Selecting a supported display mode

The display mode the monitor uses is controlled by the computer. Therefore, refer to
your computer documentation for details on how to change display modes.
The image size, position and shape might change when the display mode changes.
This is normal and the image can be readjusted using automatic image setup and the
image controls.
Unlike CRT monitors, which require a high refresh rate to minimize flicker, LCD or
Flat Panel technology is inherently flicker-free.
Note: If your system has previously been used with a CRT monitor and is currently
configured to a display mode outside the range of this monitor, you may need to re-
attach the CRT monitor temporarily until you have re-configured the system;
preferably to 1920 x 1080 at 60 Hz, which is the Native Resolution Display mode.
The display modes shown below have been optimized at the factory.
Table 2-3. Factory set display modes
Addressability
NTSC
PAL
640x350
640x480
720x400
800x600
832x624
1152x864
1024x768
1280x720
1280x800
1280x1024
1440x900
1600x900
1680x1050
1680x1050
1920x1080
Refresh rate
60Hz
50Hz
70Hz
60Hz， 72Hz，75Hz
70Hz
56Hz， 60Hz， 72Hz 75Hz
，
75Hz
75Hz
60Hz， 70Hz， 75Hz
60Hz
75Hz
60Hz， 70Hz，75Hz
60Hz， 75Hz
60Hz， 75Hz
60Hz
75Hz（only VGA)
60Hz
2-7
Chapter 2.
