Section 3-4

Completing the Installation

3-4-1

System Specifications

3-4-1-1 Physical Dimensions of Voluson® 730
The physical dimensions of the Voluson® 730 unit are summarized in
Table 3-6
Table 3-5
145 cm / 57.1 inches
3-4-1-2

Weight without Monitor and Peripherals

Table 3-6
3-4-1-3

Acoustic Noise Output

max. 57dB(A)
3-4-2

Electrical Specifications

Table 3-7
Power Consumption nominal 1010 VA including all options.
Mains outlets: Mains socket ST1, ST2, ST3, ST4, ST5 for accessories.
All mains outlets are co-switched by the unit's mains switch via built-in isolation transformer.
Output voltage for: ST1 - ST5: 115V or 230V.
Modification of voltage setting only by an authorized service person! Output power: 350VA per
CAUTION
mains outlet, max. power of all connected accessories must not exceed 350VA.
3-8
U
RETZTECHNIK LTRASOUND
1
lists the size of Voluson® 730, with monitor and without on-board peripherals.
Physical Dimensions of Voluson® 730
Height
Weight of Voluson® 730 With Monitor and Without Other Peripherals
Model
Voluson® 730
Electrical Specifications for Voluson® 730
Voltage Tolerances
100 VAC ±10%
115 VAC ±10%
130 VAC ±10%
230 VAC ±10%
240 VAC ±10%
Section 3-4 - Completing the Installation
Width
68 cm / 26.8 inches
Weight [kg]
136
Current
10.10 A
8.80 A
7.80 A
4.40 A
4.20 A
V ® 730 S
OLUSON
Table 3-5.
Depth
100 cm / 39.4 inches
Weight [lbs.]
300
Frequency
50, 60 Hz (±2%)
50, 60 Hz (±2%)
50, 60 Hz (±2%)
50, 60 Hz (±2%)
50, 60 Hz (±2%)
