COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis :
S15A
Model :
CB5038V5X/XST
CB5073T0X/XEC
CB5073V5X/XST
CB5079T0X/XEC
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
CONTENTS
Precautions
Reference Information

Advertisement

loading

Related Manuals for Samsung CB5038V5X/XST

Summary of Contents for Samsung CB5038V5X/XST

  • Page 1: Table Of Contents

    COLOR TELEVISION RECEIVER Chassis : S15A Model : CB5038V5X/XST CB5073T0X/XEC CB5073V5X/XST CB5079T0X/XEC COLOR TELEVISION RECEIVER CONTENTS Precautions Reference Information Specifications Alignment and Adjustments Troubleshooting Exploded Views and Parts List Electrical Parts List Block Diagrams Wiring Diagram Schematic Diagrams...
  • Page 2 ELECTRONICS © Samsung Electronics Co., Ltd. MAY .2001 Printed in Korea 3S15ASEH-5001...

  • Page 3: Specifications

    Black stripe, 90 degree deflection 21 Inch A51KQJ63X Power Requirements: AC 100~260V, 50/60Hz Antenna Input Impedance: VHF, UHF : Telescopic dipole antenna (75 ohm unbalanced type ) Speaker Impedance 8 ohm, 5W+5W (Dual Type) 16 ohm, 3W (Monitor Type & Dual Type) Samsung Electronics...
  • Page 4 SZM173ER W/O TTX, English/Russian SPM175EE TTX, West : English/German/French/Dutch/Italian/Spanish/Swedish East : English/Czech/Croatian/Romanian/Hungarian/Polish SPM175E TTX, English/French/Swiss SPM175ER TTX, English/Russian/Bulgarian Philips SPM175EP TTX, English/Iranian (TTX) SPM175EA TTX, English/French/Arabian SPM175EG TTX, English/Greek/Yugo IC902 24C04/KS24C040 EEPROM PC801 TCET1108 / LTV817B PHOTO COUPLER Samsung Electronics...
  • Page 5 KS24C040(Pin 8) TRANSISTOR SAW-FILTER TRANSISTOR K2971M K7252M 2SD1651 UPC574J 2SD1650 KSD5072 KSC815-Y KA33V KSD5071 KSA539-Y KSD1711 BC548 KSC5386 KTC9014 E B C TRANSISTOR TDA8133 TDA8356 KSR1012 TDA6101Q KSR1010 KA7630 KSR2010 KTD863-Y E C B Fig. 2-1 Semiconductor Base Diagrams Samsung Electronics...
  • Page 6 Disassembly and reassembly 3. Disassembly and Reassembly 3-1 Back Cover Removal 1. After removing the screws, press the tension rib and pull the cabinet backwards. 2. To reassemble, press the tension rib (see diagram). Samsung Electronics...
  • Page 7 2. Remove the Anode Cap from the CRT. 3. Remove the main board by pulling it with both hands. Warning: The FBT is charged with high voltage. Before removing the Anode Cap, discharge the voltage through one of the heat sinks on the main board. Samsung Electronics...
  • Page 8 Disassembly and reassembly 3-3 Speaker Removal 1. Remove the speaker by pressing the tension rib. 1. Remove the screws. 2. Remove the speaker by pressing the tension rib. Samsung Electronics...
  • Page 9 Always lift the picture tube by grasping it firmly around the faceplate, (2) Never lift the tube by its neck. (3) Do not scratch the picture tube or apply excessive pressure. Fractures of the glass may cause an implosion. Samsung Electronics...

  • Page 10: Alignment And Adjustments

    “FACTORY” or “Power OFF” keys. 3. Access the Adjustment Mode by pressing the “VOLUME” keys ( Up or Down). The adjust- ment parameters are listed in the accompany- ing table, and selected by pressing the CHAN- NEL keys ( , ). Samsung Electronics...
  • Page 11 0 ~ 63 STEP NTSC SUB COLOR 0 ~ 23 STEP SUB TINT 1 ~ 13 STEP TTX SUB-CONTRAST 0 ~ 63 STEP 16 (Only TTX Model) NOTE : PVS,PVA, PHS, parameters must be aligned using the 50Hz vertical-field rates. Samsung Electronics...
  • Page 12 L (BIT : 0) L (BIT : 0) TDA8842, CK SYSTEM, RCA JACK SYSTEM OSD DISPLAY BYTE 0 : 11 L (BIT : 1) H (BIT : 0) L (BIT : 0) H (BIT : 0) L (BIT : 1) Samsung Electronics...
  • Page 13 PAL : 27KHz (NTSC TABLE) NOT USED (D1 D0 = MUST 00) Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE during no signal 3. BLUE SCREEN ON/OFF 4. TIMER CLOCK ON/OFF 5. No CHILD LOCK Samsung Electronics...
  • Page 14 Function Required: 1. PICTURE OFF (after 15 minutes) during no signal. 2. AUDIO MUTE during no signal. 3. No BLUE SCREEN during no RF signal (Blue Screen during AV). 4. No TIMER. 5. No CHILD LOCK. 6. See "Detailed functions of CF". Samsung Electronics...
  • Page 15 MILD MODE CUSTOM MODE MODE MODE 90/50/50/50 100/50/75/50 90/50/75/50 60/50/50/50 90/50/50/50 Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE during no signal SCREEN available 3. BLUE 4. TIMER available No CHILD LOCK Samsung Electronics...
  • Page 16 PAL : 27 KHz (NTSC TABLE) MUST : DO D1 = 00 Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE during no signal. SCREEN ON/OFF 3. BLUE 4. TIMER (CLOCK ON/OFF) CHILD LOCK ON (always) Samsung Electronics...
  • Page 17 Function Required : 1. PICTURE OFF (after 15 minutes) during no signal. 2. AUDIO MUTE during no signal. BLUE SCREEN ON/OFF. 4. TIMER (CLOCK ON/OFF). 5. No CHILD LOCK → SZM -173ET (16K) : Z90203 WITHOUT LINE STEREO → SZM -173EV (24K) : Z90234 WITH LINE STEREO Samsung Electronics...
  • Page 18 2. Arab (Middle East, Africa) : SPM-175EA : English/French/Arabian Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE (during no signal) 3. No BLUE SCREEN 4. No TIMER 5. No CHILD LOCK Samsung Electronics...
  • Page 19 CUSTOM MODE 90/50/50/50 100/50/50/50 75/55/50/50 60/50/50/50 90/55/25/50 Function Required :1. PICTURE OFF (after 15 minutes) during no signal. 2. AUDIO MUTE (during no signal). 3. No BLUE SCREEN. 4. No TIMER (CLOCK /OFF). 5. No CHILD LOCK 4-10 Samsung Electronics...
  • Page 20 7. Do not attempt to connect or disconnect any wires while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts. 8. To protect against shock hazard, use an isola- tion transformer. Samsung Electronics 4-11...
  • Page 21 STANDARD picture. 4. Adjust the Screen VR (on the FBT) so that the voltage on the oscilloscope becomes 130+2.5V (See Fig. 4-1). 130 2.5V 14, 16" :120 2.5V 20, 21" : 130 2.5V Fig. 4-1 4-12 Samsung Electronics...
  • Page 22 2. Adjust RG,BG so that the levels are suitable to each local area. (c) High-Light Adjustment 1. Set SCT to 55 FL (20”. 21”), 65 FL(14”.16”) in the Factory Service Mode with using CA100. See Fig. 4-4 Samsung Electronics 4-13...
  • Page 23 6-Pole Magnet Movement 4-Pole Magnet Movement Fig. 4-5 Center Convergence Adjustment 4-3-9 VCO Adjustment Set the vco data to 80 (Factory Mode). NOTE : For SZM-173EW and SPM-175E (Western Europe remote control), set the VCO data to 1. 4-14 Samsung Electronics...
  • Page 24 4. Fig. 4-7 4. Adjust with PSL (Vertical-Slope) so that the bottom margin of the picture is 4. Fig. 4-8 5. Adjust with PHS (Horizontal Shift) so that the lion-head pattern and CRT centers are aligned. Samsung Electronics 4-15...
  • Page 25 MEMO 4-16 Samsung Electronics...

  • Page 26: Troubleshooting

    5-1 No Video (Raster On, No Sound) Open the IF Pin of Tuner Measure the Check/Replace Voltage of Each Pin TU01, of TU01 Check IC901 Check/Replace Pins 39, 40 IC901, IC201 See "No Sound" See "No Video" (Video OK) (Sound OK) Samsung Electronics...
  • Page 27 Check/Replace Check IC802 IC802 (KA7630) Pin 9 (5V) Check IC901 Check/Replace Pin 16 (4V). IC901 Check IC901 Check/Replace Pin 18 ; Stand-by : 0V IC901, (µ-com). Normal : 5V Check/Replace Check IC201, IC201, Q401, Q402. Pin 40 (H-out) Samsung Electronics...
  • Page 28 Check/Replace Pin 6 (CVBS) IC201 Check IC201 Pins 19, 20, 21 Check/Replace Check IC201 IC201, Q203 pin 27 (Y-IN) Check IC501 Check/Replace on the CRT PCB IC501 Check/Replace R417, R505 (HEATER 6.3Vrms) D503 (CRT G1 pin) CRT, V999 Samsung Electronics...
  • Page 29 R812, R813 Check/Replace Check IC602 IC602 Check/Replace A/V Front assembly. 5-5 No TTX Check/Replace Check IC901 QT02, IC901 Pins 24 Check IC901 Check/Replace Pin 31,32,33,34,35 IC901 Check IC201 Check/Replace Pin 23, 24, 25, 26 IC201 See No Video Samsung Electronics...

  • Page 30: Exploded Views And Parts List

    Exploded Views & Parts List 6. Exploded Views & Parts List 6-1 5038 Samsung Electronics...
  • Page 31 Exploded Views & Parts List 6-2 5073 Samsung Electronics...
  • Page 32 Exploded Views & Parts List 6-3 5079 Samsung Electronics...

  • Page 33: Electrical Parts List

    Electrical Parts List 7. Electrical Parts List 7-1 CB5038V5X/XST Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY PCB MAIN(OPT) ..2 PC801 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST ..2 IC902 1103-001020 IC-EEPROM;N24C04-WBN6,2x256Kx8Bit,DIP,8P ..2 DZ903 1203-000451 IC-VOLTAGE REGULATOR;33,TO-92,3P,-,PLAST...
  • Page 34 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm ..2 C305 2305-000178 C-FILM,MPEF;10nF,5%,100V,TP,-,5mm ..2 R805 2004-001967 R-METAL(S);68Kohm,1%,1/2W,AA,TP,2.5x6.5m ..2 C207 2305-000196 C-FILM,MPEF;150nF,5%,63V,TP,-,5mm ..2 R301 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6. ..2 C306 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15 ..2 R817 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6. ..2 C239 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..2 R215 2001-001015 R-CARBON;9.1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..2 C413 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm Samsung Electronics...
  • Page 35 2701-000212 INDUCTOR-AXIAL;68uH,10%,3x7mm ..2 EY807 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 L904 2701-000299 INDUCTOR-AXIAL;13UH,10%,2.5X3.4MM ..2 EY808 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 L101 2701-000326 INDUCTOR-AXIAL;560nH,10%,2.3x3.4mm ..2 EY809 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 L809 2701-001032 INDUCTOR-AXIAL;100uH,10%,5x14mm ..2 EY810 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 L810 2701-001032 INDUCTOR-AXIAL;100uH,10%,5x14mm ..2 EY811 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- Samsung Electronics...
  • Page 36 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR ...3 AA61-10162B BRACKET-IC;-,-,SBHG-1,T1.0,-,100,- *AA94-01175A ASSY-CRT;A48KRD82X,+0MG,20,BARE,TVI,(H) ...3 AA62-30150F HEAT-SINK,ES;-,A6063 EXTR,-,WHT,45/31,-, AA03-10029X CRT-COLOR;-,A48KRD82X(H),0mG,20,90deg,5 ..2 C.Y AA27-00002A MAGNET-CONVERGENCE;-,JH291-SC-OB,29.1MM AA27-20003X COIL-DEGAUSSING;-,20,14.4ohm,48T,L2170,E ASSY AA27-50004W DEFLECTION-YOKE;-,DSE-1992LL(1H),20’/A48 AA63-60028A SPACER-DY;NEOPRENE,-,BLK,V0 W12,-,- AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, *AA95-00285A ASSY;-,38_73,S15A,PAL,-,9P AA65-30107A CLAMP-D,COIL;NYLON 66,V2,NTR,-,20~22 INC ..2 QE01 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T Samsung Electronics...
  • Page 37 ...3 H/S301 AA62-30150F HEAT SINK-ES;-,A6063 EXTR,-,WHT,45/31,-,-,- ...3 DZ702 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500mW ...3 0205-000129 GREASE-SILICON;SC102,JAPAN ...3 DZ703 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500mW AA98-60005N ASSY-SUB,PART;SCT15A,MAIN,ALL MODEL,- ...3 DZ704 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500mW ...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63SN/37PB ...3 DZ705 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500mW ...3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,SN63/PB37 ...3 DZ901 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500mW Samsung Electronics...
  • Page 38 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x10mm ...3 R906 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R802 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x10mm ...3 R919 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R307 2003-001026 R-METAL OXIDE(S);180OHM,5%,2W,AF,TP,3.9X ...3 R926 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R825 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x10mm ...3 R927 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R930 2004-000218 R-METAL;10KOHM,1%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 39 2305-000178 C-FILM,MPEF;10nF,5%,100V,TP,-,5mm ...3 L706 2701-000184 INDUCTOR-AXIAL;4.7UH,10%,2.5X3.4MM ...3 C207 2305-000196 C-FILM,MPEF;150NF,5%,63V,TP,-,5MM ...3 L902 2701-000189 INDUCTOR-AXIAL;470NH,10%,2.5X3.4MM ...3 C239 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ...3 L102 2701-000212 INDUCTOR-AXIAL;68uH,10%,3x7mm ...3 C413 2305-000382 C-FILM,MPEF;4.7NF,5%,400V,TP,-,5MM ...3 L809 2701-001032 INDUCTOR-AXIAL;100UH,10%,5X14MM ...3 C306 2305-000285 C-FILM,MPEF;220nF,5%,100V,TP,20x18x11.5,15 ...3 L810 2701-001032 INDUCTOR-AXIAL;100UH,10%,5X14MM Samsung Electronics...
  • Page 40 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- HA99-200022 ASSY-PCB,A/V FRONT(ACI);TSB,S15A ...3 EY831 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ...3 QE01 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,TP,120- ...3 EY303 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ...3 RE05 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 EY304 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ...3 RE03 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 EY820 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ...3 RE04 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 41 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWRCH18 ..2 SPK+CF HA60-020003 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWRCH18 ..2 PA+CF HA60-020008 SCREW-TAPTITE;RWH,+,B,M4,L12,ZPC(YEL),SWRCH1 ..2 CRT+CF HA60-020010 SCREW-ASSY;WC,HH,+,M5,L26.5,SWRCH18A,ZPC( AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,- HA64-300016 CABINET-BACK;DP,5073,HIPS,HB,BLK, ...3 HA01-030017 RESIN-HIPS;NTR,HB,DOW A-TECH,IEC65, ...3 HA01-030001 RESIN;M.BATCH,WILSON 902-BK-60,BLK AA65-30009A CLAMP-FBT;ABS,V0,BLK,-,-,- AA65-30018A CLAMP-WIRE;DONG-A,NYLON-66,-,-,-,DATL-600 HA68-500025 LABEL-RATING;A/P 90G,T0.2,L55,W55,STANDARD HA02-030005 TAPE-INK;WIDTH 55 MM HA68-500021 LABEL-QMS;-,T0.1,L135,W35,WHT,-,- Samsung Electronics...
  • Page 42 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST ..2 R231 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..2 IC902 1103-001020 IC-EEPROM;N24C04-WBN6,2x256Kx8Bit,DIP,8P ..2 R611 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..2 DZ903 1203-000451 IC-VOLTAGE REGULATOR;33,TO-92,3P,-,PLAST ..2 R706 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..2 DZ803 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL ..2 R218 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..2 IC802 1203-001531 IC-POSI.FIXED REG.;7630,SIP,10P,-,PLASTI 7-10 Samsung Electronics...
  • Page 43 R-FUSIBLE(S);1ohm,5%,2W,AA,TP,3.9x10mm ..2 C201 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..2 R821 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm ..2 C914 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..2 R814 2008-000267 R-FUSIBLE(S);2.4ohm,5%,2W,AA,TP,3.9x10mm ..2 C915 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..2 R815 2008-000267 R-FUSIBLE(S);2.4ohm,5%,2W,AA,TP,3.9x10mm ..2 C416 2306-000195 C-FILM,MPPF;360nF,5%,400V,TP,26x19x11.5, ..2 R820 2008-000299 R-FUSIBLE(S);47ohm,5%,2W,AF,TP,3.9x10mm ..2 C409 2306-000253 C-FILM,MPPF;7.2nF,5%,1.6KV,TP,28.5x18.5x Samsung Electronics 7-11...
  • Page 44 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- ..2 EY816 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 Z204 2903-000184 FILTER-CERAMIC;BP,5.5MHz,120KHz,6dB,-,TP ..2 EY817 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 Z205 2903-000189 FILTER-CERAMIC;BP,5.74MHz,100KHz,8dB,-,T ..2 EY818 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 Z210 2903-000189 FILTER-CERAMIC;BP,5.74MHz,100KHz,8dB,-,T ..2 EY819 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ..2 Z202 2903-001019 FILTER-CERAMIC;BR,5.5MHz,-,-,-,TP,- ..2 EY822 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- 7-12 Samsung Electronics...
  • Page 45 ASSY POWER CORD ..2 RE04 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..2 RE01 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M ..2 RE02 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M *AA96-00283A ASSY POWER CORD;-,KJ-10,SPT-2,EP2,H/C250 ..2 CE07 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF,20%,16V,Y5P,TP AA39-10003K POWER-CORD;-,KJ-10,SPT-2,2.4m,-,UL/CSA ..2 CE06 2202-000862 C-CERAMIC,MLC-AXIAL;390pF,10%,50V,Y5P,TP ..2 CE03 2401-001264 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 ..2 CE01 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 Samsung Electronics 7-13...
  • Page 46 ...3 DZ705 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500mW AA98-60005N ASSY-SUB,PART;SCT15A,MAIN,ALL MODEL,- ...3 DZ901 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500mW ...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63SN/37PB ...3 DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,DO- ...3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,SN63/PB37 ...3 DZ302 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,TP ...3 0204-000442 SOLVENT;1M-1000,C3H70H,96,- ...3 Q703 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,TP,120- ...3 0204-001024 FLUX;DF-98TVS,-,20%,- 7-14 Samsung Electronics...
  • Page 47 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R931 2004-000218 R-METAL;10KOHM,1%,1/8W,AA,TP,1.8X3.2MM ...3 R960 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R929 2004-000253 R-METAL;11KOHM,1%,1/8W,AA,TP,1.8X3.2MM ...3 R933 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R912 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R938 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 RA01 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R211 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 R227 2001-000011 R-CARBON;75Kohm,5%,1/8W,AA,TP,1.8x3.2mm Samsung Electronics 7-15...
  • Page 48 C-FILM,MPEF;220nF,5%,100V,TP,20x18x11.5,15 ...3 L809 2701-001032 INDUCTOR-AXIAL;100UH,10%,5X14MM ...3 C205 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm ...3 L810 2701-001032 INDUCTOR-AXIAL;100UH,10%,5X14MM ...3 C206 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm ...3 X202 2801-000226 CRYSTAL-UNIT;3.579545MHz,20ppm,28-AAM,15pF, ...3 C308 2305-000450 C-FILM,MPEF;56NF,5%,100V,TP,-,5MM ...3 X203 2801-003726 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAM,20pF, ...3 C211 2305-000665 C-FILM,MPEF;100NF,5%,63V,TP,7.5X4.0X5.0MM, ...3 X901 2801-001476 CRYSTAL-UNIT;12.0MHz,50ppm,28-ABQ,S,30ohm,T 7-16 Samsung Electronics...
  • Page 49 ...3 LE01 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm ...3 EY821 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- ...3 JE01 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING),1/0.6mm ...3 EL403 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- ...3 JE02 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING),1/0.6mm ...3 EL408 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- ...3 JE03 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING),1/0.6mm ...3 EL501 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- Samsung Electronics 7-17...
  • Page 50 ..2 PA+CF HA60-020008 SCREW-TAPTITE;RWH,+,B,M4,L12,ZPC(YEL),SWRCH1 ..2 CRT+CF HA60-020010 SCREW-ASSY;WC,HH,+,M5,L26.5,SWRCH18A,ZPC( AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,- HA64-300015 CABINET-BACK;DP,5079-5379,HIPS,HB,BLK, ...3 HA01-030017 RESIN-HIPS;NTR,HB,DOW A-TECH,IEC65, ...3 HA01-030001 RESIN;M.BATCH,WILSON 902-BK-60,BLK AA65-30009A CLAMP-FBT;ABS,V0,BLK,-,-,- AA65-30018A CLAMP-WIRE;DONG-A,NYLON-66,-,-,-,DATL-600 HA68-500025 LABEL-RATING;A/P 90G,T0.2,L55,W55,STANDARD HA02-030005 TAPE-INK;WIDTH 55 MM HA68-500021 LABEL-QMS;-,T0.1,L135,W35,WHT,-,- HA02-030006 TAPE-INK; WIDTH 105 MM 7-18 Samsung Electronics...

  • Page 51: Block Diagrams

    TO µ-COM B + 5V HEAT TO CRT 14" FSV-14A001 POWER-CORD DIODE-BRIDGE TO 1CHIP B + 8V D2SB60 TO B + 5V TUNER PRE AMP SAW SWITCHING SWITCH MULTI TO TTX B + 5V REGULATOR U-COM KA7630 16.5V TO TDA8356 HDT B Samsung Electronics...

  • Page 52: Wiring Diagram

    SOUND L IN SOUND L OUT SOUND R IN SOUND R OUT CN602 FRONT VIDEO IN L + OUT L - OUT 21 PIN VIDEO IN R - OUT R + OUT 21 PIN AUDIO IN FRONT AUDIO OUT Samsung Electronics 10-1...

  • Page 53: Schematic Diagrams

    @ @ @ @ @ ? ? @ @ @ @ @ ? ) X ? g @ ? ? @ e ? @ ) X g @ ? ? @ e ? @ @ ) : Power Line : Signal Line Samsung Electronics 11-1...
  • Page 54 @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ ? : Power Line : Signal Line 11-2 Samsung Electronics...
  • Page 55 @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ ? : Power Line : Signal Line Samsung Electronics 11-3...
  • Page 56 : Power Line p a ng h ompon n ad a u y h PRODUCT SAFETY NOT CE n manua Do no d g ad y o h h ough mp op v ng : Signal Line 11-4 Samsung Electronics...
  • Page 57 @ ? e @ ? h f @ @ e ? @ @ ? @ ? e @ ? h f @ @ e ? @ @ ? @ ? e @ ? h f @ @ e ? @ @ ? : Power Line : Signal Line Samsung Electronics 11-5...
  • Page 58 @ @ L ? V 4 @ @ e V 4 @ @ 0 Y e @ @ f @ @ ? @ @ ? ? @ @ ? ? @ @ ? @ @ ? @ @ @ @ @ @ ? V 4 @ @ @ H ? V 4 @ @ 0 Y ? @ @ ? V 4 ) ? V 4 @ @ @ 0 Y e 7 @ H ? e ? V 4 @ @ 0 Y ? h e @ ? : Power Line : Signal Line 11-6 Samsung Electronics...
