WWW.CANNONDALE.COM
© 2019 Cycling Sports Group
Topstone Owner's Manual Supplement
134949 Rev. 1
Owner's Manual Supplement
CANNONDALE USA
Cycling Sports Group, Inc.
1 Cannondale Way,
READ THIS SUPPLEMENT AND YOUR
Wilton CT, 06897, USA
CANNONDALE BICYCLE OWNER'S MANUAL.
Both contain important safety information. Keep
1-800-726-BIKE (2453)
both for future reference.
www.cannondale.com
CANNONDALE EUROPE
Cycling Sports Group Europe, B.V.
Hanzepoort 27, 7570 GC, Oldenzaal,
Netherlands +41 61 4879380
servicedeskeurope@
cyclingsportsgroup.com
CANNONDALE UK
Cycling Sports Group
Vantage Way, The Fulcrum,
Poole, Dorset, BH12 4NU
+44 (0)1202732288
sales@cyclingsportsgroup.
co.uk
Advertisement
Related Manuals for Cannondale Topstone
Summary of Contents for Cannondale Topstone
- Page 1 WWW.CANNONDALE.COM © 2019 Cycling Sports Group Topstone Owner’s Manual Supplement 134949 Rev. 1 Owner’s Manual Supplement CANNONDALE USA CANNONDALE EUROPE CANNONDALE UK Cycling Sports Group, Inc. Cycling Sports Group Europe, B.V. Cycling Sports Group 1 Cannondale Way, Hanzepoort 27, 7570 GC, Oldenzaal,...
- Page 2 WWW.CANNONDALE.COM Topstone - Owner’s Manual Supplement © 2019 Cycling Sports Group Topstone Owner’s Manual Supplement 134949 Rev. 1 Safety Messages In this supplement, particularly important information is presented in the following ways: Indicates a hazardous situation which, if not avoided, may result in death or serious injury.
- Page 3 Cannondale USA applicable warranties, please coordinate Cycling Sports Group, Inc. all service and maintenance through your 1 Cannondale Way, Wilton CT, 06897, USA Authorized Cannondale Dealer. 1-800-726-BIKE (2453) NOTICE Unauthorized service, maintenance, or Cycling Sports Group Europe B.V...
- Page 4 Topstone - Owner’s Manual Supplement SAFETY INFORMATION Important Composites Inspection & Crash Damage Message Of Carbon Frames/Forks Your bike (frame and components) is After A Crash Or Impact: made from composite materials also Inspect frame carefully for damage. See known as “carbon fiber.”...
- Page 5 Improper mechanical work increases the risk of an accident. Any bicycle accident has risk of serious injury, paralysis or death. To minimize risk we strongly recommend that owners always have mechanical work done by an Authorized Cannondale Dealer. 134949 Rev 2.
- Page 6 Topstone - Owner’s Manual Supplement Trainers Water Bottles If you ride a trainer that requires removal Side impacts to a water bottle or cage can of the front wheel and clamps the fork result in damage to threaded inserts due to dropouts: Be sure your fork quick release is the leverage on a very small area.
- Page 7 Tightening Torques Before building up a frame set, consult with Correct tightening torque for the fasteners your Cannondale Dealer and the component (bolts, screws, nuts) on your bicycle is very manufacturers, and discuss your riding style, important to your safety. Correct tightening...
- Page 8 Topstone - Owner’s Manual Supplement TECHNICAL INFORMATION Frame Specification Item Specification Head Tube UPR: 1-1/8 in, LWR: 1-1/4 in Headset Integrated, 1-1/8 in - 1-1/4 in Bottom Bracket: Type / Width BB30A / 83 mm Front Derailleur Brazed-on Seat Post: Dia./Binder 27.2 mm / Internal Wedge...
- Page 9 English Geometry Seat Tube Length Top Tube Horizontal Head Tube Angle Seat Tube Angle (effective) 75 mm Standover Head Tube Length Wheelbase Front Center Chain Stay Length Bottom Bracket Drop Bottom Bracket Height Fork Rake Trail Stack Reach Dimensions = centimeter/inches Size 41.0/16.1 45.8/18.0...
- Page 10 Topstone - Owner’s Manual Supplement Rear Derailleur Mount Front Derailleur Mount 2 N·m 1. RD Mount 1. FD Mount a. Di2 Frame exit 2. Screw 2. Screws (2X) b. Di2 Mount exit 3. Cover To replace: Serial Number Remove the rear axle.
- Page 11 English Bottom Bracket Cable Guide Identification 1. BB Guide 2. Screw (2X) 3. Di2 Cable Plug 4. Plug a. Drain hole Rear Fender Support Identification Maintain tire clearance with fender. 1. Fender Support 2. Screw (2X) 45mm The wheel rim and tire models, and 2 N·m fender shape used will affect the fender clearance.
- Page 12 NOTICE bearings annually (at a minimum) or anytime the crankset assembly is disassembled, serviced, or if a Consult with your Cannondale Dealer on the problem is indicated. quality and compatibilty of any proposed To inspect, when the crankset is removed, rotate the replacement component.
- Page 13 English Routing Identification FD - Front Derailleur RD - Rear Derailleur RB - Rear Brake SP - Seat post Battery Di2 - Plug 134949 Rev 2.
- Page 14 Topstone - Owner’s Manual Supplement LockR To remove the LockR from the frame: 1. Loosen the screw 4-6 turns using a T25 Torx key. 2. Tap head of screw with a rubber mallet to un-seat the wedge bolt located on the opposite side.
- Page 15 English • Do not install assembled. • Apply grease to all parts. 1 N·m 5 N·m Insert 5mm & Unthread Unthread & dislodge & turn to free Remove tap mallet remove Remove 134949 Rev 2.
- Page 16 Topstone - Owner’s Manual Supplement Seat Tube / Seat Stay Pivot Bearings Pull SS end away from ST just enough to allow REMOVE remove cup (5) to be snapped over M6X30mm screw (7). Remove LockR pivot hardware. Hold M6X30mm screw (7) stationary with 5mm Insert remove plate (4) through ST pivot so it’s...
- Page 17 English REMOVE M6 x 30 mm REMOVE M6 x 70 mm Identification 1. Bearing 5. Remove Cup ST Seat Stay (end) 2. Install Plate 6. Screw M6 x 70mm 3. Tool Handle 7. Screw M6 x 30 mm 4. Remove Plate SS Seat Tube 134949 Rev 2.
- Page 18 Topstone - Owner’s Manual Supplement Seat Binder Identification 1. Wedge 2. Retaining Screw 3. Binder Screw 4. Wedge 5. Frame Pocket Periodically, to maintain the seat binder assembly, it is recommended to: Remove the seat post. Apply grease to the binder screw (3) and thread 2-3 turns into the wedge (4).
- Page 19 “Care and Use the correct seat post length shown Maintenance of Carbon Fiber Seat Posts” above. Do not force or bottom-out the in your Cannondale Bicycle Owner’s seat post inside the frame. Manual. 134949 Rev 2.
- Page 20 Topstone - Owner’s Manual Supplement Sizing a seat post If the seat post must be cut, use the appropriate saw blade for the seat post material, aluminum or carbon. Lightly sand the edges of the cut seat tube with light sandpaper.
- Page 21 English Water Bottle / Fender Mount Fasteners M5 x 1.0 x 25 mm 2 N·m M5 x 1.0 x 12 mm M5 x 1.0 x 16 mm M5 x 1.0 x 16 mm M5 x 1.0 x 16 mm M5 x 1.0 x 25 mm M5 x 1.0 x 25 mm NOTICE •...
- Page 22 2Lead P1.0 Bolt 165L K32079 Blank Frame Plugs (QTY 3) Speed Rel TA 100x12 K83000 K33000 2Lead P1.0 Bolt 119L Topstone Crb Front Derailleur Mount K33010 Topstone Crb Front Derailleur 1X Cover K91010 Kingpin Bearing Install Removal Tool 134949 Rev 2.
- Page 23 WWW.CANNONDALE.COM English © 2019 Cycling Sports Group Topstone Owner’s Manual Supplement 134949 Rev. 1 CANNONDALE USA CANNONDALE EUROPE CANNONDALE UK Cycling Sports Group, Inc. Cycling Sports Group Europe, B.V. Cycling Sports Group 1 Cannondale Way, Hanzepoort 27, 7570 GC, Oldenzaal,...
- Page 24 WWW.CANNONDALE.COM WWW.CANNONDALE.COM © 2019 Cycling Sports Group © 2019 Cycling Sports Group Topstone Owner’s Manual Supplement Topstone Owner’s Manual Supplement 134949 Rev. 1 134949 Rev. 2 CANNONDALE USA CANNONDALE USA CANNONDALE EUROPE CANNONDALE EUROPE CANNONDALE UK CANNONDALE UK Cycling Sports Group, Inc.
