Summary of Contents for Boss Audio Systems BV9695B
-
Page 2: Table Of Contents
Congratulations on your purchase of a Boss Audio Systems Multimedia Receiver. It has been designed, engineered and manufactured to bring you the highest level of performance and quality, and will offer you years of entertainment pleasure. Specifications....................1 Safety Notice..................... Accessories....................... -
Page 3: Specifications
Model No. BV9695B Fixed front panel 6.95 inch TFT screen FM/AM radio RBDS A-Link (Screen Mirroring) DVD fully compatible with DVD/VCD/CD/MP3/MPEG4/JPEG Push-To-Talk (PTT) General Front USB and support Micro SD features Bluetooth audio stream and hands-free phone call AUX input... -
Page 4: Safety Notice
Please read and understand the following safety information before operating this unit. WARNING! To ensure safety while driving and to comply with laws, drivers should not watch video or operate the video device while driving. The unit is suitable for 12V power supply (requires grounding). Do not connect it to 24V power supply in trucks or buses, or else it will be damaged. -
Page 5: Accessories
ACCESSORIES/INSTALLATION ACCESSORIES Remote control with a CR2025 battery......Wire harness..............Mounting brackets............Bracket screws ............. Trim ring................ UNIT INSTALLATION Screws Screws Bracket Trim ring 1. Put the 2 brackets to the left and right side of the unit. 2. Use the supplied screws to attach the brackets to the unit. 3. -
Page 6: Wires Connection Description
WIRES CONNECTION DESCRIPTION Description of the Input/Output Interface Fuse (10A) AV Inputs and Ouputs AM/FM Antenna Jack Wire Harness Connector (connects to the supplied wire harness) Audio/Video Inputs and Outputs R.CAM..... Rear Camera Input (Yellow) V-IN.......Video Input (Yellow) SUB1....Subwoofer Output 1 (Green) L-IN......Left Audio Input (White) SUB2.... -
Page 7: Panel Introduction
Micro SD card slot Connect to a Micro SD card for media play. 2 Disc slot 3 Remote sensor Receive signal from the remote control. 4 Built-in Microphone Pick up sound during hands-free calls via Bluetooth connection. Eject the disc. (Push To Talk) Press to access smartphone voice assistant capability via Bluetooth connection. -
Page 8: Remote Control Introduction
: Eject or end a Bluetooth phone call. 11 PBC: During VCD/SVCD play, display or skip the content menu of the disc. : Dial or answer a Bluetooth phone call. 12 Numeric buttons: • Select a title/chapter/track. • In radio mode, select a preset station. •... -
Page 9: Main Menu Operation Instruction
MAIN MENU OPERATION INSTRUCTION MAIN MENU 1 1. Tuner Interface 10:30 2. Bluetooth Streaming Interface 3. DISC Interface 4. Bluetooth Phone Interface TUNER STREAMING DISC PHONE 5. USB Interface Micro SD Interface Front/Rear Camera Interface CAMERAS AV INPUT AV INPUT Interface MAIN MENU 2 10:30 AUX IN Interface... -
Page 10: Access Setup Interface
CAMERA SETTINGS-Menu 2 Camera Trigger Rear Camera Delay Rear Rear Camera Rear Cam Pwr Front Camera Front Cam Pwr 1. Camera Trigger: Touch to select Front/Rear/Off. Select to display the front or rear camera view, or no camera view when reversing. 2. -
Page 11: Tuner Settings
ACCESS SETUP INTERFACE 1. Touch to select whether to output sound from an external amplifier. 2. Startup volume & Starup voice: Set a default volume. If the volume at the last shutdown is less than this volume, the volume at the last shutdown will be used when rebooting;... -
Page 12: About Settings
TUNER OPERATION About SETTINGS –Menu 8 1. Calibrate the touch screen to improve responsiveness and accuracy. Touch the crosshair on the screen each time it appears to calibrate the screen. 2. View version numbers of this product 3. Restore the product to factory settings. 4. -
Page 13: Disc/Cd/Usb/Sd Playback
DISC/CD/USB/MICRO SD PLAYBACK d. PTY (Program Type) Touch an on-screen button to select a program type. The unit will search for the selected program and broadcast it. NOTE: If RBDS is turned off, CT/TA/AF/PTY will not function. DVD MODE OPERATION Touch the “DISC”... -
Page 14: Media Playing Cd Audio
DISC/CD/USB/MICRO SD PLAYBACK MEDIA PLAYING CD AUDIO Touch the “DISC” icon in the main menu to access the CD track playback interface. Show the music’s ID3 information. 2. Skip to the previous song. 3. Change play mode: repeat all, repeat single, sequential play and shuffle play. -
Page 15: Bluetooth Operation
0000. When prompted for password, input 0000 on your mobile phone for Bluetooth connection. e.Bluetooth name for this unit: BOSS AUDIO BV9695B 2. Function area: a.Touch to see the dialing keypad. Users can dial phone numbers and make calls. -
Page 16: Bluetooth Phone Book
BLUETOOTH PHONE BOOK 1. Touch to search for a name or phone number. 2. Touch to sync phonebook. 3. Contact list. BLUETOOTH PHONE CALL HISTORY 1. Touch to sync phone call history. 2. Touch to show missed calls. 3. Touch to show the dialed phone numbers. -
Page 17: A-Link(Screen Mirroring) Operation
A-LINK(SCREEN MIRRORING) OPERATION A-LINK App allows you to mirror the screen of certain Android smartphones on the screen of this unit. Scan either of the QR codes to download the “A-LINK” App in Amazone App Store or Google Play Store and install it to your smartphone. -
Page 18: Steering Wheel Control (Swc)
STEERING WHEEL CONTROL (SWC) SWC INTRODUCTION Steering Wheel Control (SWC) function allows you to operate this unit via an external device (steering wheel control). A third-party adapter must be used in order for this unit to be compatible with your OEM steering wheel controls. -
Page 19: Troubleshooting
TROUBLESHOOTING Media displayed Cause Corrective Action Loading Disc is being read. Disc is dirty. Clean the disc. No Disc/Bad Disc Disc is upside down. Insert the disc in the right way. Unknown Disc Unsupported disc type. Check and change the disc. Error Illegal mechanism operation.
