LevelOne SoHoCon FSW1602TX Specifications

Datasheet_FSW-1602TX
LevelOne's FSW-1602TX Fast Ethernet Switch is a wire-speed
and cost-effective networking device that provides 16 ports with
10/100 Mbps Ethernet connections.
dynamic memory allocation with a store-and-forward switching
method to ensure that the buffer is effectively allocated for each
port. It also controls the data flow between transmit and receive
nodes to guarantee against all possible packet loss. All ports
support Auto-MDIX allowing uplinking to another switch
straightly without cable selection hassle.
The FSW-1602TX is ideal to share bandwidth 10Mbps or
100Mbps workgroups with multiple high-speed servers. With
the highest bandwidth at 200Mbps, each port can provide
workstations with congestion-free data-pipes for simultaneous
access to the server.
expandable by cascading two or more switches together and
provide more Ethernet connections.
This unit is small and desktop-sized specially designed to fit in
space-limited locations. Users can immediately use any of the
features of this product simply by attaching the cables and
turning on the power. For instant error detection, the switch is
equipped with a full range of LEDs to help you monitor and
troubleshoot problems on your network.
16-port 10/100BASE Ethernet Switch with RJ-
45 connectors
Supports Auto-negotiation for speed and duplex
modes for each port
Supports Auto-MDI/MDI-X for each port
Store-and-Forward switching method
16-port 10/100 Mbps Compact Switch
This device combines
Furthermore, this device is also
Key Features
one world_one brand_one level_ one world_one brand_one level_
FSW-1602TX
Supports 8K absolute MAC addresses
Supports 512Kbytes RAM for data buffering
Front-panel diagnostic LEDs
IEEE 802.3x flow control for full-duplex
Back pressure flow control for half-duplex
