- Page 1 Edge Keyboard ™ User’s guide...
-
Page 2: Table Of Contents
Contents Welcome Package contents Your diNovo Edge™ keyboard The diNovo Edge keyboard at a glance 6 Installation Configuration Using the diNovo Edge keyboard Tips and troubleshooting Service and support Compliance and FCC statement Logitech® hardware product limited warranty... -
Page 3: Welcome
Welcome Thank you for purchasing the Logitech ® diNovo Edge ™ keyboard. This document provides a comprehensive guide to using your new keyboard with your Macintosh® computer. If you need more information about this product, visit www.logitech.com. -
Page 4: Package Contents
Package contents diNovo Edge keyboard Power supply diNovo Dock/charging station Cleaning cloth Logitech CD-ROM with Logitech Control Center software... -
Page 5: Your Dinovo Edge Keyboard
Your diNovo Edge keyboard The Logitech diNovo Edge keyboard excels at delivering performance, comfort, easy of use, and style, and is an excellent match for your Macintosh computer. Stylishly slim and sleek, the diNovo Edge keyboard simplifies and extends your access to the digital universe with a number of innovative features. -
Page 6: The Dinovo Edge Keyboard At A Glance
The diNovo Edge keyboard at a glance Battery-indicator light Blinks green while charging; lights green for 5 seconds upon connection; glows red when batteries are low Launch sleep mode Media hot keys Mouse left-click Bluetooth status light Launch Front Row Blinks green during connection;... -
Page 7: Installation
• Insert the lower edge of the keyboard into the dock/charging station, lining up the Logitech logo on the keyboard with the logo on the charging station. A full charge takes about four hours and provides up to one month of normal use. - Page 8 Installation Power on • Slide down the power switch on the right edge of the keyboard. The keyboard is on when the orange power indicator is visible next to power icon.
- Page 9 Click the (Set Up New Device) button. The Bluetooth Setup Assistant starts. From the list of Bluetooth devices, select Keyboard, and then click Continue. The Setup Assistant displays a list of Bluetooth keyboards within range of the console. Click + to set up a Bluetooth device...
- Page 10 Logitech diNovo Edge. Select Note: If the diNovo Edge keyboard does not appear in the list of Bluetooth keyboards, turn the keyboard off and then back on to restart the pairing. The Setup Assistant displays a randomly generated passkey. Using your diNovo Edge keyboard, enter the provided passkey and press Return to pair the keyboard with your computer.
- Page 11 Installation Install the Logitech Control Center software Use the Logitech Control Center software to get the most out of your new Logitech diNovo Edge keyboard. This convenient software gives you access to useful shortcuts that increase your productivity, comfort, and enjoyment.
-
Page 12: Configuration
Configuration Using the Logitech Control Center software Use the Logitech Control Center software to adjust tracking speed and reassign function keys. Start the Logitech Control Center software Apple () menu > System Preferences, Choose and then click Logitech Control Center. - Page 13 Configuration Customize keys Keys button. Click the A list of keys and their current assignments appears. Select a key in the Name column. The Details area displays current key settings. Use the provided buttons and pull-down menus to change the action associated with the selected key.
-
Page 14: Using The Dinovo Edge Keyboard
Macintosh computer. Application keys Launch your favorite applications with a single touch. Set preferences for these keys in the Logitech Control Center. (F5–F8) Desktop management Transform your desktop into the ideal space for work and play with one-touch controls for your favorite Macintosh features, including Exposé®,... - Page 15 Using diNovo the Edge keyboard Using the TouchDisc The diNovo Edge keyboard TouchDisc is a revolutionary, easy-to-use controller that combines the features of a touch pad and a scroll wheel. Move the cursor by sliding your finger across the TouchDisc.
- Page 16 Front Row and the diNovo Edge keyboard The perfect companion to Front Row, Apple’s intuitive full-screen media manager, the diNovo Edge keyboard enhances the remote control features provided by the Apple® Remote. Launch Front Row Press the Front Row button on the diNovo Edge keyboard to start the media manager.
- Page 17 Using the diNovo Edge keyboard Playback Media hot keys The media hot keys on your keyboard correspond to the controls on your Apple Remote. Use them to play, pause, skip forward or backward, fast-forward, or rewind. Volume controls During playback, the volume slider on the diNovo Edge keyboard duplicates the functions of the + and –...
- Page 18 Using diNovo Edge Charging the keyboard Use the provided dock/charging station to keep your diNovo Edge keyboard fully charged and ready. Only fours hours of charging gives you up to one month of battery life. A 10-minute charge provides about a day of use.
-
Page 19: Tips And Troubleshooting
If a problem should occur, you can usually solve it quickly in one of the following ways: • When the keyboard makes a connection, the battery indicator light is solid green for five seconds (page 6). If it blinks red, the battery is low;... -
Page 20: Service And Support
Service and support General support For service and discussion forums, visit www.logitech.com/support/ Software downloads Visit www.logitech.com/downloads/ Registering your diNovo Edge keyboard Visit www.logitech.com/register/ Technical support... - Page 21 Service and support Technical support...
-
Page 22: Compliance And Fcc Statement
For more information, please read the Comfort Guidelines located on the Logitech Web site at www.logitech.com/comfort/. These ® guidelines are also available on your hard drive after the product software has been installed (Start/Programs/ Logitech/Mouse and Keyboard/Help Center/ Comfort and safety). - Page 23 Compliance and FCC statements FCC Statement This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 24: Logitech® Hardware Product
Logitech’s entire liability and your exclusive remedy for any breach of warranty shall be, at Logitech’s option, (1) to repair or replace the hardware, or (2) to refund the price paid, provided that the hardware is returned to the point of purchase or such other place as Logitech may direct with a copy of the sales receipt or dated itemized receipt. - Page 26 Apple, Mac, and Macintosh are trademarks of Apple Inc., registered in the U.S. and other countries. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc., and any such use of such marks by logitech is under license.
