS04.ctlVal Output 4 control On/Off .SPCS05.ctlVal Output 5 control On/Off .SPCS06.ctlVal Output 6 control On/Off .SPCS07.ctlVal Output 7 control On/Off .SPCS08.ctlVal Output 8 control On/Off .SPCS09.ctlVal Output 9 control On/Off .SPCS10.ctlVal...
Section 2 1MRS757823 A DNP3 data mappings Column name Description Values The value range of the original IEC 61850 data. Scaling is needed to convert floating point data into DNP3 integer values. Scaling type selected as default. Default “R” means ratio scaling. See the DNP3 communication protocol manual for details.
Section 2 1MRS757823 A DNP3 data mappings 2.5.2 Switchgear functions 2.5.2.1 CTRL.CBCSWI1 CB 4-pole (2 bit) position value Table 94: CTRL.CBCSWI1 CB 4-pole (2 bit) position value IEC 61850 name SA name Description Values Arg 1,2,3,4 CTRL.CBCSWI1 Intermediate=0; Off=1; On=2; .Pos.stVal POSITION Bad=3...
Section 2 1MRS757823 A DNP3 data mappings 2.5.3.7 LD0.VSMSQI2 Sequence of voltage measurement (2) Table 105: LD0.VSMSQI2 Sequence of voltage measurement (2) IEC 61850 name SA name Description Values Arg 1,2,3,4 LD0.VSMSQI2 Sequence of voltages 0.00…4.00 .SeqV.c1.cVal.mag I1_DB -Positive magnitude [xUn] 0,4,0,400 0.00…4.00...
Section 2 1MRS757823 A DNP3 data mappings IEC 61850 name SA name Description Values Arg 1,2,3,4 0/1/3=Off/Ok/ .ISCSO3.stVal LED 3 state Alarm 0,3,0,3 0/1/3=Off/Ok/ .ISCSO4.stVal LED 4 state Alarm 0,3,0,3 0/1/3=Off/Ok/ .ISCSO5.stVal LED 5 state Alarm 0,3,0,3 0/1/3=Off/Ok/ .ISCSO6.stVal LED 6 state Alarm 0,3,0,3 0/1/3=Off/Ok/...
Implementation table and the point list tables, provides a complete configuration/interoperability guide for communicating with a device. Table 114: Device profile document DNP3 device profile document Vendor name: ABB Oy Device name: RER615 Highest DNP level supported: Device function: For requests: Level 2+ ○...
Page 58
Section 3 1MRS757823 A DNP3 protocol implementation DNP3 device profile document ○ Sometimes ● Configurable as: "Only when reporting event data", or "When reporting event data or multi-fragment messages" Timeouts while waiting for: Data link ○ None ○ Fixed at ____ ○...
Section 3 1MRS757823 A DNP3 protocol implementation DNP3 device profile document ○ Configurable ○ When device restarts ○ Only certain objects ○ When status flags change ○ Sometimes (attach explanation) ○ ENABLE/DISABLE UNSOLICITED No other options are permitted. function codes supported Default counter object/variation: Counters roll over at: ●...
Page 60
Section 3 1MRS757823 A DNP3 protocol implementation Table 115: Implementation table OBJECT REQUEST (Library will parse) RESPONSE (Library will respond with) Object Variation Function codes Qualifier codes number number Description Function codes (dec) Qualifier codes (hex) (dec) (hex) Binary 1 (read) 00, 01 (start-stop) input –...
Page 61
Section 3 1MRS757823 A DNP3 protocol implementation OBJECT REQUEST (Library will parse) RESPONSE (Library will respond with) 16-bit 1 (read) 00, 01 (start-stop) 129 (response) 00, 01 (start-stop) 2 (default) analog 06 (no range, or all) 17, 28 (index) input 07, 08 (limited qty) 17, 28 (index) 32-bit...
Page 62
Section 3 1MRS757823 A DNP3 protocol implementation OBJECT REQUEST (Library will parse) RESPONSE (Library will respond with) Time delay 129 (response) 07 (limited qty) fine (qty = 1) Not defined Class 0 1 (read) 06 (no range, or all) data Class 1 1 (read) 06 (no range, or all)
Section 4 1MRS757823 A Glossary Section 4 Glossary Application function block library CROB Control relay output block Common time of occurrence. The time and date CTO object is an information object that represents the absolute time of day. DNP3 A distributed network protocol originally developed by Westronic.
Page 68
Contact us ABB Oy Medium Voltage Products, Distribution Automation P.O. Box 699 FI-65101 VAASA, Finland Phone +358 10 22 11 +358 10 22 41094 www.abb.com/substationautomation...
