Vector Lab Products
Refrigerators and Freezers
Operation and Service Manual
Following installation, please forward this manual
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Toll free 1-855-686-5592
www.vectorlabproducts.com
01381983R00

Advertisement

Table of Contents
loading

Related Manuals for Vector VREF12-LB-RGD

Summary of Contents for Vector VREF12-LB-RGD

  • Page 1 Vector Lab Products Refrigerators and Freezers Operation and Service Manual Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free 1-855-686-5592 www.vectorlabproducts.com 01381983R00...

  • Page 2: Table Of Contents

    Wiring diagram - Solid Door ..............16 Vector Lab Products Refrigerators and Freezers...

  • Page 3: Welcome To Vector

    . If damage is found, notify the shipper immediately and contact Vector Lab Products so that we can help in the filing of a claim, if necessary . Check your paperwork to determine which configuration you have . Vector Lab Products configuration numbers are designed to provide information about the type of refrigerator you are receiving .

  • Page 4: Ambients

    § 115 V, 60 Hz, 1 phase § Minimum circuit ampacity: 15A § Maximum size of branch circuit overcurrent device: 15A circuit § Vector Lab Products recommends circuit be protected by GFCI breaker § Does not require dedicated circuit Refrigeration Specifications §...

  • Page 5: Installation

    (Fig. 1) . 2. Plug refrigerator into a 115 V 60 Hz 15A outlet . Power the Unit 1. Plug in unit and press power button located on rear, right-hand corner . Vector Lab Products Refrigerators and Freezers...

  • Page 6: Stabilizer Bracket Details

    For the external network connection, fasten directly the pins according to the remote alarm network configuration . When an alarm occurs the contact relay switches from the N .C . position to N .O . Vector Lab Products Refrigerators and Freezers...

  • Page 7: Controller Operation

    Controller Operation In normal operation, the controller will display temperature in degrees Celsius. To change from Celsius to Fahrenheit requires a programming key. Contact Vector Products Parts Department at 1-855-686-5592 for part numbers and pricing. CAUTION! Vector Lab Products does not authorize changing any critical operating parameters as it can cause improper system operation and/or severe mechanical damage.Changing...

  • Page 8: Locking/Unlocking Of The Keypad

    Press and release any key to silence the alarm . Check that the controller is not locked (LOC) . If locked press and hold any key for 1 second and (UNL) will DISPLAY . Vector Lab Products Refrigerators and Freezers...

  • Page 9: Defrosting

    AH on the controller screen reports a High Temperature Alarm . Defrosting Vector Lab Products refrigerators and freezers do not require manual defrost as they utilize a hot gas defrost cycle to keep the evaporator coil frost free . The defrost cycle is typically always terminated when the evaporator probe (Pb2) reads 8 C .
  • Page 10 Alarms Vector Lab Products Refrigerators and Freezers...

  • Page 11: Cleaning

    4. Use a vacuum cleaner with brush attachment to clean condenser, compressor and related parts . Refrigeration System The Vector Lab Products refrigeration system is designed to give many years of trouble-free service . Except for routine cleaning of the air-cooled condenser and related parts, the refrigeration system requires no service or maintenance .

  • Page 12: Refrigeration Diagram - Refrigerators

    High Psi Low Psi Vapor Vapor HOT GAS LINE HOT GAS SOLENOID Low Psi High Psi Liquid Liquid DRYER EVAPORATOR/DEFROST UNIT CONDENSING UNIT HIGH PRESSURE VAPOR HIGH PRESSURE LIQUID LOW PRESSURE LIQUID LOW PRESSURE VAPOR Vector Lab Products Refrigerators and Freezers...

  • Page 13: Facade Removal

    2 x 156 .64 psig Start winding = 13 .35 Ω 19 .6 VREF72-LB-RGD (2 x 0 .090 kg) (2 x 2 .6 barg) (2 x 10 .8barg) Run winding = 4 .89 Ω Vector Lab Products Refrigerators and Freezers...

  • Page 14: Controller Replacement

    9. Secure wires with wire ties . 10. Reconnect (+) terminal to back up battery . 11. Remove safety latch, rotate façade, and reinstall hold down screws . 12. Plug in unit, power on, and ensure proper operation . Vector Lab Products Refrigerators and Freezers...
  • Page 15 . 11-12-13 where the temperature probes are wired and remove the cables . 2. Insert the programming key in the controller terminals n .10-11-12: Vector Lab Products Refrigerators and Freezers...
  • Page 16 2. If the programming fails, the signal leds will turn firmly red instead of green . In this case, repeat the procedure making sure that the programming key is correctly inserted into the controller terminal blocks . Vector Lab Products Refrigerators and Freezers...

  • Page 17: Door Gasket Replacement

    4. Open and close door, checking for proper gasket seal without pinching against refrigerator . Modular Refrigeration System Vector Lab Products’ Modular Refrigeration System allows technicians to remove the entire unit from the refrigerator top . 1. Remove rear support column using 5/16" nut driver .
  • Page 18 Since the cabinet is a closed environment, we use a R290 gas monitor to ensure that the interior atmosphere Is below the Lower Explosive Limit (LEL) PRIOR to energizing the power outlet . 1. To install the gas detector, simply connect each of the three CANNON Plugs to it’s corresponding mate . Vector Lab Products Refrigerators and Freezers...
  • Page 19 2. Connect the air sample tube to the factory installed connection . Vector Lab Products Refrigerators and Freezers...
  • Page 20 4. A green and orange indicator will illuminate . 5. Push the reset button, the orange indicator light will turn off . The Green light will remain on signifying power at the outlet . Vector Lab Products Refrigerators and Freezers...
  • Page 21 . This test will take approximnately one inute to complete . If no gas is detected, the unit will supply power to the internal power outlet . Vector Lab Products Refrigerators and Freezers...

  • Page 22: Wiring Diagram - Glass Door

    Ground White Black White Black White Black Black 16awg RELAY White Ground Black White Ground Black White Ground LRS-75-12 INPUT : 100-240Vac 50/60Hz OUTPUT : 12Vdc 6A -V +V Ground Blue Brown Reset Key Vector Lab Products Refrigerators and Freezers...

  • Page 23: Wiring Diagram - Solid Door

    White White Grey Brown Yellow Orange Black Black White White Black Ground White Black White Black White Black Black 16awg RELAY White Ground Black White Ground Black White Ground Ground Blue Brown Reset Key Vector Lab Products Refrigerators and Freezers...
  • Page 24 Replacement parts Vector Lab Products Refrigerators and Freezers...
  • Page 25 Door Switch 01394378 Door Lock with Key 01394329 Lock Latch 01398148 Battery Back-Up Kit 01394212 Hinging Kit 01394196 Glass Door 01394279 Door Gasket 01394097 Door Handle 01394113 Safety Fan 01394345 Not shown Kit, Condensation 01401355 Vector Lab Products Refrigerators and Freezers...
  • Page 26 Vector Lab Products Refrigerators and Freezers...
  • Page 27 01394402 Led Driver 01394055 Safety Fan 01394345 Battery Backup Protection Relay 01394394 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 25 01398296 Key, Programming, Fahrenheit, Vector Ref 25 01398304 Lighting Switch 01394360 Probes Kit 01394220 Top Protection Grid 01398155...
  • Page 28 Vector Lab Products Refrigerators and Freezers...
  • Page 29 Probes Kit 01394220 Safety Fan 01394345 Battery Backup Protection Relay 01394394 Controller- Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 25 01398296 Key, Programming, Fahrenheit, Vector Ref 25 01398304 Power Relay 01394402 Door Switch 01394378 Door Lock with Key...
  • Page 30 Vector Lab Products Refrigerators and Freezers...
  • Page 31 01394238 Power Cord 01316140 Top Protection Grid 01398171 Probe Kit 01394220 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 30 01398312 Key, Programming, Fahrenheit, Vector Ref 30 01398338 Battery Backup Protection Relay 01394394 Safety Fan 01394345 Power Relay 01394402...
  • Page 32 Vector Lab Products Refrigerators and Freezers...
  • Page 33 01394378 Power Relay 01394402 Safety Fan 01394345 Battery Backup Protection Relay 01394394 Controller-Requires Programming Key 01394410 Key, Programming, Fahrenheit, Vector Ref 30 01398338 Key, Programming, Celsius, Vector Ref 30 01398312 Probe Kit 01394220 Not shown Kit, Condensation 01401355 Vector Lab Products Refrigerators and Freezers...
  • Page 34 Vector Lab Products Refrigerators and Freezers...
  • Page 35 01316140 Top Protection Grid 01398197 Probe Kit 01394220 Lighting Switch 01394360 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 49 01398379 Key, Programming, Fahrenheit, Vector Ref 49 01398387 Battery Backup Protection Relay 01394394 Power Relay 01394402 Door Switch 01394378...
  • Page 36 Vector Lab Products Refrigerators and Freezers...
  • Page 37 01394238 Power Cord 01316140 Top Protection Grid 01398197 Probe Kit 01394220 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 49 01398379 Key, Programming, Fahrenheit, Vector Ref 49 01398387 Battery Backup Protection Relay 01394394 Safety Fan 01394345 Power Relay 01394402...
  • Page 38 Vector Lab Products Refrigerators and Freezers...
  • Page 39 01394238 Power Cord 01316140 Top Protection Grid 01398197 Probe Kit 01394220 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 49 01398379 Key, Programming, Fahrenheit, Vector Ref 49 01398387 Battery Backup Protection Relay 01394394 Safety Fan 01394345 Power Relay 01394402...
  • Page 40 Vector Lab Products Refrigerators and Freezers...
  • Page 41 Top Protection Grid 01398197 Probe Kit 01394220 Lighting Switch 01394360 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 49, Sliding Door 01398353 Key, Programming, Fahrenheit, Vector Ref 49, Sliding Door 01398361 Led Driver 01394352 Safety Fan 01394345 Battery Backup Protection Relay...
  • Page 42 Vector Lab Products Refrigerators and Freezers...
  • Page 43 01398155 Probes Kit 01394220 Safety Fan 01394345 Battery Backup Protection Relay 01394394 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Fzr 25` 01398411 Key, Programming, Fahrenheit, Vector Fzr 25` 01398429 Power Relay 01394402 Door Switch 01394378 Door Lock with Key...
  • Page 44 Vector Lab Products Refrigerators and Freezers...
  • Page 45 01394238 Power Cord 01316140 Top Protection Grid 01398213 Probe Kit 01394220 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Fzr 49 01398437 Key, Programming, Fahrenheit, Vector Fzr 49 01398445 Battery Backup Protection Relay 01394394 Safety Fan 01394345 Power Relay 01394402...
  • Page 46 Vector Lab Products Refrigerators and Freezers...
  • Page 47 01398239 Top Protection Grid 01398247 Probe Kit 01394220 Lighting Switch 01394360 Controller-Requires Programming Key 01394410 Key, Programming, Celsius, Vector Ref 72 01398395 Key, Programming, Fahrenheit, Vector Ref 72 01398403 Battery Backup Protection Relay 01394394 Safety Fan 01394345 Power Relay 01394402...
  • Page 48 801 Church Lane • Easton, PA 18040, USA 01381983R00 Toll free 1-855-686-5592 www.vectorlabproducts.com © Vector Products LLC 02/21...
