Important Safety Instructions; Electrical Requirements - Frigidaire FGMC3066UD Installation Instructions Manual

MICROWAVE/ WALL OVEN COMBINATION
Important Notes to the Installer
1. Read all instructions contained in these installation
instructions before installing the combination oven.
2. Remove all packing material from the oven
compartments before connecting the electrical
supply to the wall oven.
3. Observe all governing codes and ordinances.
4. Be sure to leave these instructions with the
consumer.
5. Oven door may be removed to facilitate installation.
6. THIS COMBINATION OVEN IS NOT APPROVED
FOR STACKABLE OR SIDE-BY-SIDE
INSTALLATION.
Important Note to the Consumer
Keep these instructions with your Owner's Guide for
future reference. Do not discard oven removal tools
found in the literature bag.
IMPORTANT SAFETY
INSTRUCTIONS
• Be sure your combination oven is installed and
grounded properly by a qualified installer or service
technician.
• This wall oven must be electrically grounded in
accordance with local codes or, in their absence,
with the National Electrical Code ANSI/NFPA No.70-
latest edition in United Sates, or with CSA Standard
C22.1, Canadian Electrical Code, Part 1, in Canada.
Stepping, leaning or sitting on the door
of this wall oven can result in serious injuries and can
also cause damage to the wall oven.
• Never use your wall oven for warming or heating
the room. Prolonged use of the wall oven without
adequate ventilation can be dangerous.
The electrical power to the oven must be
shut off while line connections are being made. Failure
to do so could result in serious injury or death.
1. Carpentry
Refer to figure 1 for the dimensions applicable to your
appliance, and the space necessary to receive the
combination oven. The oven support surface may be
solid plywood or similar material, however the surface
must be leveled from side to side and from front to
rear.
INSTALLATION INSTRUCTIONS

2. Electrical Requirements

This appliance must be supplied with the proper
voltage and frequency, and connected to an individual,
properly grounded branch circuit, protected by a circuit
breaker or fuse. To know the circuit breaker or fuse
required by your model, see the serial plate to find the
wattage consumption and refer to table A to get the
circuit breaker or fuse amperage.
Observe all governing codes and local ordinances
Appliance Protection
Rating Watts Circuit
240V Recommended
Less than 20A
4800W
4801W - 7200W 30A
7201W - 9600W 40A or 50A
9601W and + 50A
1. A 3-wire or 4-wire single phase 120/240 or 120/208
Volt, 60 Hz AC only electrical supply is required on a
separate circuit fused on both sides of the line (red
and black wires). A time-delay fuse or circuit breaker
is recommended. DO NOT fuse neutral (white wire).
Only certain cooktop models may be installed over
certain built-in electric oven models. Approved
cooktops and built-in ovens are listed by the MFG
ID number (see the insert sheet included in the
literature package).
NOTE: Wire sizes and connections must conform with
the fuse size and rating of the appliance in accordance
with the American National Electrical Code ANSI/NFPA
No. 70-latest edition, or with Canadian CSA Standard
C22.1, Canadian Electrical Code, Part 1, and local
codes and ordinances.
An extension cord should not be used
with this appliance. Such use may result in a fire,
electrical shock, or other personal injury. If you need a
longer power cord you can purchase a 10' (3 m) power
cord kit #903056-9010 by calling the Service Center.
2. These appliances should be connected to the
fused disconnect (or circuit breaker) box through
flexible armored or nonmetallic sheathed cable.
The flexible armored cable extending from the
appliance should be connected directly to the
junction box. The junction box should be located
as shown in Figure 1 and with as much slack as
possible remaining in the cable between the box
and the appliance, so it can be moved if servicing
is ever necessary.
3. A suitable strain relief must be provided to attach
the flexible armored cable to the junction box.
2
Appliance Protection
Rating Watts Circuit
208V Recommended
Less than 20A
4100W
4101W - 6200W 30A
6201W - 8300W 40A or 50A
8301W and + 50A
Figure 2
