TP-Link RE220 Quick Start Manual page 4

Specifications
Hardware
· Ethernet Port: 1 10/100Mbps RJ45 Port
· Button: WPS Button, RESET Button
· Antenna: 3 Internal Antennas
· Power Consumption: 6.5W
· Dimensions (W × D × H):
2.6×2.2×4.3 in. (65.8×55.8×110 mm)
For more information, please visit
https://www.tp-link.com/us/products/details/RE220.html
or scan the QR code left
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network
conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.
Wireless
· Wireless Standards:
802.11b/g/n 2.4GHz
· Frequency:
· Signal Rate:
· Transmit Power:
· Reception Sensitivity:
5GHz:
11a 6Mbps: -94dBm, 11a 54Mbps: -79dBm
11ac HT20 MCS0: -94dBm, 11ac HT20 MCS8: -73dBm
11ac HT40 MCS0: -91dBm, 11ac HT40 MCS9: -67dBm
11ac HT80 MCS0: -88dBm, 11ac HT80 MCS9: -64dBm
2.4GHz:
WPS Button
11g 54Mbps: -81dBm, 11n HT20 MCS7: -79dBm
Ethernet Port
11n HT40 MCS7: -76dBm
RESET Button
· Wireless Function:
Wireless Statistics
· Wireless Security:
encryptions
IEEE 802.11a/n/ac 5GHz, IEEE
2.4GHz and 5GHz
300Mbps at 2.4GHz, 433Mbps at 5GHz
≤20dBm
Enable/Disable Wireless Radio,
64/128-bit WEP, WPA/WPA-PSK2
Others
· Certification
FCC, RoHS
· System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or
Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari
4.0, or other Java-enabled browser
· Package Contents
AC750 Wi-Fi Range Extender RE220
Quick Installation Guide
w w w.tp-link.com
TP-Link AC750 Wi-Fi Range Extender RE220
