- Page 1 Operation manual Daikin Altherma R Hybrid Operation manual CHYHBH05AF English Daikin Altherma R Hybrid CHYHBH08AF...
-
Page 2: Table Of Contents
Latest revisions of the supplied documentation may be available on Menu structure: Overview user settings ........the regional Daikin website or via your installer. Installer settings: Tables to be filled in by installer ....The original documentation is written in English. All other languages 3.7.1... -
Page 3: Components In A Typical System Layout
5 seconds in the main menu of the menu structure. INFORMATION If you press while changing settings, the changes will NOT be applied. 3.2.2 Status icons Icon Description Space operation mode = Heating. Not applicable. CHYHBH05+08AF Operation manual Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
Page 4: Space Heating Control
Result: The room temperature follows the manually adjusted value ( ), but will return to the scheduled value after the overrule period (= Temperature lock: 2/4/6/8 hours or permanent). Operation manual CHYHBH05+08AF Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
Page 5: Room Thermostat Control - Using The Leaving Water Temperature Home
Reheat mode 35°C Reheat tank temperature – hysteresis value In reheat mode ( ),the DHW tank continuously heats up to the temperature shown on the DHW tank temperature home page (example: 50°C). CHYHBH05+08AF Operation manual Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
Page 6: Schedules: Example
6 Copy from Saturday to Sunday. 7 Save the schedule and give it a name. See below for more details. To program the schedule for Monday 1 Use to select Monday. Operation manual CHYHBH05+08AF Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
Page 7: Menu Structure: Overview User Settings
Fuel price [7.6] Units of measurement Decimal point Temperature Pressure Produced energy Flow Consumed gas [7.7] Set weather dependent Main [7.7.1] Main Additional Set weather-dependent heating [7.7.2] Additional Set weather-dependent heating CHYHBH05+08AF Operation manual Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
Page 8: Installer Settings: Tables To Be Filled In By Installer
▪ Price value ranging from 0.00~290 valuta/MBtu (with 2 Type 2 (Scheduled significant values). only) ▪ Price value ranging from 0.00~990 valuta/kWh (with 2 Maximum setpoint Depends on significant values). model Operation manual CHYHBH05+08AF Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
Page 9: To Set The Electricity Price
Example: 2 Use to set the correct prices for High, Medium and In the morning and evening. Low, according to your electricity tariff. 3 Press to confirm. CHYHBH05+08AF Operation manual Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
Page 10: Maintenance And Service
Do NOT use the unit until a service person confirms that the part from which the refrigerant leaked has been repaired. To find the contact/helpdesk number Prerequisite: You switched the permission level to Advanced end user. Operation manual CHYHBH05+08AF Daikin Altherma R Hybrid 4P471757-1C – 2020.10... -
