Lorex VQ1137H Specifications

HIGH RESOLUTION, INDOOR, ADVANCED IMAGE
SENSOR, COLOR SURVEILLANCE DOME CAMERA
FEATURES
• High resolution image sensor produces 450 TV lines
of resolution
• 3.6mm wide angle lens ideal for most common
surveillance application
• Infrared light filter ensures accurate color
reproduction
• Ideal for indoor locations where night vision is not
required
• Connects easily to a DVR, surveillance system or
TV/monitor

SpECIFICATIONS

Image Sensor:
Video Format:
Effective Pixels:
Resolution:
Scan System:
Sync System:
S/N Ratio:
Iris:
AES Shutter Speed:
Mini Illumination:
Video Output:
Lens/ Lens Mount:
FOV (Diagonal):
Termination:
IR LED/ Night Vision Range:
Power Requirement:
Power Consumption:
Operating Temp Range:
Environmental Rating:
Weight:
VQ1137H
Lorex Technology Inc.
250 Royal Crest Court, Markham,
3700 Koppers Street
Ontario L3R 3S1 Canada.
Baltimore, Maryland 21227, USA.
High Resolution 1/4" Color Image Sensor
NTSC
H: 656, V: 492
450 TV Line
2:1 Interlace
Internal
More than 48dB
AES
1/60~1/50,000 Sec
3.0 Lux
1.0Vpp @ 75 ohm
3.6mm F 2.0/ Fixed
70 degree
BNC
NA
12Vdc
90 mA
-10° ~ 50° C / 14° ~ 122° F
Indoor Only
0.28kg / 0.61lbs
pLUG AND pLAY SECURITY

pACkAGE INFORMATION

UpC:
7-78597-01137-1
package Weight:
O.7kg / 1.6 lbs
package
190mm/7.4" (w) x 95mm/3.7" (d) x
165mm/6.4" (h)
Dimensions:
package Cube:
0.0028 m / 0.101ft
Includes:
Dome camera, 33ft BNC extension
cable, power adaptor
DIMENSIONS
4.72"/120mm
2.96"/
75mm
w w w . l o r e x c c t v . c o m
As our product is subject to continuous improvement, Lorex Technology & subsidiaries
reserve the right to modify product design, specifications & prices without notice and with-
4.72"/
120mm
©2009 Lorex Technology Inc.
out incurring any obligation. E&OE
1-01122009
