LAIA CUTE 12X User Manual

LAIA CUTE 12X/30X
P/N: C12X/30X
User manual
Product looking
1
2
Pack
x1 USB cable x1 Wireless cam
x1 Remote control x1 Wall mount bracket
x1 Visca cable
Product features
3
Full HD resolution
1/2.8 inch high quality CMOS sensor. Resolution is up to 1920x1080
with frame rate up to 60 fps.
Multiple optical zoom lens
12X/30X optical zoom lens to ensure good quality video.
Autofocus technology
Fast, accurate and stable auto focusing technology.
Low noise and high SNR
Super high SNR image is achieved with low noise CMOS. Advanced
2D/3D noise reduction technology further reduces the noise while
ensuring high image clarity.
Multiple video output interfaces
HDMI, USB3.0, LAN. Simultaneously output audio and video signal
via HDMI and LAN. LAN interface support POE, USB 3.0 support
dual code stream.
USB3.0 Support Dual Coding Stream
Support main stream and sub –stream, simultaneous output and
supports YUY2, MJPEG, H.264, NV12, H.265 video coding format.
x1 User manual
x1 Power supply
Copyright © 2020 Laia · www.laiatech.com
Built-in Gravity Sensor: support PTZ auto-flip function and easy
installation.
Multiple Network Protocol: support ONVIF,GB/T28181,RTSP,RTMP,VISCA
OVER IP,IP VISCA,RTMPS,SRT protocols; Support RTMP push
mode,easy to be connected to streaming server (Wowza,FMS); Support
RTP multicast mode.
Control Interface: RS422 is compatible with RS485, RS232-IN, RS232-
OUT, and the RS232 interface supports cascading.
Multiple Control Protocol: Support VISCA,PELCO-D,PELCO-P protocols.
Camera also supports automatic identification protocols.
Quiet Pan / Tilt Movement: with high accuracy step driving motor,
camera can pan / tilt extremely quiet and smooth.
Various remote controls: Users can choose infrared remote control or
wireless remote control according to the environmental conditions used.
The 2.4G wireless remote control is not affected by angle, distance, and
infrared interference. Support the remote control signal transparent
transmission function, which is convenient for back-end equipment to
use.
Multiple Application: Online-education, Lecture Capture, Webcasting,
Video conferencing, Tele-medicine, Unified Communication, Emergency
command and control systems, etc.
4
Safety precautions
Avoid damage to product caused by heavy pressure, strong vibration or
immersion during transportation, storage and installation.
Housing of this product is made of organic materials. Do not expose it to
any liquid, gas or solids which may corrode the shell.
Do not expose the product to rain or moisture.
To prevent the risk of electric shock, do not open the case. Installation
and maintenance should only be carried out by qualified technicians.
Do not use the product beyond the specified temperature, humidity or
power supply specifications.
Wipe it with a soft, dry cloth when cleaning the camera lens. Wipe it
gently with a mild detergent if needed. Do not use strong or corrosive
detergents to avoid scratching the lens and affecting the image.
This product contains no parts which can be maintained by users
themselves. Any damage caused by dismantling the product by user
without permission is not covered by warranty.
Installation and use of this product must strictly comply with local
electrical safety standards.
The power supply of the product is ±12V, the max electrical current is 2A.
Do not rotate the camera head violently, otherwise it may cause
mechanical failure.
This product should be placed on a stable desktop or other horizontal
surface. Do not install the product obliquely, otherwise it may display
inclined image.
Ensure there are no obstacles within rotation range of the holder.
Do not power on before completely installation.
Electromagnetic fields at specific frequencies may affect the video
image. This product is Class A. It may cause radio interference in
household application. Appropriate measure is required.
All rights reserved
