Furuno GC-001 User Manual

GESTURE CONTROLLER
This guide covers safe use and battery replacement for the Gesture Controller. For how to use the GC-001 with your equipment, see
the related operator's/installation manual. The Bluetooth
Inc. and any use of such marks by FURUNO is under license.
Included items
The following items are included with your GC-001: 1 pack Batteries (Type: LR03(GD)E 2PT, Code: 000-194-027-10)
Note: The alkaline batteries included with this product (2×AAA) are supplied for initial installation and testing. The alkaline
batteries may have a short life-span (approx. 1 month), and should be replaced as required.
Safety Instructions
To prevent damage or injury to persons and property, follow the safety guidelines below. The following indications are used
in this guide to highlight potential dangers. Please read the safety instructions carefully before operating the equipment.
WARNING
CAUTION
WARNING
Do not disassemble or modify
the equipment.
Fire, electrical shock or bodily injury
can result.
Bluetooth Transmission and Connection
®
• This equipment uses wireless communication. External influences can interrupt or interfere with transmission.
• This equipment transmits on the 2.4GHz bandwidth. Devices such as microwave ovens and other scientific and production line equipment
also use this licensed bandwidth.
• Before using this equipment, make sure that no other equipment which transmits on the same bandwidth is in use.
• In cases where other equipment is found to be in use, turn this equipment off and move to a location where there is no interference.
• Although Bluetooth operates within a 10 m radius, obstructions can reduce the operable distance.
®
• The following factors are know to interfere with Bluetooth
- Places surrounded my metallic objects.
- Places with wireless LAN capability, microwave ovens, mobile phones, gaming equipment with communication capability and areas where
electromagnetic waves are present.
How to fit/change the batteries
To prevent injury caused by battery leakage, explosion or over-heating, adhere to these handling guidelines.
• Keep the batteries away from small children. The battery is a choking hazard and should not be swallowed. If a battery is suspected to have been
swallowed, consult a physician immediately.
• If a battery is placed incorrectly, battery leakage or explosion may occur, resulting in personal injury or damage to the equipment and property.
• Do not touch the battery or battery discharge if the battery is leaking.
The alkaline in the battery discharge can cause blindness if it comes in contact with your eyes.
If eye contact has occurred, immediately flush the area with clean water and contact a physician.
If skin contact occurs, wash the area immediately with clean water. If the skin shows signs of inflammation or irritation, consult a physician.
• Do not use batteries other than the specified alkaline batteries. Also, do not mix old batteries with new batteries.
Use of non-specified batteries, or mixing batteries, can cause contamination and/or damage to equipment and property from explosion or leakage.
• Do not place batteries in fire or water. Also, do not heat, disassemble or remodel the batteries.
The batteries may explode or leak, causing fire, injury or property damage.
• When the batteries are depleted, or the equipment will not be used for an extended period of time,
remove the batteries.
If the batteries are left in the equipment, leakage, damage, fire or contamination may occur.
• When storing the batteries, make sure the poles are facing the same direction. Also store the
batteries in a cool, dry place.
• When disposing the batteries, tape both poles (+ & -) before disposal and refer to local laws and
regulations for the correct disposal method.
1. Use a flat-head screwdriver to unfasten the fixing screw, then remove the battery cover.
2. Insert the included batteries. For replacement, remove the old batteries, then insert the new batteries.
Take particular caution that the polarity is correct. Poles are marked as "+" and "-".
3. Fit the battery cover firmly, taking care that each edge is not protruding from the case. If there are any
protrusions, the case may lose its waterproof rating and the screw may not fasten correctly.
4. After confirming that the battery cover is fitted correctly, use the screw from step 1 to secure the battery cover.
Pub. No. C72-01603-B
(1712, GREG) GC-001
USER GUIDE
word mark and logos are registered trademarks owned by Bluetooth SIG,
®
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in minor or moderate injury.
Do not remove the battery cover other
than to replace/check the batteries.
Water or foreign objects can enter the
case and damage the equipment.
communication.
®
GC-001
Model
CAUTION
The brand and product names mentioned
in this guide are trademarks, registered
trademarks or service marks of their
respective holders.
Warning, Caution
Prohibitive Action
Mandatory Action
Make sure you follow
the instructions
regarding the handling
of the batteries.
Fixing
Battery
screw
cover
