Technical Specifications

Parameter Value
Back-up battery 3V 50mAh Lithium, rechargeable, not user-replaceable, PANASONIC model VL2330
Fuse Automatic

Environmental Conditions

Parameter
Operating temperature (vertical installation)
Storage temperature
Operating and storage humidity
Vibrations
Shock
Protection class
Touchscreen technology
Touchscreen reliability
*) The front face of the Control Panel unit, installed in a solid panel, has been tested using conditions
equivalent to the standards shown in the table above. Even though the Control Panel unit‟s level of re-
sistance is equivalent to these standards, oils that should have no effect on the Control Panel can possi-
bly harm the unit. This can occur in areas where either vaporized oils are present, or where low viscosity
cutting oil are allowed to adhere to the unit for long periods of time. If the Control Panel‟s front face pro-
tection sheet becomes peeled off, these conditions can lead to the ingress of oil into the Control Panel
and separate protection measures are suggested.
Also, if non-approved oils are present, it may cause deformation or corrosion of the front face. Therefore,
prior to installing the Control Panel be sure to confirm the type of conditions that will be present in the
Control Panel‟s operating environment.
If the installation gasket is used for a long period of time, or if the unit and its gasket are removed from the
panel, the original level of the protection cannot be guaranteed. To maintain the original protection level,
be sure to replace the installation gasket regularly.
Operating Instructions
Value
0 °C ... +50 °C
-20 °C ... +70 °C
5 % ... 85 % RH not-condensing
5 Hz ... 9 Hz, 7 mm
p-p
9 Hz ... 150 Hz, 1 g
± 50 g, 11 ms, 3 pulses per axis
IP66 front panel *
Resistive
> 1 million operations
7
According to
EN 60068-2-14
EN 60068-2-14
EN 60068-2-30
EN 60068-2-6
EN 60068-2-27
EN 60529
-
-
CP650, CP660, CP675
