Eureka AS2000 Series Quick Start Manual

PLEASE READ FOR IMPORTANT TIPS ON ASSEMBLY
AS2000-AS2039 Series
QUICK START GUIDE
For detailed vacuum information including FAQs
please visit eureka.com or call the Customer
Service Helpline: 1-800-282-2886.
8 a.m. to 7:30 p.m. (CST), Monday - Friday
10 a.m. to 6:30 p.m. (CST), Saturday - Sunday
What's In The Carton
Easy 4 Step Assembly
Fig. 1
STEP Alternate View
1
B
A
Fig. 2
B
A
Fig 1: With the backbone (B) loosely on the
base (A), rotate the backbone forward until
the vaccum is locked in the upright position.
Fig 2: stand as shown and push down on
backbone (B) valve to snap into place. Pull up
to ensure the backbone has locked properly.
Hose and Tool Storage
STEP
1
Hose
Retainer
E
C
Route hose (E) through
hose retainer on front of
handle (C).
See reverse for Get Ready to Vacuum instructions
www.eureka.com
© 2013 Electrolux Home Care Products, Inc. Printed in China PN 87469
Base (A) Backbone (B)
To view our "How to Assemble" demo, visit www.eureka.com/airspeed/assembly,
scan the QR code to the right, or contact our customer service helpline.
STEP
2
Hose Retainer
B
C
A
B
Align so that the hose retainer on the handle
(C) is facing the vacuum front. Lower the
handle (C) onto the backbone (B). Push
down to snap into place. Pull up to ensure
the handle has locked properly.
STEP STEP
2
E
Put hose end (E) into hook
at base of tool clips. Then
push hose into clips.
Handle (C) Dust Cup (D)
STEP
3
Put dust cup (D) into place on base. Push
cup handle toward backbone (B) to snap
into place.
STEP
3 4
G
Slide crevice tool (F) into
top of extension wand end
(G). Place into clips on the
side of the vacuum.
Crevice Tool (F)
Extension Wand (G)
Note: Remove Crevice Tool (F) and
Extension Wand (G) from inside of
Hose (E)
Backbone (B) hole before assembly.
STEP
4
To attach hose connector, align tabs and
lower hose onto connector. Turn clockwise
STEP
5
H
Store dusting brush (H) on On some models: Attach
back of vacuum. turbo nozzle (I) to clip on
Dusting Brush (H)
Turbo Nozzle (I)
to lock.
I
handle (C).
