Lexicon, Inc.
DC-2/MC-1 Serial Communications Protocol
Application Header:
Command DC_RESP_EFFECT_PARAM_VALUES
Data Count 1 + EffectParamCount
Application Data:
Data[0] EffectId
Data[1] effect_param_value[0]
Data[...] effect_param_value[...]
Data[DataCount-1] effect_param_value[EffectParamCount-1]
7.3.11.5 Data Description
EffectId:
Data Type:
Max:
effect_param_value:
Data Type:
Max:

7.3.12 Get Custom Name

Request to DC-2/MC-1 for an effect definition. DC-2/MC-1 will respond with "Custom Name Packet".
7.3.12.1 Command Packet Description
Application Header:
Command DC_CMD_GET_CUST_NAME
Data Count 0
Application Data:
N/A
7.3.12.2 Data Description
N/A
7.3.12.3 Custom Name Response Packet
Application Header:
Command
Data Count
Application Data:
Data[0]- Data[DataCount-1]
7.3.12.4 Data Description
CustomName:
Data Type:
Max Length:

7.3.13 Get Input Name by Id

Request to DC-2/MC-1 for an input name. DC-2/MC-1 will respond with "Input Name Packet".
7.3.13.1 Command Packet Description
Unsigned 8 bit integer.
Set by the Effect Count in the "Unit Configuration Packet".
Unsigned 8 bit integer array.
Dependent on the parameter definition
DC_RESP_CUST_NAME
strlen(CustomName) + 1
CustomName
Null(0x00) terminated ASCII character string.
CUSTOM_NAME_LENGTH defined in Appendix E Protocol Constants.
0x87
nn
nn
nn
nn
nn
0x2B
0x00
0x89
nn
ch ch ch ... 0x00
