9 TEChNICAL sPECIFICATIONs
Following are the C Series technical specifications. These figures are accurate at the time of printing but
please note that all figures are subject to change without notice. For the most accurate and current information
available, please visit www.labgruppen.com.
Model C 68:4 C 48:4
Number of channels 4 4
Peak total output all channels driven 6800 W 4800 W
Peak output voltage per channel 141 V 141 V
Max. output current per channel 24.5 Arms 17.5 Arms
Max Output Power
16 ohms per ch. (all ch.'s driven) 650 W 625 W
8 ohms per ch. (all ch.'s driven) 1200 W 1000 W
4 ohms per ch. (all ch.'s driven) 1700 W 1200 W
2 ohms per ch. (all ch.'s driven) 1200 W 600 W
Hi-Z per ch. (all ch.'s driven): 70 Vrms / 100 V peak 1600 W 900 W
16 ohms Bridged per ch. 2400 W 2000 W
1)
8 ohms Bridged per ch. 1) 3400 W 2400 W
4 ohms Bridged per ch. 2400 W 1200 W
1)
2 ohms Bridged per ch. 1) n.r. n.r.
Hi-Z Bridged per ch. : 140 Vrms / 200 V peak 3200 W 1800 W
1)
35 dB and VPL: 100 V
Performance with Gain:
THD 20 Hz - 20 kHz for 1 W <0.1%
<0.05%
THD at 1 kHz and 1 dB below clipping
Signal To Noise Ratio >112 dBA
>70 dB
Channel separation (Crosstalk) at 1 kHz
Frequency response (1 W into 8 ohms) +0/-3 dB 2.3 Hz - 56 kHz
20 kOhm
Input impedance
Input Common Mode Rejection, CMR 50 dB
30 mOhm
Output impedance @ 100 Hz
Voltage Peak Limiter (VPL), max. peak output
VPL, selectable per ch. 141, 118, 100, 85, 71, 59, 50, 42 V
3)
282, 236, 200, 170, 142, 118, 100, 84 V
VPL, when bridged 3) 1)
Voltage Peak Limiter mode (per ch.) Hard / Soft
Gain and Level
Amplifier gain selectable (all channels) 1)
23, 26, 29, 32, 35, 38, 41, 44 dB
– rear-panel switches
35 dB
Default gain
Front-panel potentiometer, 21 position detented from -inf to 0 dB
Level adjustment (per ch.)
, hidden behind security panel/dust-filter grille
Connectors and switches
Input connectors (per ch.) 3-pin Phoenix, electronically balanced
Output connectors (per ch.) Barrier strip 2-pole screw terminals
Output bridge mode A+B and/or C+D, inputs A and C are input source
High pass filter -
NomadLink network On board, 2 x RJ45 connectors IN and OUT
®
Intelligent fans (on/off) Yes, depending on presence of output signal
Power on/off and Remote enable on/off Individual switches on front-panel
Cooling Two fans, front-to-rear airflow, temperature controlled speed
General Purpose Outputs (GPO) -
General Purpose Inputs (GPI) -
front-panel indicators
Common NomadLink ® Network; Power Average Limiter (PAL)
Signal present / High-impedance; -10 dB and -4 dB output
Per channel signal;Voltage Peak Limiter (VPL); Current Peak Limiter (CPL): Very
High Frequency (VHF); High temperature; Fault; Mute
Power
Operating voltage, 230 V / 115 V nominal 130-265 V / 65-135 V
Minimum power-up voltage, 230 V / 115 V 171 V / 85 V
Power Average Limiter (PAL) Yes
2)
Soft-start / Inrush Current Draw Yes / max. 5 A
Mains connector 230 V CE: 16 A, CEE7; 115 V ETL: 20 A / NEMA 5-20P
W: 483 mm (19"), H: 88 mm (2 U), D: 343 mm (13.5")
dimensions (W/h/d)
Weight 12 kg (26.4 lbs.)
Black painted steel chassis with gray painted steel front
finish
CE, ANSI/UL 60065 (ETL), CSA C22.2 NO. 60065, FCC
Approvals
Note 1): Automatic -6 dB gain compensation when bridging channels. Ch.'s A+B and/or C+D, E+F , G+H, can be bridged individually.
Note 2): PAL can reduce the maximum output power to keep the power supply operating safely, and/or to prevent excessive current draw tripping the mains breaker. Refer to Operation Manual.
Note 3): For sine waves, peak voltage output values translate to Vrms with the formula V/1.41 = Vrms. E.g. 100 V peak equals app. 70 V peak. Hence, outputs can be set for high-impedance loads without
requiring a transformer.
All specifications are subject to change without notice.
30 C Series C 68:4, C 48:4, C 28:4 and C 16:4 Operation Manual
C 28:4 C 16:4 C 20:8x C 10:8x C 10:4x C 5:4x
4 4 8 8 4 4
2800 W 1600 W 2000 W 1000 W 1000 W 500 W
141 V 141 V 100 V / 70 Vrms 100 V / 70 Vrms 100 V / 70 Vrms 100 V / 70 Vrms
12 Arms 8.5 Arms 8 Arms 5,6 Arms 8 Arms 5,6 Arms
600 W 400 W 250 W 125 W 250 W 125 W
700 W 400 W 250 W 125 W 250 W 125 W
700 W 300 W 250 W 125 W 250 W 125 W
300 W n.r 4) 125 W 60 W 125 W
700 W 400 W 250 W 125 W 250 W 125 W
1400 W 800 W 500 W 250 W 500 W 250 W
1200 W 600 W 500 W 250 W 500 W 250 W
600 W n.r 250 W 125 W 250 W 125 W
4)
n.r. n.r. n.r. n.r. n.r. n.r.
1400 W 800 W 500 W 250 W 500 W 250 W
32 dB and VPL: 100 V
<0.1%
<0.05%
>112 dBA
>70 dB
2.3 Hz - 56 kHz
20 kOhm
50 dB
48 mOhm
100, 63, 45, 32 V
200, 126, 90, 64 V
Hard / Soft
29, 32, 35, 38 dB
32 dB
Front-panel potentiometer, 21 position detented from -inf to 0 dB
, hidden behind security panel/dust-filter grille
3-pin Phoenix, electronically balanced
Barrier strip 2-pole screw terminals
A+B, C+D, E+F , G+H, inputs A, C, E, G are signal source
Fixed at 35 Hz, switchable per channel
On board, 2 x RJ45 connectors, IN and OUT
Yes, depending on presence of output signal
Individual switches on front-panel
Two fans, front-to-rear airflow, temperature controlled speed
Contact Closure types, 2-pole Phoenix
Contact Closure types, 2-pole Phoenix
2) ; Power on NomadLink ® Network; Power Average Limiter (PAL) 2) ; Power on
Signal present / High-impedance; Voltage Peak Limiter (VPL); Current
Peak Limiter (CPL): Very High Frequency (VHF); High temperature;
Fault; Mute
100-240 V
80 V
Yes
Yes / max. 5 A
IEC Inlet / NEMA 5-15P
W: 483 mm (19"), H: 88 mm (2 U), D: 343 mm (13.5")
8.5 kg (18.75 lbs.)
Black painted steel chassis with gray painted steel front
CE, ANSI/UL 60065 (ETL), CSA C22.2 NO. 60065, FCC
General
This product is manufactured by Lab.gruppen, and it
is warranted to be free from any defects caused by
components or factory workmanship, under normal
use and service, for a period of six (6) years from
date of purchase from an authorized Lab.gruppen
dealer.
If the product fails to perform as specified during the
60 W
warranty period, Lab.gruppen will undertake to repair,
or at its option, replace this product at no charge to
its owner, provided the unit is returned undamaged,
shipping prepaid, to an authorized service facility or
to the factory.
This warranty shall be null and void if the product is
subjected to: repair work or alteration by a person
other than those authorized by us; mechanical
damage including shipping accidents; war, civil insur-
rection, misuse, abuse; operation with incorrect AC
voltage, incorrect connections or accessories; opera-
tion with faulty associated equipment; or exposure to
inclement weather conditions. Damage due to normal
wear and tear is not covered by the warranty. Units
on which the serial number has been removed or
defaced will not be eligible for warranty service.
Lab.gruppen shall not be responsible for any
incidental or consequential damages. Lab.gruppen's
responsibility is limited to the product itself.
Lab.gruppen takes no responsibility for any loss
due to cancellation of any events, or rent of replace-
ment equipment or costs due to a third party's or
customer's loss of profit, or any other indirect cost
or losses however incurred.
Lab.gruppen reserves the right to make changes or
improvements in design or manufacturing without
assuming any obligation to change or improve
products previously manufactured.
This warranty is exclusive, and no other warranty is
expressed or implied. This warranty does not affect
the customer's statutory rights.
International warranties
Please contact your supplier or distributor for this
information, as rights and disclaimers may vary from
country to country.
WARRANTY 10
Technical assistance and service
International
If your Lab.gruppen product requires repair, contact
your Lab.gruppen dealer or distributor, or contact
Lab.gruppen by fax or email to obtain the location
of the nearest authorized service centre.
factory service
In the event Lab.gruppen product requires factory
service, you may contact Lab.gruppen's service
department for return instructions and a Return
Authorization number.
Please note for product return:
1. Use the original packing.
2. Include a copy of the sales receipt, your name,
return address, phone and fax number, email
address and description of the defect.
3. Mark the Return Authorization number on the
outside of the packing.
4. Ship the product prepaid to:
Lab.gruppen AB
Faktorvägen 1
SE-434 37 Kungsbacka
SWEDEN
Phone: +46 300 56 28 00
Fax: +46 300 56 28 99
info@labgruppen.com
www.labgruppen.com
C Series C 68:4, C 48:4, C 28:4 and C 16:4 Operation Manual 31
