Instructions for use
GB
English
IND73W
Contents
Features, 11-12
Instructions, 13-19
FAQs and Troubleshooting, 20-21
Service, 22
Care and Maintenance, 23-25
Disposal, 26
WASHING MACHINE
Advertisement
Table of Contents
Related Manuals for Indesit IND73W
Summary of Contents for Indesit IND73W
-
Page 1: Table Of Contents
Instructions for use WASHING MACHINE Contents General Safety Instructions, 2-5 English Product Overview, 6 Getting Started: Installation, 7-10 Features, 11-12 Instructions, 13-19 FAQs and Troubleshooting, 20-21 Service, 22 Care and Maintenance, 23-25 Disposal, 26 IND73W... -
Page 2: General Safety Instructions
General Safety Instructions WARNING CAUTION This appliance has not been designed for commercial applications. Ÿ This appliance is intended to be used in household and similar applications such as: Ÿ – farm houses – by clients in serviced apartments, holiday apartments and residential type environments This appliance is not intended for use by persons (including children) with reduced Ÿ... - Page 3 Do not insert any objects into the appliance. Ÿ Do not kink or damage the power cord, and position it out of the way so no one steps Ÿ on or places anything on the cord or against it. Do not overload the wall outlet. Overloading can result in fire or electric shock. Ÿ...
- Page 4 WARNINGS...
- Page 5 CAUTIONS Do not wash water-proof clothing...
-
Page 6: Product Overview
Product Overview Level indicator Cold and hot water connections (on back side) Detergent box Softener dispenser Wash/spin tub Control panel Handle (one on each side) Rollers (one on each back corner) Housing Adjustable leg (one on right side) Accessories included: Hot inlet hose, cold inlet hose, drain hose with elbow, bottom cover and screws. -
Page 7: Getting Started: Installation
Getting Started: Installation Unpacking This product has been packaged to protect it against transportation damage. Keep Ÿ the original packaging carton in a safe place. It will help prevent any damage if the product needs to be transported in the future. In the event that it is to be disposed of, please recycle it and all other packaging materials where possible. - Page 8 Install the water inlet hoses to your hot and cold water taps, as described below. Check and ensure that the sealing washers are firmly in place. Ÿ Attach the straight end of the hose to your water taps. Make sure to attach the hot Ÿ...
- Page 9 CAUTION! CAUTION! CAUTION! The drain hose and drain pump filter are located at the back of the machine, as Ÿ illustrated below, left. Pinching the two bands of the clamp on the drain hose, connect it to the drain hose Ÿ...
- Page 10 CAUTION! While the washer is in use, make sure the height of the drain hose is at least 80cm, Ÿ otherwise the washer will not work well, or the water may flow out in the course of washing. Also ensure the drain hose is not higher than 120cm above ground, otherwise the washer will not drain water well.
-
Page 11: Features
Features 1. Detergent indication These indicate how much powder detergent to use. See Detergent and load recommendations, page 14, for details. 2. Time and preset indicators This indicator shows the remaining time during washing, e.g.: When setting soak and wash processes, this indicator shows the time you set, e.g.: This indicator shows during presetting when the washing will be finished, e.g.: When an abnormal condition occurs, it shows the warning code, e.g.: 3. - Page 12 6. Water Level button You can choose the appropriate water level that matches the load size. Different water levels for washing or rinsing are optional. See 'Setting the water level ...', page 18, for details. 7. Preset/Ultrasonic button Press this button to preset the finish time of the washing (not applicable for the Delicate program).
-
Page 13: Instructions
Instructions A Make sure the washer is stable and level. The inbuilt levelling indicator (see page 6) will help you determine whether levelling is necessary. If so, adjust the adjustable leg (front right) to stabilise the washer (see page 7). B Make sure the water inlet hoses are properly installed (see page 8). - Page 14 Default settings Max. Program Suitable items Load Wash time Rinse Spin time Water Temp. (kg) (minutes) (times) (minutes) Level (Wash/Rinse) For normally soiled everyday Auto Auto Auto Normal* Warm/Cold clothing and other items (5~40) (5~26) (1~8) Dependent on the custom Auto Custom Cold/Cold...
- Page 15 This washing machine is equipped with a fuzzy logic function that automatically chooses certain wash cycle processes for the Normal, Heavy Duty, Custom and Wool programs. You do not have to adjust them yourself, however, if you want to adjust these values yourself, proceed as follows: 1.
- Page 16 Use this program for washing blankets or other bulky items. It will automatically select the highest water level (90L), but you can adjust this manually down to 65L according to the size of your bulky item(s). 1. Press the Power button and open the washer lid. 2.
- Page 17 This washing machine has a 0–24 hour preset function, which you can set to determine the time when the washing program will finish. (It is, in effect, similar to a 'delayed start' function, but you set the time period after which you want the wash to finish rather than to start.) NOTES: * The Preset function is not available for the Delicate program.
- Page 18 Other functions Hot / cold / warm water wash This top load washing machine must be connected to both a cold and a hot water tap. You can then set it to use either just cold water for a cold water wash, or just hot water for a hot water wash, or both hot and cold water for a warm water wash.
- Page 19 Fuzzy control For certain wash programs, the machine automatically detects the weight of your wash load and selects the appropriate wash cycle processes. • For the Normal and Heavy Duty programs, the machine will automatically select the correct water power and level, wash and spin time, and rinse type. •...
-
Page 20: Faqs And Troubleshooting
FAQs and Troubleshooting Not all unusual incidents you may encounter with your washing machine are faults, or cause for concern. Check in the list below what issues may arise and why. Also check in the table on the following page for solutions to other common problems. •... - Page 21 Error messages When the following problems occur, the microcomputer inside the washer will detect the abnormal condition. An electronic buzzer will sound for approximately 10 seconds, an error message will flash, as shown below, and the washer will stop operating. Type of Error Where to check...
-
Page 22: Service
Service Before calling for Assistance: • Check whether you can solve the problem alone (see "FAQs and Troubleshooting"). • Restart the programme to check whether the problem has been solved. • If this is not the case, contact an authorised Technical Assistance Centre using the telephone number provided on the warranty card. -
Page 23: Care And Maintenance
Care and Maintenance Use a soft cloth to wipe any water or dirt off the washer lid and housing. If using a Ÿ damp cloth, squeeze it almost dry to avoid leaving water residues. The detergent box may be pulled out for cleaning, if required. Other inside parts Ÿ... - Page 24 running water, taking care not to damage any parts. Reinstall the filter, making sure it...
- Page 25 Storage If the appliance is not going to be used for an extended period of time, please unplug the machine from the power supply and disconnect all hoses. Clean the machine and filters as described on the previous pages. Let the machine air-dry thoroughly. Then store it in the original packaging in a dry location, out of reach of children.
-
Page 26: Disposal
Disposal...
