Mackie 1202 Brochure

12 2 MICRO SERIES MIC/LINE MIXER
x
The
MicroSeries
1202 delivers the
same high performance
electronics and rugged all-
steel construction as its big
brother, the CR-1604. Same
high-headroom and low
noise mic preamplifiers.
Same overall dynamic range.
Same rugged steel construc-
tion with built- in power
supply, thru-hole-plated
fiberglass circuit boards,
gold-plated interconnects
and sealed rotary controls.
The result is a rare combi-
nation of performance and
reliability in a small, very
affordable mixer that is well
suited to serious permanent
installation, video and mo-
bile recording applications.
Big mixer features in
less than one
square foot of space
The MicroSeries 1202
mic/line mixer has:
• A working signal-to-noise
ratio of 90dB, distortion
below 0.009% across the
entire
audio spec-
trum and
116dB inter-
nal dynamic range (that's
26dB better than digital!)
• Switchable phantom-
powered mic inputs with
discrete, balanced micro-
phone preamps as good or
better than those found in
big consoles. Four conju-
gate-pair transistors with
large-emitter geometry re-
duce distortion at all levels,
while delivering extremely
low noise (–129.5 dBm
@150 ohms, 20Hz-20kHz,
with over a 300K band-
width).
• Four mono channels
(each featuring discrete
front-end mic preamp/line
input) and four stereo input
channels (each with sepa-
rate left and right line
inputs).
• Pan control on every
channel.
2/6/98
RELATED PRODUCTS
MS1202 "DUMBO EAR"
RACK BRACKETS
MORE INFORMATION
MS1202 ARCHITECTS' AND
ENGINEERS' SPECIFICATIONS
"IN YOUR FACE"
ALL-PRODUCT BROCHURE
FEATURES
4 low noise/high head-
room mic inputs (–129.5
E.I.N.)
4 bal./unbal. line inputs
4 stereo line inputs
Tape inputs/outputs
2 AUX sends per channel
2 stereo effects (AUX)
returns
Center-detent controls
2-band EQ
Headphone monitor
w/level control
3-way 12-LED peak
meter display
Rugged steel construction
Built-in power supply
Less than 1 square ft.
"footprint"
3-Year Limited Warranty
®
