6.1.4.
Buttons
6.1.4.1.
Module Buttons
Mark
A
B
C
6.1.4.2.
UBox Buttons
This section applies to the S5416 server only.
Mark
A
B
C
6-6
Description Guide
Front view
Description
Power-on
Module identification
BMC reset
Front view
Button
Firmware recovery button
Power button
Reset button
Component
Management Board Right Side (MRB)
Management Board Right Side (MRB)
Management Board Right Side (MRB)
Component
LMB module
LMB module
LMB module
