  • Page 1 CHAPTER 1 Preface...

  • Page 2: Table Of Contents

    Table of Content Preface Table of Content ... 1-2 Regulations Information ... 1-5 FCC-B Radio Frequency Interference Statement... 1-5 FCC Conditions ... 1-6 Safety Instructions ... 1-7 Safety Guideline for Using Lithium Battery ... 1-9 WEEE Statement ... 1-13 Optical Device Drive Notice ... 1-20 Caution on Using Modem ...
  • Page 3 Right Side View... 2-15 Left Side View... 2-17 Rear Side View ... 2-19 Bottom Side View... 2-20 Getting Started Power Management... 3-2 ECO Engine -- Power Saving Function... 3-2 AC Adapter ... 3-4 Battery Pack ... 3-6 Using the Battery Pack... 3-9 Basic Operations...
  • Page 4 Installing the Express card ... 3-28 Safely Remove Hardware... 3-30 BIOS Setup About BIOS Setup ... 4-2 When to Use BIOS Setup... 4-2 How to Run BIOS Setup... 4-2 Control Keys ... 4-3 BIOS Setup Menu ... 4-4 Main menu... 4-5 Advanced menu ...

  • Page 5: Regulations Information

    Regulations Information FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 6: Fcc Conditions

    w Shield interface cables and AC power cord, if any, must be used in order to comply with the emission limits. FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: n This device may not cause harmful interference.

  • Page 7: Safety Instructions

    Safety Instructions Read the safety instructions carefully and thoroughly. All cautions and warnings on the equipment or user’s manual should be noted. Keep this equipment away from humidity and high temperature. The openings on the enclosure are used for air convection and to prevent the equipment from overheating.
  • Page 8 Place the power cord in a way that people are unlikely to step on it. Do not place anything on top of the power cord. To prevent explosion caused by improper battery replacement, use the same or equivalent type of battery recommended by the manufacturer only.

  • Page 9: Safety Guideline For Using Lithium Battery

    Safety Guideline for Using Lithium Battery (English) CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer’s instructions. (French) (Français) ATTENTION: II y a danger d’ex;losion s’il y a remplacement incorrect de la batterie. Remplacer uniquement avec une batterie du meme type ou d’un type équivalent recommandé...
  • Page 10 1-10 üreticinin talimatlarına göre degerlendiriniz. ΠΡΟΣΟΧΗ: Κίνδυνος έκρηξης εάν η μπαταρία τοποθετηθεί λανθασμένα. Να αντικαθιστάτε μόνο με (Greek) (Ελληνικά) τον ίδιο ή αντίστοιχο τύπο με αυτό που συνιστά ο κατασκευαστής του εξοπλισμού. Να απορρίπτετε τις χρησιμοποιημένες μπαταρίες ως απορρίμματα σύμφωνα με τις οδηγίες του κατασκευαστή. (Polish) (Polski) OSTRZEŻENIE: Nieprawidłowa wymiana może spowodować...
  • Page 11 1-11 권장하는 것과 동일하거나 동등한 배터리로만 교체하십시오. 사용한 배터리는 제조업체의 지침에 따라 폐기하십시오. LƯU Ý: Thay thế pin không tương thích có thể dẫn đến nguy cơ bị nổ. Chỉ thay thế bằng pin cùng (Vietnam) (Tieng Viet) loại hoặc loại tương ứng khuyên dùng bởi nhà sản xuất thiết bị. Vứt bỏ pin đã sử dụng theo hướng dẫn của nhà sản xuất. ข...
  • Page 12 1-12 (Swedish) (Svenska) VARNING: Explosionsfara vid felaktigt batteribyte. typ som rekommenderas av apparattillverkaren. (Finnish) (Suomi) VAROITUS: Paristo voi räjähtää, jos se on virheellisesti asennettu. valmistajan suosittelemaan tyyppiin. (Slovak) (Slovensky/Slovenčina) výbuchu. Vymeňte iba za rovnakú batériu alebo za rovnocenný typ batérie, ktorý odporúča výrobca zariadenia. Batérie zneškodnite podľa pokynov výrobcu.

  • Page 13: Weee Statement

    1-13 (Estonia) (Eesti) ETTEVAATUST! Plahvatusoht, kui aku on valesti paigaldatud. Asendage ainult sama või tootja poolt soovitatud võrdväärse akuga. Hävitage kasutatud aku vastavalt tootja juhistele. ‫در ﺻﻮرت ﺗﻌﻮﯾﺾ ﺑﺎﺗﺮی، ﺗﻨﮭﺎ از ﺑﺎﺗﺮﯾﮭﺎی ﭘﯿﺸﻨﮭﺎدی ﺷﺮﮐﺖ ﺗﻮﻟﯿﺪ ﮐﻨﻨﺪه‬ ‫ﻣﻦ ﻗﺒﻞ‬ ‫ﺑﮫ‬ ‫ﻓﻘﻂ ﺑﻨﻔﺲ أو ﻧﻮع ﻣﻜﺎﻓﺊ أوﺻﻰ‬ WEEE Statement (English) Under the European Union ("EU") Directive on Waste Electrical and Electronic Equipment, Directive...
  • Page 14 1-14 Gemäß der Richtlinie 2002/96/EG über Elektro- und Elektronik-Altgeräte dürfen Elektro- und (German) (Deutsch) Elektronik-Altgeräte nicht mehr als kommunale Abfälle entsorgt werden, die sich auf 13.August, 2005 wirken. Und der Hersteller von bedeckt Elektronik-Altgeräte gesetzlich zur gebrachten Produkte am Ende seines Baruchbarkeitsdauer zurückzunehmen.
  • Page 15 1-15 Σύμφωνα με την Οδηγία 2002/96/ΕΚ της Ευρωπαϊκής Ένωσης («ΕΕ») περί Απόρριψης Ηλεκτρικού (Greek) (Ελληνικά) και Ηλεκτρονικού Εξοπλισμού (WEEE), η οποία λαμβάνει ισχύ στις 13 Αυγούστου 2005, τα προϊόντα «ηλεκτρικού και ηλεκτρονικού εξοπλισμού» δεν είναι δυνατόν να απορριφθούν πλέον ως κοινά απορρίμματα και οι κατασκευαστές κεκαλυμμένου...
  • Page 16 1-16 文规定「电机电子设备产品」不可再以都市废弃物处理，且所有相关电子设备制造商，均须在产品使用寿命结束后进行回 收。 (Japanese) (日本語) (Japanese) (日本語) 2005 年 8 月 13 日以降に EU 加盟国を流通する電気・電子製品には WEEE 指令によ りゴミ箱に×印のリサイクルマークの表示が義務づけられており、廃棄物として捨てることの禁止とリサイクルが義務づけられて います。 2005 년 8 월 13 일자로 시행된 폐전기전자제품에 대한 유럽연합("EU") 지침, 지침 2002/96/EC 에 (Korean) (한국어) 의거하여, "전기전자제품"은 일반 쓰레기로 폐기할 수 없으며 제품의 수명이 다하면 해당 전자제품의 제조업체가 이러한...
  • Page 17 1-17 koja stupa na snagu od 13. Avgusta 2005, proizvodi koji spadaju pod "elektronsku i električnu opremu" ne mogu više biti odbačeni kao običan otpad i proizvođači ove opreme biće prinuđeni da uzmu natrag ove proizvode na kraju njihovog uobičajenog veka trajanja. (Netherlands) (Nederlands) De richtlijn van de Europese Unie (EU) met betrekking tot Vervuiling van Electrische en...
  • Page 18 1-18 alaisen sähkö- tai elektroniikkalaitteen valmistajan on otettava laitteet takaisin niiden käyttöiän päättyessä. Na základe smernice Európskej únie („EU“) o elektrických a elektronickýc h (Slovak) (Slovensky/ Slovenčina) zariadeniach číslo 2002/96/ES, ktorá vstúpila do platnosti 13. augusta 2005, výrobky, ktorými sú „elektrické a elektronické zariadenia”...
  • Page 19 1-19 (Croatian) (Hrvatski) U okviru Direktive Europske Unije ("EU") o Otpadnim električnim i elektronički m uređaji ma, Direktiva 2002/96/EC, koja je na snazi od 13. kolovoza 2005., "električni i elektronički uređaji" se ne smiju više bacati zajedno s kućni m otpadom i proizvođači su obvezni zbrinuti takve proizvode na kraju njihovog životnog vijeka. (Estonia) (Eesti) Vastavalt Euroopa Liidu ("EL") direktiivile 2002/96/EÜ...

  • Page 20: Optical Device Drive Notice

    1-20 Optical Device Drive Notice CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest “AUTHORIZED service station.”...

  • Page 21: Trademarks

    1-21 Trademarks n All trademarks are the properties of their respective owners. ® n AMD is a registered trademarks of AMD ® ® n Intel and Pentium are registered trademarks of Intel Corporation. ® n Microsoft is a registered trademark of Microsoft Corporation. Windows registered trademarks of Microsoft Corporation.

  • Page 22: Introductions

    CHAPTER 2 Introductions...

  • Page 23: Manual Map

    Congratulations on becoming a user of this notebook, the finely designed notebook. This brand-new exquisite notebook will give you a delightful and professional experience in using notebook. We are proud to tell our users that this notebook is thoroughly tested and certified by our reputation for unsurpassed dependability and customer satisfaction Manual Map This User’s Manual provides instructions and illustrations on how to operate this notebook.

  • Page 24: Unpacking

    Chapter 4, BIOS Setup, provides information on BIOS Setup program and allows you to configure the system for optimum use. Unpacking First, unpack the shipping carton and check all items carefully. If any item contained is damaged or missing, please contact your local dealer immediately. Also, keep the box and packing materials in case you need to ship the unit in the future.

  • Page 25: Specification

    Specification Physical Characteristic Dimension Weight Processor Type Support Processor L2 Cache FSB Speed Core Chips North Bridge South Bridge Memory Technology Memory Maximum 358 (W) x 259 (D) x 27~31 (H) mm 2.6 kg Micro-FCPGA (478pin) ® Intel Merom Core 2 Duo / Penryn 6MB/ 3MB 1066 MHz ®...
  • Page 26 Power AC Adapter Battery Type RTC Battery Storage HDD form factor Optical Device I/O Port Monitor (VGA) Mic-in Line-in RJ11 RJ45 Internal Microphone Headphone Out Card Reader 65W, 19V 6 cells / 9 cells 2.5”, 9.5mm High, 5400rpm 60 / 80 / 100 / 120 GB Super Multi/ DVD Combo (Devices listed here may vary without notice) RGB D-Sub x 1...
  • Page 27 Communication Port (Items listed here may vary without notice) 56K Fax/MODEM PCI LAN PTT Approval Wake on LAN Wake on Ring Wireless LAN Bluetooth Express Card Slot Display LCD Type Brightness Video Graphics LCD Resolution CRT Output MDC v1.5 Giga LAN Support Support Express Card Slot x 1...
  • Page 28 WebCam CMOS Audio Sound Controller Sound Codec chip Internal Speaker Internal Microphone Sound Volume Software & BIOS USB Flash Boot BIOS Others Kensington Lock Hole Compliance 1.3 Mega Pixel ® Realtek ALC888 Azalia Interface 2 speakers Adjust by volume button, K/B hot-key & SW Yes, USB floppy boot up DOS only Fast Boot Support --- Yes WHQL...

  • Page 29: Product Overview

    Product Overview This section provides the description of basic aspects of the notebook. It will help you to know more about the appearance of this notebook before using it. Please be aware that the notebook shown in this section may vary from the actual one that users purchased. Top-open View Press the Cover Latch to open the Display Panel.
  • Page 30 Rubber Pads This is to protect your notebook from random closing. WebCam This built-in webcam can be used for picture taking, video recoding or conferencing, and any other interactive applications. Cover Latch This is a bounce-back device to fasten the display panel on the main deck of the notebook in closed position.
  • Page 31 2-10 WLAN & BT Press this button to activate the Internet browser. Internet Press this button to turn the Webcam function on or off. Webcam 6. Power Button / Power LED Power Button：Press the power button to turn the notebook power ON and OFF.
  • Page 32 2-11 w Glowing green and blue at the same time when Wireless LAN and w LED goes out when all functions are disabled. w Note: For flight safety consideration, make sure this LED goes out Scroll Lock: Glowing blue when the Scroll Lock function is activated. Caps Lock: Glowing blue when the Caps Lock function is activated.
  • Page 33 2-12 Power On/ Off/ Suspend: w Blinking blue when the system is in suspend mode. w Glowing blue when the system is activated. w LED goes out when the system is turned off.

  • Page 34: Front View

    2-13 Front View 1. Cover Latch This is a bounce-back device to fasten the display panel on the main deck of the notebook in closed position. 2. Card Reader The built-in card reader may support various types of memory card, such as MMC (Multi-Media Card), XD (eXtreme Digital), SD (Secure Digital), SDHC (SD High Capacity), MS (Memory Stick) or MS Pro (Memory Stick Pro) cards.
  • Page 35 2-14 Line Out: A connector for speakers or headphones. Microphone: Used for an external microphone. Line In: Used for an external audio device.

  • Page 36: Right Side View

    2-15 Right Side View 1. Express Card Slot The notebook provides an Express Card slot. The new Express Card interface is smaller and faster than PC Card interface. The Express Card technology takes advantage of the scalable, high-bandwidth serial PCI Express and USB 2.0 interfaces. 2.
  • Page 37 2-16 4. Power Connector To connect the AC adapter and supply power for the notebook.

  • Page 38: Left Side View

    2-17 Left Side View 1. Kensington Lock This notebook provides a Kensington Lock hole, which allows users to secure the notebook in place with a key or some mechanical PIN device and attached through a rubberised metal cable. The end of the cable has a small loop which allows the whole cable to be looped around a permanent object, such as a heavy table or other similar equipment, thus securing the notebook in place.
  • Page 39 2-18 4. USB Port The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the mouse, keyboard, modem, portable hard disk module, printer and more. 5. Optical Device Drive w A slim DVD Super Multi (DVD Dual and DVD RAM) or DVD Combo drive is available in this notebook, depending on the model you purchased.

  • Page 40: Rear Side View

    2-19 Rear Side View 1. Kensington Lock This notebook provides a Kensington Lock hole, which allows users to secure the notebook in place with a key or some mechanical PIN device and attached through a rubberised metal cable. The end of the cable has a small loop which allows the whole cable to be looped around a permanent object, such as a heavy table or other similar equipment, thus securing the notebook in place.

  • Page 41: Bottom Side View

    2-20 Bottom Side View 1. Battery Lock/Unlock Button Battery cannot be moved when the button is positioned on lock status. Once the button is slid to unlock position, the battery is removable. 2. Battery Pack This notebook will be powered by the battery pack when the AC adapter is disconnected. 3.

  • Page 42: Getting Started

    CHAPTER 3 Getting Started...

  • Page 43: Power Management

    Power Management ECO Engine -- Power Saving Function ECO Engine, the outstanding and unique power saving function, provides 5 different power saving modes – Gaming mode, Movie mode, Presentation mode, Office mode, and Turbo Battery mode, to extend the battery running time while performing different tasks with this notebook. Touch the ECO quick launch touch sensor repeatedly to switch among these 5 different modes or to turn this ECO Engine off recurrently.
  • Page 44 Presentation Mode Select this mode while performing presentation applications. Office Mode Select this mode while dealing with office documentation tasks. Turbo Battery Mode Select this mode to maximize the battery running time. ECO Engine Disabled...

  • Page 45: Ac Adapter

    AC Adapter Please be noted that it is strongly recommended to connect the AC adapter and use the AC power while using this notebook for the first time. When the AC adapter is connected, the battery is being charged immediately. Note that the AC adapter included in the package is approved for your notebook;...
  • Page 46 Connecting the AC Power 1. Unpack the package to find the AC adapter and power cord. 2. Attach the power cord to the connector of the AC adapter. 3. Plug the DC end of the adapter to the notebook, and the male end of the power cord to the electrical outlet.

  • Page 47: Battery Pack

    Battery Pack This notebook is equipped with a high-capacity Li-ion battery pack. The rechargeable Li-ion battery pack is an internal power source of the notebook. Be aware of that this battery pack may be damaged if users try to disassemble the battery pack on their own.
  • Page 48 Releasing the Battery Pack It is always recommended to have another battery in reserve for enough power supply. Please contact your local dealer to buy a battery pack that is compliant to your notebook. To remove the battery pack, following the steps below: 1.
  • Page 49 Replacing the Battery Pack To insert the battery pack, following the steps below: 1. Use both hands to align and insert battery pack compartment with orientation. 2. Slightly slide and press the battery pack into the right position until the battery back is fastened in the compartment.

  • Page 50: Using The Battery Pack

    Using the Battery Pack Battery Safety Tips Replacing or handling the battery incorrectly may present a risk of fire or explosion, which could cause serious injury. w Only replace the main battery pack with the same or equivalent type of battery. w Do not disassemble, short-circuit or incinerate batteries or store them to temperatures above +60°...
  • Page 51 3-10 Charging the Battery Pack The battery pack can be recharged while it is installed in the notebook. Please pay attention to the following tips before recharging the battery: w If a charged battery pack is not available, save your work and close all running programs and shut down the system or Save-to-Disk.

  • Page 52: Basic Operations

    3-11 Basic Operations If you are a beginner to the notebook, please read the following instructions to assure your own safety, and make yourself comfortable during the operations. Safety and Comfort Tips The notebook is a portable platform that allows you to work anywhere. However, choosing a good workspace is important if you have to work with your notebook for a long period of time.

  • Page 53: Having A Good Work Habit

    3-12 1. Keep your hands and feet with optimal comfort. 2. Adjust the angle and position of LCD panel. 3. Adjust the desk’s height. 4. Sit straight and keep a good posture. 5. Adjust the chair’s height. Having a Good Work Habit Have a good work habit is important if you have to work with your notebook for long periods of time;...

  • Page 54: Knowing The Keyboard

    3-13 Knowing the Keyboard This notebook provides a full-functioned keyboard. categories: Typewriter keys, Cursor keys, Numeric keys and Function keys. The keyboard shown here may vary from the actual one, depending on which county users purchase the notebook. This keyboard can be divided into four Typewriter keys Numeric keys Cursor keys /...
  • Page 55 3-14 Typewriter Keys In addition to providing the major function of the keyboard, these typewrite keys also provide several keys for special purposes, such as [Ctrl,] [Alt,] and [Esc] key. When the lock keys are pressed, the corresponding LEDs will light up to indicate their status: n Num Lock: Press and hold the [Fn] key and press this key to toggle the Num Lock on and off.
  • Page 56 3-15 Cursor Keys The four cursor (arrow) keys and [Home], [PgUp], [PgDn], [End] keys are used to control the cursor movement. Move the cursor left for one space. Move the cursor right for one space. Move the cursor up for one line. Move the cursor down for one line.

  • Page 57: Function Keys

    3-16 Function Keys n Windows Keys You can find the Windows Logo key ( keyboard, which are used to perform Windows-specific functions, such as opening the Start menu and launching the shortcut menu. For more information of the two keys, please refer to your Windows manual or online help.

  • Page 58: Knowing The Touchpad

    3-17 Knowing the Touchpad The touchpad integrated in your notebook is a pointing device that is compatible with standard mouse, allowing you to control the notebook by pointing the location of the cursor on the screen and making selection with its two buttons. 1.
  • Page 59 3-18 Using the Touchpad Read the following description to learn how to use the touchpad: n Configuring the Touchpad You can customize the pointing device to meet your personal needs. For example, if you are a left-handed user, you may want to swap the functions of the two buttons. In addition, you can change the size, shape, moving speed and other advanced features of the cursor on the screen.
  • Page 60 3-19 that your each tap on the touchpad is equivalent to pressing the left button. Tapping twice more rapidly on the touchpad is to execute a double-click. n Drag and Drop You can move files or objects in your notebook by using drag-and-drop. To do so, place the cursor on the desired item and slightly tap twice on the touchpad, and then keep your fingertip in contact with the touchpad on the second tap.

  • Page 61: About Hard Disk Drive

    3-20 About Hard Disk Drive Your notebook is equipped with a 2.5-inch hard disk drive. The hard disk drive is a storage device with much higher speed and larger capacity than other storage devices, such as the floppy disk drive and optical storage device.

  • Page 62: Using The Optical Storage Device

    3-21 Using the Optical Storage Device Your notebook is equipped with an optical storage device. The actual device preinstalled in your notebook depends on the model you purchased. n Super Multi: Works as a multi-functional DVD Dual Drive and a DVD RAM Drive. n DVD Combo Drive: This device allows you to read DVD and CD, and record CD format.
  • Page 63 3-22 Inserting the Disk The following instructions general procedure when operating the optical storage device: Confirm that the disk is placed correctly securely tray before closing the tray. Do not leave the disk tray open. describe the Confirm that the notebook is turned on. Press the eject button on the panel and the disk tray will slide out partially.
  • Page 64 3-23 Removing the Disk Follow the instructions below to remove the disk that is placed in the optical storage device: Press the eject button on the drive’s panel and the disk tray will slide out partially. Gently pull the tray out until fully extended.

  • Page 65: Connecting The External Devices

    3-24 Connecting the External Devices The I/O (input/output) ports on the notebook allow you to connect peripheral devices. All devices listed here are for reference only. Connecting the Peripheral Devices Connecting the USB devices This notebook provides USB ports for connecting various USB devices, such as mouse, keyboard, digital camera, webcam, printer, and external optical storage device, ete..
  • Page 66 3-25 Connecting the External Display Devices This notebook provides a VGA port for connecting a larger display with higher resolution. The 15-pin-D-sub VGA port allows users to connect an external monitor or other standard VGA-compatible device (such as a projector) for a great view of the notebook display. Once the display is connected to the notebook, power on the notebook and the external display should respond by default.

  • Page 67: Connecting The Communication Devices

    3-26 Connecting the Communication Devices Using the LAN The RJ-45 connector of the notebook allows you to connect the LAN (local area network) devices, such as a hub, switch and gateway, to build a network connection. For more instructions or detailed steps on connecting to the LAN, please ask your MIS staff or network manager for help.
  • Page 68 3-27 Using the Modem or Combo Modem The built-in 56Kbps fax/data modem or combo modem (with built-in Bluetooth function) allows you to use a telephone line to communicate with others or to dial-up to connect the Internet. For more instructions or detailed steps on dialing-up through the modem, please consult your MIS staff or Internet service provider (ISP) for help.

  • Page 69: Express Card Installation

    3-28 Express Card Installation This computer provides an Express Card slot. The new Express Card interface is smaller and faster than PC Card interface. The Express Card technology takes advantage of the scalable, high-bandwidth serial PCI Express and USB 2.0 interfaces. The following instruction provides you with a basic installation for the Express Card, including how to install and remove it.
  • Page 70 3-29 Removing the Express Card Installing the Express Card...

  • Page 71: Safely Remove Hardware

    3-30 Safely Remove Hardware When any peripheral device is connected to the notebook, the Safely Remove Hardware icon will appear on the taskbar. Double-click the icon to bring up the Safely Remove Hardware dialog box. You can see all connected peripheral devices here. If you want to remove any of the devices, move the cursor to the device and click Stop.

  • Page 72: Bios Setup

    CHAPTER 4 BIOS Setup...

  • Page 73: About Bios Setup

    About BIOS Setup When to Use BIOS Setup? You may need to run the BIOS Setup when: An error message appears on the screen during the system booting up and is requested to run SETUP. You want to change the default settings for customized features. You want to reload the default BIOS settings.

  • Page 74: Control Keys

    Control Keys You can use only the keyboard to control the cursor in the BIOS Setup Utility. Press left arrow to select one menu title. Press up arrow to select one menu title. 1) Open the selected item to change setting options. 2) Bring up a sub-menu when available.

  • Page 75: Bios Setup Menu

    BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Main Menu Show system overview information about BIOS version, CPU features, memory size and setting of system time and date. Advanced Menu Configure IDE and USB settings.

  • Page 76: Main Menu

    Main Menu System Date This item allows you to set the system date. [day:month:date:year]. Month Date Year System Time This item allows you to set the system time. The system clock will go on no matter you shut down the PC or get into sleep mode. The time format is [hour:minute:second].
  • Page 77 System Information This item provides the information about the firmware, processor, and system memory.

  • Page 78: Advanced Menu

    Advanced Menu Intel(R) SpeedStep(tm) tech. ––--–––This item allows you to enable or disable Intel SpeedStep technology. When set to Disabled, the system always operates in a conserve power mode (the processor works at FSB400-600MHz or FSB533-800MHz). If you want optimize the processor, set this item to Enabled, so that the processor’s speed will be controlled by the use of your operating system and applications.

  • Page 79: Security Menu

    Security Menu Change Supervisor Password When this function is selected, a message box will appear on the screen as below: Type the password, up to six characters in length and press [Enter]. The password typed now will replace any previously set password from CMOS memory.
  • Page 80 To clear a set password, just press [Enter] when you are prompted to enter the password. A message box will show up confirming the password will be disabled. Once the password is disabled, the system will boot and you can enter Setup without entering any password. Supervisor Password allows the user to enter and change the settings of the setup menu;...

  • Page 81: Boot Menu

    4-10 Boot Menu Boot Settings Configuration Configure settings during system boot. Boot Device Priority These items showing the sequence of boot devices where BIOS attempts to load the disk operating system.

  • Page 82: Exit Menu

    4-11 Exit Menu Exit & Save Changes Save the changes you have made and exit the utility. Exit & Discard Changes Exit the utility without saving the changes you have made. Discard Changes Abandon your changes and reload the previous configuration before running the utility.
