Installation
Installing the MA205 should be relatively easy. With a bit of
planning, the MA205 will give trouble free service for years.
1. The most important consideration when installing the MA205
is cooling. When installing it in an equipment stack, it should be the
top component. It needs at least 3"-5" of space above the amplifier
to allow for adequate convection cooling.
2. When installing the MA205 in a rack we suggest adding a
3-1/2" blank above and below the MA205. In multiple MA205
installations, plan for a 3-1/2" blank (double) between each MA205
and a 3-1/2" blank on the top and bottom. Amplifiers should always
be the top components in a rack system.
3. If MA205 channels frequently shut down due to overheating,
install a fan directed up from the MA205 bottom center.
4. Never operate the MA205 on its side, as the cooling potential
drops significantly when operated on the side.
5. Connect the MA205 inputs to the source component outputs with
good quality, short as possible RCA jack cables.
6. Connect the MA205 speaker outputs to speakers using good
quality speaker wire. Minimum 16 gauge copper wire is recommended
with 14 gauge minimum for runs over 30' (10m).
Note: Ideally the MA205 is operated into 4-8 ohm speaker
loads. The MA205 will not operate into 2 ohm loads.
Do not attempt to mono bridge the MA205
7. Make sure the speakers in each room are connected in phase with
the amplifier + going to the speaker + . Out of phase speakers give
unstable imaging and poor bass response.
8. If connecting the MA205 to the whole house sound system,
connect the whole house amplifier outputs to the MA205 speaker
terminals labeled "AMP INPUTS" using good quality speaker wire.
9. If you are planning to use a video signal to trigger the MA205
power on and off, connect a good quality video wire with an RCA
jack to the MA205 input labeled "Video Input". Make sure the music
sense button is in the "OUT" position.
10. If the music sense or video input is being used to turn the
MA205 power on and off, switch the music sense button to the
"OUT" position. Adjust the "Sens" itivity pot on the MA205 so the
amp turns on when quieter passages are playing via the RCA line level
inputs. Adjust the "Delay" pot so the amp turns off a reasonable time
after the music has stopped.
installation continued...
11. To use the 12VDC trigger to turn the MA205 on/off, connect the
trigger to the 3.5mm trigger jack. Set the music sense switch to "IN".
The front panel power switch is normally off (out position).
12. Individually adjust the channel gains as required. For best noise
and hum cancellation, all MR205 gains should be on full (fully cw).
MA205 2 Channel Power Amplifier
Inputs:
Input impedance:
Outputs:
Output power:
Peak output power: 70 watts RMS per channel (4 ohms)
Ideal impedance:
Freq. response:
S/N ratio:
THD distortion:
IMD distortion
Trigger control:
Power:
Dimensions:
Weight:
Caution:
distorted sound is heard, turn the volume down immediately
or speaker and/or amplifier damage could occur that is
not covered by the warranty. If this problem persists,
contact your dealer.
User Adjustments and Service:
adjustments on the MA205. Your installer may make
certain level and delay adjustments on the rear panel.
Caution:
so do not attempt to open or repair the MA205. Refer
servicing to a qualified technician only or contact the
factory for information.
3
Gold RCA style with adjustable gain
20 k ohms
Gold 5 way Binding posts
50 watts RMS per channel (8 ohms)
4-8 ohm speakers
10 Hz - 40 kHz +/- 1 dB (1w)
over 95 dB A weighted 50 watts
<0.1% 20 Hz to 20 kHz
<0.01% 60 Hz 7 kHz 4:1 (SMPTE)
12 VDC 35mA (3.5mm input jack)
140 watts 117 VAC
8.5" x 3.5" x 10.5"
8 lbs (3.6 kg)
Never listen to sound that is distorted. If
The MA205 contains no user serviceable parts,
There are no user
4
